This floor type air conditioner is published with the manufacturer’s full specification — 220V-1Ph-60Hz, 24000Btu. Made by Foshan Peile Engineering Technology Co., Ltd. (3 years on the platform, typical reply ≤8h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Floor Type Air Conditioner
- Indoor Power Supply: 220V-1Ph-60Hz
- Capacity (Btu): 24000Btu
- Cooling Capacity: 24000btu
- Capacity: 24000
- Refrigerant: R410A
- Place Of Origin: China
Technical Specifications
| Type | Ceiling |
|---|---|
| Capacity (Btu) | 24000Btu |
| Cooling/Heating | Cooling Only |
| Energy Efficiency Rating | Class A |
| EER | 2-4 |
| Fixed Frequency/Variable Frequency | Fixed Frequency |
| Refrigerant | R410A |
| Feature | Energy-Saving, Remote Control |
| Remote Control | Yes |
| Operating Language | English |
| Place Of Origin | China |
| Recommended Room Size（Square Feet） | 200 |
| Product Name | Duct Type LCAC |
| Function | Cooling |
| Indoor Power Supply | 220V-1Ph-60Hz |
| Cooling Capacity | 24000btu |
| Control | Wire controller |
| Capacity | 24000 |
| Use | Room |
| Condition | New |
| Selling Units | Single item |
| Single Package Size | 199X199X199 cm |
| Single Gross Weight | 70.0 kg |
Product Details
Model | AFCN-24CA1YG | AFCN-36CA1YG | AFCN-48CA1YG | AFCN-60CA1YG | |||
Power supply | V-Ph-Hz | 220V-1Ph-60Hz | 220V-1Ph-60Hz | 220V-1Ph-60Hz | 220V-1Ph-60Hz | ||
Cooling | Capacity | Btu/h | 24000 | 36000 | 48000 | 60000 | |
Capacity | W | 7032 | 10548 | 14068 | 17580 | ||
Input | W | 2912 | 4013 | 6400 | 7200 | ||
Rated current | A | 11.12 | 17.5 | 34.85 | 34.85 | ||
Input(indoor unit) | W | 420 | 240 | 420 | 420 | ||
Rated current(indoor unit) | A | 1.9 | 1.09 | 1.9 | 1.9 | ||
EER | Btu/h.W | 8.24 | 8.97 | 7.50 | 8.33 | ||
EER | W/W | 2.41 | 2.63 | 2.20 | 2.44 | ||
MCA | A | 2.30 | 1.30 | 2.30 | 2.30 | ||
MOP | A | 3.00 | 3.00 | 3.00 | 3.00 | ||
Operation Control | Remote controller | Remote controller | Remote controller | Remote controller | |||
Indoor coil | Number of rows | 3 | 3 | 3 | 3 | ||
Tube pitch(a)xrow pitch(b) | mm | 21×13.37 | 21×13.37 | 21×13.37 | 21×13.37 | ||
Fin spacing | mm | 1.4 | 1.4 | 1.4 | 1.4 | ||
Fin type | Hydrophilic | Hydrophilic | Hydrophilic | Hydrophilic | |||
Tube outside dia. and type | mm | 7 | 7 | 7 | 7 | ||
Inner grooved | Inner grooved | Inner grooved | Inner grooved | ||||
Coil length x height x width | mm | 680×252×40.11 | 948×252×40.11 | 1318×252×70 | 1318×252×70 | ||
Number of circuits | 4 | 4 | 5 | 5 | |||
Indoor air flow(High speed) | m3/h | 1200 | 2400 | 2100 | 2100 | ||
Indoor noise level | dB(A) | 48-52 | 51-57 | 55 | 55 | ||
Indoor unit | Dimension(W*H*D) | Body(mm) | 1050×235×675 | 1250×235×675 | 1670×235×675 | 1670×235×675 | |
Packing(W*H*D) | Body(mm) | 1130×325×765 | 1380×325×765 | 1750×325×770 | 1750×325×770 | ||
Net/Gross weight | Body(Kg) | 26.5/31 | 32/37 | 40/46 | 40/46 | ||
Indoor fan motor | Brand | Kaibang | Weiling | Kaibang | Kaibang | ||
Model | YSK110-59LD-4P17 | YSK110-180LD-4P2 | YSK110-59LD-4P17 | YSK110-59LD-4P17 | |||
Input | W | 135 | 360 | 135*2 | 135*2 | ||
Output | W | 70 | 180 | 70*2 | 70*2 | ||
Capacitor | uF | 3 | 5 | 3*2 | 3*2 | ||
Speed(hi/mi/lo) | r/min | 1310/1139/1060 | 1330/1230/1130 | 1310/1139/1060 | 1310/1139/1060 | ||
Refrigerant piping | Liquid side/ Gas side | mm | Ф9.52/Ф15.88 | Φ9.52/Φ19.05 | Φ9.52/Φ19.05 | Φ9.52/Φ19.05 | |
Max. Pipe length | m | 20 | 20 | 20 | 20 | ||
Max. Fall | m | 10 | 10 | 10 | 10 | ||
Connection wiring | Power wiring | mm2 | 3×1.0 | 3×1.0 | 3×1.0 | 3×1.0 | |
Operation temp | ℃ | 16-32 | 16-32 | 16-32 | 16-32 | ||
Draining pipe dimension | mm | Ф25 | Ф25 | Ф25 | Ф25 | ||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–99 set: US $329 / set
- 100+ set: US $299 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this floor type air conditioner?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
Can the floor type air conditioner be supplied for my local voltage?
The standard configuration is 220V-1Ph-60Hz. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Peile Engineering Technology Co., Ltd., based in China. The company 3 years as a verified Alibaba.com supplier, Trading Company. Browse the full Foshan Peile Engineering Technology Co., Ltd. range on HVACR Nexus.
