The driver integrated servo motor listed here carries type Servo Motor, model number iHSV60-30-40-48-EC-SC, documented exactly as the manufacturer publishes it. Made by Shenzhen Just Motion Control Electromechanics Co.,ltd. (18 years on the platform, typical reply ≤2h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Driver Integrated Servo Motor
- Model Number: iHSV60-30-40-48-EC-SC
- Rated Power: 400W
- AC Voltage: 48V DC
- Rated Speed: 3 000 RPM
- Peak Speed: 4200rpm
- Warranty: 1 year
Technical Specifications
| Phase | Single-Phase |
|---|---|
| AC Voltage | 48V DC |
| Rated Power | 400W |
| Rated Speed | 3 000 RPM |
| Type | Servo Motor |
| Frame | / |
| Motor Mounting Type | / |
| Protect Feature | Explosion-proof |
| Efficiency | IE 1 |
| Warranty | 1 year |
| Model Number | iHSV60-30-40-48-EC-SC |
| Brand Name | JMC |
| Place Of Origin | Guangdong, China |
| Frequency | 50Hz |
| Rotor Inertia | 68kg.mm² |
| Motor Length | 180mm |
| Field-Bus Type | EtherCAT |
| Communication Protocol | CANopen over EtherCAT |
| Encoder | 1000 lines |
| Peak Speed | 4200rpm |
| Shaft Size | 14*30mm |
| Rated Current | 11.2A |
| Peak Torque | 1.9Nm |
| Selling Units | Single item |
| Single Package Size | 25X15X20 cm |
| Single Gross Weight | 3.0 kg |
Product Details
Communication Specifications: | ||||||
Bus Type | RS485 | CAN | EtherCAT | |||
Baud Rate | 115200bps | 1Mbps | 100Mbps full duplex | |||
Transmission Distance | max 1km | max 1km | max interval 100m | |||
Number of Slaves | 32 | 127 | 65535 | |||
Network Topology | Daisy chain | Daisy chain | Daisy chain, Star chain, Tree chain | |||
Motion Control Mode | PP: Profile Position PV: Profile Velocity HM: Home Mode | PP: Profile Position PV: Profile Velocity HM: Home | CSP: Cycle Synchronous Position CSV: Cycle Synchronous Velocity PP / PV / HM | |||
Communication Protocol | Modbus-RTU | CIA 301 CANopen | CANopen over EtherCAT | |||
Device Protocol Standard: IEC61800-7 CiA402 Drive Profile | ||||||
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–10 piece: US $169 / piece
- 11–50 piece: US $160 / piece
- 51+ piece: US $144 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this driver integrated servo motor?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 year warranty. Spare parts and technical support remain available after the warranty period.
Can the driver integrated servo motor be supplied for my local voltage?
The standard configuration is 48V DC. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Just Motion Control Electromechanics Co.,ltd., based in China. The company 18 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Shenzhen Just Motion Control Electromechanics Co.,ltd. range on HVACR Nexus.
