Key specification for this die-cast aluminum alloy impeller: 230V/1Ph/50Hz, blade material Aluminum Alloy. Everything below is reproduced from the factory data sheet. Made by Nanfang Ventilator Co., Ltd. (1 year on the platform, typical reply ≤6h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Die-Cast Aluminum Alloy Impeller
- Model Number: NXD No500*500
- Voltage: 230V/1Ph/50Hz
- Blade Material: Aluminum Alloy
- Noise Level: 30-70dB(A)
- Speed: 1430r/min
- Warranty: 1 Year
Technical Specifications
| Voltage | 230V/1Ph/50Hz |
|---|---|
| Speed | 1430r/min |
| Blade Material | Aluminum Alloy |
| Noise Level | 30-70dB(A) |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Control Method | RS485/0-10V interface |
| Core Components | EC brushless motor, centrifugal impeller, built-in |
| Place Of Origin | Guangdong, China |
| Brand Name | NFFAN |
| Model Number | NXD No500*500 |
| Color | Silver |
| Certificate | CCC,CE,ATEX,EAC,AMCA |
| Total Pressure (Pa) | 10-450 |
| Static Pressure (Pa) | 5-430 |
| Efficiency | 70% |
| Weight | 45KG |
| Frequency | 50/60Hz |
| Environmental Temperature | -20~40 ℃ |
| Explosion Proof/Anti-Corrosion | Yes (customizable explosion-proof/anti-corrosion type) |
| Energy Efficiency Characteristics | Ultra high energy efficiency, precise control |
| Impeller Diameter | impeller diameter 2.5-5.6dm |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $1111 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this die-cast aluminum alloy impeller?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this die-cast aluminum alloy impeller carry?
It is supplied with CCC,CE,ATEX,EAC,AMCA documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the die-cast aluminum alloy impeller be supplied for my local voltage?
The standard configuration is 230V/1Ph/50Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Nanfang Ventilator Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Nanfang Ventilator Co., Ltd. range on HVACR Nexus.
See more in Impellers & Fan Blades on HVACR Nexus.
