Centrifugal fan — 220 V, 380 V, air flow 21000 m³/h. The complete factory specification follows. Made by Weifang Sailair Ventilation Equipment Co., Ltd. (1 year on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Centrifugal Fan
- Model Number: SCB-800-8-0.37KW-6, SCB-1140-8-0.42KW-4, SCB-1250-10-0.55KW-5, SCB-1250-10-0.75KW-6, SCB-1380-10-0.75KW-5
- Power Source: Electric
- Power: 0.75-10P
- Voltage: 220 V, 380 V
- Air Flow: 21000 m³/h
- Material: Stainless Steel
Technical Specifications
| Blade Diameter | 32/45/49/55 |
|---|---|
| Voltage | 220 V, 380 V |
| Speed | 520, 620 |
| Type | Axial Flow Fan |
| Material | Stainless Steel |
| Blade Material | Stainless Steel |
| Mounting Type | Wall Fan |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Shandong, China |
| Brand Name | Sailair |
| Model Number | SCB-800-8-0.37KW-6, SCB-1140-8-0.42KW-4, SCB-1250-10-0.55KW-5, SCB-1250-10-0.75KW-6, SCB-1380-10-0.75KW-5 |
| Frame Material | Plastic |
| Size | 1380*1380*310 |
| Power | 0.75-10P |
| Rotation | 520,620 r/min |
| Air Flow | 21000 m³/h |
| No.Of Blades | 4/5/6 |
| Motor | 380V/50HZ/3phase or customization |
| Bearing | Imported Auto bearing |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Model | Size(mm) | Power（KW） | Rotation（r/min) | Air flow(m³/h) | Voltage | No.of blades |
SCB-800-8-0.37KW-6 | 800*800*310 | 0.37-8P | 620 | 21000 | 220V | 6 |
SCB-800-8-0.37KW-6 | 800*800*310 | 0.37-8P | 620 | 21000 | 380V | 6 |
SCB-1140-8-0.42KW-4 | 1140*1140*310 | 0.42-8P | 620 | 22500 | 220V | 4 |
SCB-1140-8-0.42KW-4 | 1140*1140*310 | 0.42-8P | 620 | 22500 | 380V | 4 |
SCB-1250-10-0.55KW-5 | 1250*1250*310 | 0.55-10P | 520 | 24500 | 380V | 5 |
SCB-1250-10-0.75KW-6 | 1250*1250*310 | 0.75-10P | 520 | 28000 | 380V | 6 |
SCB-1380-10-0.75KW-5 | 1380*1380*310 | 0.75-10P | 520 | 29500 | 380V | 5 |
SCB-1100-8-0.42KW-4 | 1100*1100*310 | 0.42-8P | 620 | 22000 | 220V | 4 |
SCB-1100-8-0.42KW-4 | 1100*1100*310 | 0.42-8P | 620 | 22000 | 380V | 4 |
SCB-1100-10-0.55KW-6 | 1100*1100*310 | 0.55-10P | 520 | 24000 | 380V | 6 |
SCB-1200-10-0.75KW-6 | 1200*1200*310 | 0.75-10P | 520 | 27500 | 380V | 6 |
Ordering and Pricing
- Minimum order quantity: 10 set
- Volume pricing:
- 10–49 set: US $96 / set
- 50–99 set: US $88 / set
- 100+ set: US $80 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 10 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the centrifugal fan be supplied for my local voltage?
The standard configuration is 220 V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Weifang Sailair Ventilation Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Weifang Sailair Ventilation Equipment Co., Ltd. range on HVACR Nexus.
