Manufactured by Wuhan Huahai Century Laser, this cross flow fans is documented here exactly as the factory publishes it. Supplier profile: 18 years on the platform. Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of These Cross Flow Fans
- Laser Power: 50W/60W/100W
- Applicable Material: Metal Plastic
- Warranty: 3 Years
- Place Of Origin: Hubei, China
- Feature: Programmable
- Laser Type: Fiber Laser
Technical Specifications
| Laser Type | Fiber Laser |
|---|---|
| Marking Area | 110mm*110mm |
| Laser Source Brand | Raycus |
| Cooling System | AIR COOLING |
| Configuration | Stand-Alone |
| Control System Brand | Sino |
| Marking Head Brand | Huahai Laser |
| Feature | Programmable |
| Warranty | 3 Years |
| Mode Of Operation | Pulsed |
| Cnc Or Not | Yes |
| Graphic Format Supported | AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT |
| Condition | New |
| Key Selling Points | Multifunctional |
| Working Accuracy | High Precision |
| Place Of Origin | Hubei, China |
| Brand Name | Huahai Laser |
| Control Software | 3D marking software |
| Weight | 110 KG |
| Laser Power | 50W/60W/100W |
| Laser Wavelength | 1064nm |
| Cooling | air cooling |
| Applicable Material | Metal Plastic |
| Laser Source | Raycus,IPG |
| Galvanometer | 3d sino laser head |
| Max,Marking Area | 500*500mm |
| Control Card And Software | JCZ EZCAD3 |
| Switch | Taiwan meanwell |
| Packaging Details | standard export wooden case, according to your requirements |
| Port Of Dispatch | Shanghai, Shenzhen |
| Selling Units | Single item |
| Supply Ability | 220 sets per Month |
Product Details
Applicable Industries of fiber laser marking machine:
Mobile Phone keypad,plastic translucent keys,electronics components,integrated circuits (IC),electrical
appliances,communications products,sanitary ware,tools,accessories,knives,eyeglasses and clocks,jewelry,
auto parts,luggage buckle,cooking itensiles,stainless steel products and other industries.
Applicable Materials of fiber laser marking machine:
Metal(including rare metals),engineering plastics,electroplating materials,coating material,plastic,rubber,
epoxy resin,ceramic,plastic,ABS,PVC,PES,steel,copper and other materials
surface 200*200mm.Very good 3D marking performance.
Technical Parameters of fiber laser marking machine:
| Laser Generator Brand | RAYCUS/IPG | RAYCUS/IPG | RAYCUS/IPG |
|
| Laser Power(W) | 20 | 30 | 50 |
|
| Galvo Marking Speed | ≥7m/s | ≥7m/s | ≥7m/s | Max 9m/s |
| Marking Area | 110mm | 110mm | 110mm | 175mm optional |
| Marking Focus | 180mm | 180mm | 180mm |
|
| Marking Content | Vector, bar code, a variety of fonts, photos, and other formats |
| ||
| Marking Mode | static state and dynamic state |
| ||
| On-line Speed | ≤120m/min | Depends on marking content | ||
| Operating Temperature | 5-35°C |
| ||
| Operating Humidity | Relative humidity is less than 95%, No condensation |
| ||
| Structural Materials | good-quality aluminum alloy, stainless steel |
| ||
| Edit Mode | Computer software to edit |
| ||
| Communication Interface | USB, RS232 interface |
| ||
| Power Supply | AV220V/50Hz |
| ||
| Rated Power | 500W | 800W | 1000W |
|
| Optional Accessories | Sensor, On-line detection speed encoder, rotary marking, equipment cabinet, laser generator support | foot switch | ||
A wide selectivity of operating wavelengths Ultra-low amplitude noise High stability and ultra-long lifetime
China brand ,top 3D galvo brand in China.Speical in 3D technology
famous "wavalength" brand.Fast speed,high conversion rate
Easy operated ,and have a special 3D interferface
Precision Laser Marking Working Table
Control system use famous Taiwan “MW” power supply with stable performance.professional
technology and long lifetime
Good connection.fiber laser cable is protected by it
1> How can i install and operate fiber color laser marking machine by myself?
Re: When you get the laser marking machine, just need to connect with power cord, then machine can start work. Because the marking software is installed in computer, engineer have set the parameters well before delivery. Also, the complete English user manual and operation video will be sent to you. 98% customers can easily use the machine.
2> How to get technical support after purchasing the fiber color laser marking machine?
Re: You can contact us on Skype, WhatsApp and email at any time. Our professional engineer will solve your problem perfectly. If you need any remote assistant support, we will support you with Teamviewer software.
3> Will the laser marking machine come with protective goggle?
Re: Yes, we will provide it with the machine together free of charge.
4> Is there any consumables for the fiber laser marking machine ?
Re: There is no consumables, and maintenance-free. Laser source lifetime up to 100000+ hours.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $6000 / set
- 10+ set: US $5500 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cross flow fans?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Wuhan Huahai Century Laser Co., Ltd., based in China. The company 18 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Wuhan Huahai Century Laser Co., Ltd. range on HVACR Nexus.
