This gas heater is published with the manufacturer’s full specification — 380 V, power source Electric. Made by Jiangsu Ruiyuan Heating Equipment Technology Co., Ltd. (17 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Gas Heater
- Power Source: Electric
- Voltage: 380 V
- Warranty: 12 months
- Certification: CE,ISO
- Place Of Origin: Jiangsu, China
- Type: Air Heater
Technical Specifications
| Type | Air Heater |
|---|---|
| Power Source | Electric |
| Voltage | 380 V |
| Core Components | heater furnace |
| Key Selling Points | Accurate Temperature Control |
| Warranty | 12 months |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Place Of Origin | Jiangsu, China |
| Brand Name | RYAN |
| Dimension(L*W*H) | customize |
| After-Sales Service Provided | Engineers available to service machinery overseas |
| Heating Type | electric heating |
| Product Type | air heater |
| Name | industrial heaters |
| Port | shanghai |
| Certification | CE,ISO |
| City | yanchneg |
| MOQ | 1set |
| Packing | 1pcs/carton |
| Factory | factory direct sell |
| Packaging Details | outside standard export wood case,industrial heaters |
| Port Of Dispatch | Shanghai |
| Selling Units | Single item |
| Supply Ability | 60 sets per Month industrial heaters |
Product Details
|
Heat efficient more than 95%.
|
|
Fast heating and cooling.
|
|
Accurate regulation and stability.
|
|
Durable equipment, easy maintenance.
|
|
Short pipe distance against the loss of heat.
|
1. Heating cylinder: 304 stainless steel for inner cylinder, carbon steel for shell.
2. Flange heater: 304 stainless steel and air inlet&outlet flange specification is DN150,1.6Mpa.
3. Sealing gasket: spiral wound gasket among flange.
4. Terminal box: A terminal box is set at top of the heating tank and the terminal box is equipped with a protective shell. The terminals of all heating pipes are arranged in the terminal box and the heating pipe terminal is drawn through the bronze plate.
5. Thermal insulation layer: the outside of the heating cylinder is installed with thermal insulation layer, alumina silicate
fiber, thickness≥100mm.
6. Welding: the type and size of the welded joint in accordance with HG20583-1998.
B.Electrical elements
2. Air switch: Schneider
3. Contactor: Schneider
4. Indicator light: Schneider
5. Press-button: Schneider
6. Solid-state relay: Ximaden
7. Temperature detection: from Anhui Tiankang
8. Terminal strip: from Aoyu
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $4000 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this gas heater?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 12 months warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this gas heater carry?
It is supplied with CE,ISO documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the gas heater be supplied for my local voltage?
The standard configuration is 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Jiangsu Ruiyuan Heating Equipment Technology Co., Ltd., based in China. The company 17 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Jiangsu Ruiyuan Heating Equipment Technology Co., Ltd. range on HVACR Nexus.
