Key specification for this external rotor motor: 110 V, 220 V, 380 V, 400 V, power source Electric. Everything below is reproduced from the factory data sheet. Made by Jinan Seehigh Refrigerat Equipment Co., Ltd. (1 year on the platform, typical reply ≤12h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This External Rotor Motor
- Power Source: Electric
- Voltage: 110 V, 220 V, 380 V, 400 V
- Material: Stainless Steel
- Blade Material: Stainless Steel
- Speed: 1750PRM
- Warranty: 1 Year
Technical Specifications
| Blade Diameter | 175mm-910mm |
|---|---|
| Voltage | 110 V, 220 V, 380 V, 400 V |
| Speed | 1750PRM |
| Type | ac axial fan |
| Material | Stainless Steel |
| Blade Material | Stainless Steel |
| Mounting Type | Wall Fan, Roof Fan, Ceiling Fan, Duct Fan, Free Standing, Shop Window |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM, ODM |
| Place Of Origin | Shandong, China |
| Brand Name | Seehigh |
| Product Name | AC Axial Fan |
| Function | Ventilaion |
| Application | Exhaust Ventilation |
| Brand | Seehigh |
| Color | Customers’ Requirements |
| Feature | Low Noise Power Saving |
| Motor | AC External Rotor Motor |
| Product Type | Outer Rotor |
| MOQ | 1 Piece |
| Air Volume | customize |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Rated Voltage | 230 VAC |
Frequency | 50/60 Hz |
Operating Voltage | 184~276 VAC |
Rated Speed | 1750 RPM |
Input Current | 2.7 A |
Input Power | 400 W |
Air Flow | 3531.59 CFM / 6001 m³/H |
Static Pressure | 1.26 inH₂O / 316 Pa |
Acoustical Noise | 76 dB(A) |
Life Expectance | 50,000 Hours(L10) At 40°C room, humidity 15%-65%RH. |
Insulation Class | Class B |
Motor Protection | Locked rotor protection Polarity protection Automatic restart capability |
Speed Control | Control input 0~10VDC / PWM |
Protection Type | IP44 |
Signal Output | FG (Frequency Generator) |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–48 piece: US $35 / piece
- 49–99 piece: US $30 / piece
- 100+ piece: US $25 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this external rotor motor?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the external rotor motor be supplied for my local voltage?
The standard configuration is 110 V, 220 V, 380 V, 400 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Jinan Seehigh Refrigerat Equipment Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Jinan Seehigh Refrigerat Equipment Co., Ltd. range on HVACR Nexus.
