The rooftop packaged unit listed here carries capacity 56000, power source Electrical, documented exactly as the manufacturer publishes it. Made by Foshan Peile Engineering Technology Co., Ltd. (3 years on the platform, typical reply ≤7h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Rooftop Packaged Unit
- Model Number: 60hz ARV5HA1YG-16
- Power Source: Electrical
- Power (W): 5600
- Capacity (Btu): 56000
- Capacity: 56000btu/56500btu
- Material: Metal
Technical Specifications
| Type | Rooftop Air Conditioner |
|---|---|
| Application | Hotel |
| Cooling/Heating | Cooling/Heating |
| Capacity (Btu) | 56000 |
| Energy Efficiency Rating | Class A |
| Refrigerant | R-410A |
| Eer | 10 |
| Power Source | Electrical |
| Warranty | 1 Year |
| After-Sales Service Provided | Free Spare Parts |
| App-Controlled | No |
| Material | Metal |
| Operating Language | English |
| Packaging Types | Corrugated Box |
| Place Of Origin | Guangdong, China |
| Brand | Airbella |
| Cop | 11.2 |
| Power (W) | 5600 |
| Model Number | 60hz ARV5HA1YG-16 |
| Packing Dimension | 1491*1056*865 |
| Net Weigt | 196kg |
| Gross Weight | 200kg |
| Capacity | 56000btu/56500btu |
| Refrigerant Type | R410A |
| Cold And Warm Function | Outdoor Air Conditioning |
| Product Name | ARV5HA1YG-16 |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Series | SEER | ||
Nominal ton | 5Tons | ||
Model type | ARV5HA1YG-16 | ||
821047200011 | |||
Power | voltage/phase/frequency | 230V/1/60 | |
Applicable voltage | Max. | 253 | |
Min. | 187 | ||
Capacity | Cooling(Btu/h) | 56000 | |
Input （W） | 5600 | ||
Heating(Btu/h) | 56500 | ||
Input （W） | 5050 | ||
Performance | EER(Btu/h W) | 10.0 | |
SEER | 16.0 | ||
Performance | COP(Btu/h W) | 11.2 | |
HSPF | 8.5 | ||
Dimensions | Length(mm) | 1486 | |
Width(mm） | 1086 | ||
Height（mm) | 840 | ||
Net weigt（Kg） | 196 | ||
Gross weight（Kg） | 200 | ||
Packing dimension: LxWxH | 1491*1056*865 | ||
Stuffing QTY | 48 | ||
Refrigerant type | R410A | ||
Flow control | EXV | ||
Compressor | Model | MNB40FEQMC | |
Brand | Mitsubishi | ||
Type | Twin-rotary DC Inverter | ||
Capacity （W） | 12900 | ||
Input （W） | 3960 | ||
Refrigerant oil （ml） | 1100 | ||
Outdoor coil | Rows | 2 | |
Fins per inch | 17 | ||
Fin Type | Hydrophilic | ||
Fin Color | Blue | ||
Tube diameter(mm) | φ7 | ||
Indoor coil | Rows | 4 | |
Fins per inch | 17 | ||
Fin Type | Hydrophilic | ||
Fin Color | Blue | ||
Tube diameter(mm) | φ7 | ||
Outdoor fan | Quantity used/diameter(mm) | 1/600 | |
Type | Axial | ||
Motor type | AC motor | ||
Quantity speeds | 1 | ||
Quantity motors/power(kW) | 1/0.23 | ||
Motor RPM | 1050 | ||
Total nominal CFM | 4000 | ||
Indoor fan | Quantity used/diameter(in.) | 1/10*10 | |
Type | Centrifugal | ||
Motor type | AC motor | ||
Quantity speeds | 2 | ||
Quantity motors/power(kW) | 1/0.35 | ||
Motor nominal RPM | 970 | ||
Total nominal CFM | 1750 | ||
Outdoor Static Pressure（Pa） | standard | 0 | |
Indoor Static Pressure（Pa） | standard（without filter） | 70 | |
Noise level | dB(A) | 66 | |
Cooling Operation Range | °F | 63-118 | |
Heating Operation Range | °F | 5-89 | |
Screws to remove the panels in front of fan motor | 9 | ||
Ordering and Pricing
- Minimum order quantity: 10 piece
- Volume pricing:
- 10–199 piece: US $1880 / piece
- 200+ piece: US $1530 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this rooftop packaged unit?
The standard minimum order quantity is 10 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Peile Engineering Technology Co., Ltd., based in China. The company 3 years as a verified Alibaba.com supplier, Trading Company. Browse the full Foshan Peile Engineering Technology Co., Ltd. range on HVACR Nexus.
