Cross flow fan — 220 V, power source Electric. The complete factory specification follows. Made by Ningbo Longwell Electric Technology Co., Ltd. (9 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Cross Flow Fan
- Power Source: Electric
- Voltage: 220 V
- Blade Material: aluminum
- Material: Plastic, Aluminum Alloy, Steel
- Speed: 4000 RPM, 1100 rpm, 990rpm
- Place Of Origin: Zhejiang, China
Technical Specifications
| Voltage | 220 V |
|---|---|
| Speed | 4000 RPM, 1100 rpm, 990rpm |
| Mounting | Wall Fan |
| Blade Material | aluminum |
| Material | Plastic, Aluminum Alloy, Steel |
| Customized Support | OEM, ODM |
| After-Sales Service Provided | Online support |
| Place Of Origin | Zhejiang, China |
| Brand Name | Longwell |
| Power Source | Electric |
| Bearing | Ball Bearing /sleeve bearing |
| Usage | fireplace |
| Fan Diameter (Mm) | 50~188 |
| Fan Length | customization available up to 1200mm |
| Application | split air conditioner , air curtains , cooling |
| Lead Time | 15-25days |
| Application Model Of AC | From 5BTU to 30BTU |
| Type | Air Cooling Fan |
| Selling Units | Single item |
| Single Package Size | 60X30X30 cm |
| Single Gross Weight | 10.000 kg |
Product Details
Fireplace fan air-conditioner fan Low noise cross flow fan
Product Overview
| Product Name | fireplace fan |
| Diameter | 30mm/40mm/43mm/45mm/50mm/60mm/80/90/100/110/120/150/180/200mm |
| Fan Length | 50-1000mm , customization length available |
| Motor | AC shaded pole motor , BLDC Motor ,AC capacitor motor |
| Voltage input | 115v/230v/12VDC/24VDC/48VDC |
| Material | Aluminum |
| Bearing | Ball Bearings / Sleeve Bearings |
| Color | Aluminum color / black coating |
| Bearing | Ball bearing and sleeve bearing available |
| Application | Cooler ,heater , floor heating , convector , oven , home appliances |
| Advantages | Low noise , long life span , competitive prices , free maintenance |
Related Products
| Product Name | Diameter | Material | Wheel Length | Number Of Blades | Shaft Diameter | Usage | |
| fireplace fan | Φ30*L | Aluminum Alloy | 100,150,200,250,300 ,400… | 20 | ∅3/∅4/∅6/∅8/∅10/∅12 | Air Curtain /AirConditioner /Air purifier / Heater | |
| Φ43*L | 100,135,150,180.200,300,350 … | 20 | |||||
| Φ45*L | 100,115,150,180,200,240,300,360,400… | 20 | |||||
| Φ50*L | 100,115,150,180,200,240,300,350,400,500… | 20 | |||||
| Φ60*L | 80,120,180,240,300,360,400,450,500 … | 22/24 | |||||
| Φ65*L | 80,120,180,240,300,360,400,450,500 … | 22 | |||||
| Φ71*L | 80,120,180,240,300,360,400,450,500,560,600… | 25 | |||||
| Φ81*L | 100, 145,380,391,480,550,630,……800 | 30 | |||||
| Φ90*L | 145,380,391,480,550,630,……800 | 35 | |||||
| Φ100*L | 250, 360,480,550,630,700,……1000 | 40 | |||||
| Φ110*L | 250, 360,480,550,630,700,……1000 | 45 | |||||
| Φ120*L | 250,360,480,550,660,680,706,……1000 | 48 | |||||
| Φ150*L | 200,360,480,515,580,660,680,810,880,….1050 | 50 | |||||
| Φ200*L | 250 360,480,515,580,660,680,810,880,….1050 | 50 | |||||
| Customization is available for any length | |||||||
Application
Customization Available
1.Are you a manufacturer ?
Yes, we are . we own over 10 production lines for different products .
2.How is your quality ?
Aboove average and top class quality are your options in our range , The quality is pretty good,and trusted by many customers in overseas .
our quality is abov the average according customer same budget , customer have 1 year warranty , and free after sales technical support in product designed life span .
3. How is your price ?
Our price is very competitive by large scale production contribution .
4.What's your lead time ?
7days -25days , depengs on volume and different items .
5.How is your responding time ?
You will get reply within 2hours online by Wechat ,Whatsapp , Skype , trade manager .
You will get respond within 8hours offline by email .
Mobile is always availble for picking up your calls .
Contact Details :
fireplace fan
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100+ piece: US $5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cross flow fan?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Can the cross flow fan be supplied for my local voltage?
The standard configuration is 220 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Ningbo Longwell Electric Technology Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Ningbo Longwell Electric Technology Co., Ltd. range on HVACR Nexus.
