The centrifugal fan listed here carries voltage 220-240V, 380 V, 3707.98 CFM, documented exactly as the manufacturer publishes it. Made by Ganzhou Changyuan Machinery Equipment Co., Ltd. (1 year on the platform, typical reply ≤1h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Centrifugal Fan
- Power: 4 kW
- Horsepower: 5.36HP
- Voltage: 220-240V, 380 V
- Maximum Air Flow: 3707.98 CFM
- Material: Carbon Steel, Steel
- Warranty: 1 Year
Technical Specifications
| Maximum Air Flow | 3707.98 CFM |
|---|---|
| Filter Type | Filter Bag |
| Voltage | 220-240V, 380 V |
| Phase | Single Phase, Three Phase |
| Power | 4 kW |
| Material | Carbon Steel, Steel |
| Main Inlet Diameter | 4 in, 6in, 8 in |
| Number Of Adaptor Inlets | 1, 2, 3 |
| Upper Filter Type | Filter Bag |
| Horsepower | 5.36HP |
| Installation | Bottom Loading, Customized, Side Loading, Top Loading |
| Maximum Sound Rating | 60 dBA |
| Warranty | 1 Year |
| Condition | New |
| Place Of Origin | Henan,china |
| Brand Name | CHANGYUAN |
| Dimension(L*W*H) | 146*69*240cm |
| Minimum Particle Size | 0.1-10 μm |
| Weight | 68 |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
PRODUCT HIGHLIGHTS
- uD83DuDCA8 Powerful Suction & Efficient Filtration
- ● Pure Copper Motor Core: Engineered for high efficiency and longevity, our vacuum cleaner delivers consistent, powerful suction that stands the test of time.
- ● Enhanced Airflow Design: Featuring elevated impeller blades, the unit achieves high-speed airflow while maintaining low operational noise levels for a comfortable user experience.
- ● Multi-Stage Filtration: Equipped with a non-woven dust bag, the system efficiently captures fine particles, ensuring cleaner air exhaust and a healthier environment.
- uD83CuDFD7️ Versatile Application & Customization
- ● Multi-Scenario Utility: Designed for versatility, this machine is ideal for workshops, commercial spaces, and industrial environments.
- ● Customizable Inlet: We offer tailored inlet options to meet specific client requirements, ensuring seamless integration with your existing systems.
- uD83DuDEE0️ Robust Design & Easy Operation
- ● 360° Swivel Casters: Fitted with heavy-duty, wear-resistant wheels, the vacuum is highly maneuverable and easy to transport across various surfaces.
- ● User-Friendly Assembly: Designed for simplicity; even beginners can install and operate the unit with zero learning curve, saving valuable time and labor costs.
Model | Motor Powe | Air volume(m³/h) | Air inlet size(cm) | Bag size(cm) | Dimensions(cm) | Package Size(cm) | Net weight/ gross weight(kg) |
MF9030B | 3kW | 6000 | 3×Φ10 | 48×80 | 121×55×210 | 117×55×57 | 47/50 |
MF9040C | 4kW | 6300 | 4×Φ10 | 63×100 | 146×69×240 | 146×69×69 | 68/78 |
MF9055 | 5.5kW | 7300 | 6×Φ10 | 63×100 | 146×69×240 | 146×69×69 | 68/78 |
MF9075 | 7.5kW | 8200 | 6×Φ10 | 63×100 | 146×69×240 | 146×69×69 | 68/78 |
* Filtration System: Adopts a high-quality non-woven fabric filtration system to lock in dust tightly.
* Clean Air: Effectively intercepts micro-particles and exhausts clean air, preventing secondary pollution.
* Clean Air: Effectively intercepts micro-particles and exhausts clean air, preventing secondary pollution.
Featuring a standard 100mm(4") air inlet, this unit ensures unobstructed airflow to rapidly extract industrial waste such as dust,
wood chips, and debris. It supports synchronized connection with multiple machines, allowing a single unit to handle simultaneous
operations across several devices. Inlet diameters are fully customizable to perfectly adapt to your specific working conditions.
wood chips, and debris. It supports synchronized connection with multiple machines, allowing a single unit to handle simultaneous
operations across several devices. Inlet diameters are fully customizable to perfectly adapt to your specific working conditions.
The impeller has undergone rigorous dynamic balancing calibration to eliminate deflection and vibration during high-speed
operation. Combined with a heightened design, it delivers greater air volume and more concentrated airflow, achieving truly
high-speed yet low-noise performance. With stable operation and an extended service life, the overall durability of the machine is
significantly enhanced.
operation. Combined with a heightened design, it delivers greater air volume and more concentrated airflow, achieving truly
high-speed yet low-noise performance. With stable operation and an extended service life, the overall durability of the machine is
significantly enhanced.
The machine body features a high-temperature baking finish, creating a dense and durable coating with excellent resistance to
corrosion and scratches. Even when operating in harsh industrial environments characterized by moisture, dust, and frequent
impacts, the chassis remains robust and looks new, effectively extending the service life of the entire unit.
corrosion and scratches. Even when operating in harsh industrial environments characterized by moisture, dust, and frequent
impacts, the chassis remains robust and looks new, effectively extending the service life of the entire unit.
Changyuan Woodworking Machinery Enterprise covers an area of 33,000square meters and currently has286 employees. It has a professional scientificresearch team, including 26 senior technical engineers, withstrong technicalforce. Our company mainly produces and operates more than ten kinds ofproducts,including woodworking dust collectors and industrial central vacuumcleaners. The company integratesdesign, production, sales and service. Strivefor excellence and create industry-leading products throughoutthe entire process.The company has passed the high-tech enterprise certification and is a trainingbase forthe integration of industry and education in universities and anengineering technology research and development center. It has 51 nationalpatents. The enterprise regards design as its soul and quality as itslife. Thefactory has automated production lines,laser fiber cutting sheet metal workshops,sprayingcenters, CNC machining centers, intelligent warehousing centers, etc.The company strictly controls qualityin all aspects, and all products have passedISO9001 quality system certification.
FAQs
Are you a factory or a trading company?
Answer: Yes, we are a manufacturing factory. We are an experienced and professional manufacturer of woodworking vacuum cleaners and bag dust collectors with a history of more than 20 years. We can guarantee product quality and good after-sales service, welcome to consult.
How do we guarantee quality?
Answer: To guarantee product quality fbr our foreign trade customers, we employ rigorous measures. Wecarefully select high-quality raw material supplierswho adhere to international standards. Ourproduction process follows a strict quality management system, ensuring stability and reliabilityWe have a dedicated quality in'spection department that conducts thorough testing on finishedproducts to meet customer any international standards, We also offer exceptional after-salesservice, promptly addre
How long does delivery [production] and shipping take?
How long does delivery [production] and shipping take?
This is our first order, how can I trust your company?
We cooperate with Alibaba, which is a trustworthy company, so you can buy our products safely. All our products are inspected by third parties, and every machine produced is certified by ISO9001quality management to ensure product quality.
Payment method?
Answer: We accept payment methods supported by the platform. If you have any questions, please consult the store customer service.
What is product warranty
Answer: The motor has a one-year warranty. If the motor burns out (non-human damage) within one year, we will send a new motor free of charge.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–29 set: US $260 / set
- 30+ set: US $250 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the centrifugal fan be supplied for my local voltage?
The standard configuration is 220-240V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Ganzhou Changyuan Machinery Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, Trading Company. Browse the full Ganzhou Changyuan Machinery Equipment Co., Ltd. range on HVACR Nexus.
