This centrifugal plastic air extractor is published with the manufacturer’s full specification — 220V/380V, power source type Electricity powered. Made by Shandong Handun Environmental Technology Co., Ltd. (9 years on the platform, typical reply ≤1h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Centrifugal Plastic Air Extractor
- Model Number: HDCF
- Power Source Type: Electricity powered
- Voltage: 220V/380V
- Material: Plastic
- Blade Material: Plastic
- Noise Level: 40 dB and above
Technical Specifications
| Duct Diameter | 160mm-300mm(6.30in-11.81in) |
|---|---|
| Mounting | Free Standing |
| Voltage | 220V/380V |
| Motor Type | AC Motor |
| Speed | 1450rpm/2900rpm |
| Material | Plastic |
| Blade Material | Plastic |
| Power Source Type | Electricity powered |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM |
| Noise Level | 40 dB and above |
| Place Of Origin | Shandong, China |
| Brand Name | Handun |
| Model Number | HDCF |
| Color | White |
| Name | Plastic Extractor Fan |
| Model | Model HDCF |
| Driven Type | Direct Driven |
| Impeller Diameter | 160mm/200mm/250mm/300mm |
| Application | Industrial Chemical Air Ventilation |
| Feature | Centrifugal flow |
| Delivery Time | 15-20 days |
| Certificate | CE/ISO |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Acid Proof Fume Plastic Extractor Fan
Centrifugal Fan
Model HDCF series anti corrosion plastic centrifugal fan is suitable for weak acid and alkali environment. Main features are anti-corrosion and acid and alkali resistant . which is widely used in scientific research, chemical, metallurgy electronic, medicine galvanizing plant, lab fume hood industries to exhaust acid and corrosion air and other noxious gas out.
Main Characteristic
100% copper coil motor and double ball bearing confirm fan long working lift time. Impeller is backward type one and made of fiber reinforced PP. While casing is made of PE. Bolts nuts for fastening impeller and casing is stainless steel 304. Inlet is the standard round type. Normal size is 160mm,200mm,250mm and 300mm. which is convenient to connect standard plastic duct. Motor support is thick steel painted by epoxy resin. Which is better efficiency for anti-corrosion.
4. Widely used in these places
1). Ware house ventilation ;
2). Factories and workshops (such as paper mill, galvanized products producing factories,
painting factories);
3). Garage and other buildings which need air ventilate.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $760 / set
- 10+ set: US $730 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal plastic air extractor?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this centrifugal plastic air extractor carry?
It is supplied with CE/ISO documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the centrifugal plastic air extractor be supplied for my local voltage?
The standard configuration is 220V/380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
