This greenhouse air circulation fan is published with the manufacturer’s full specification — 220V/380V, power source Electric. Made by Weifang U-One Machinery Equipment Co., Ltd. (4 years on the platform, typical reply ≤5h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Greenhouse Air Circulation Fan
- Model Number: 300-600MM
- Power Source: Electric
- Voltage: 220V/380V
- Blade Material: Aluminum alloy
- Fan Material: SS OR GL
- Speed: 1400RPM
Technical Specifications
| Voltage | 220V/380V |
|---|---|
| Speed | 1400RPM |
| Type | Roof Axial Fan |
| Blade Material | Aluminum alloy |
| Mounting Type | Ceiling Fan |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM, ODM |
| Place Of Origin | Shandong, China |
| Brand Name | U-ONE |
| Model Number | 300-600MM |
| Motor | AC Motor,Copper wire motor |
| Motor Brand | China customized |
| Motor Frequency | 50/60Hz |
| Fan Material | SS OR GL |
| Certification | ce |
| Fan Type | Axial |
| Fan Noise | Lower 70DB |
| Drive | Motor drive directly |
| Function | Air circulation |
| Color | Sliver |
| Selling Units | Single item |
Product Details
1.According to the high temperture and humidity in greenhouse,individually customize high quality totally enclosed GB motor,to ensure excellent performance.
2.Air circulation fan frame all adopt the high quality stainless steel by stretching forming,attractive appearance,no rust.
3.The fixed mount with special adjustable angle design which could change air direction as per requirement.Firmly fixed,stable operation,no swing when start.
4.Fan blades are all adopt aluminum sheet by punch forming,attractive appearance,light weight,large air volume,lower vibration.
3.The fixed mount with special adjustable angle design which could change air direction as per requirement.Firmly fixed,stable operation,no swing when start.
4.Fan blades are all adopt aluminum sheet by punch forming,attractive appearance,light weight,large air volume,lower vibration.
Model NO. | Material | Size(mm) | Frame thick (mm) | Air Flow (CMH) | Blades | Blades material | Power (W) | Voltage (V) |
UO-300-1 | SS 304 | 360*360*260 | 1 | 2800 | 285mm(4 pcs) | Aluminium alloy | 120 | 380/220 |
UO-300-2 | GL sprayed | 360*360*260 | 1 | 2800 | 285mm(4 pcs) | AL | 120 | 380/220 |
UO-400-1 | SS 201 | 455*455*310 | 1 | 3800 | 385mm(4 pcs) | AL | 120 | 380/220 |
UO-400-2 | SS 304 | 460*460*270 | 1 | 4500 | 385mm(7 pcs) | AL | 180 | 380/220 |
UO-400-3 | SS 304 | 460*460*270 | 1 | 3800 | 385mm(4 pcs) | 120 | 380/220 | |
UO-400-4 | GL sprayed | 460*460*270 | 1 | 3800 | 385mm(4 pcs) | 120 | 380/220 | |
UO-500-1 | SS 201 | 555*555*310 | 1 | 5500 | 485mm(5 pcs) | 180 | 380/220 | |
UO-500-2 | SS 304 | 560*560*270 | 1 | 5500 | 485mm(5 pcs) | 180 | 380/220 | |
UO-500-3 | SS 304 | 560*560*360 | 1 | 8800 | 485mm(7 pcs) | 370 | 380/220 | |
UO-500-4 | GL sprayed | 560*560*270 | 1 | 5500 | 485mm(5 pcs) | 180 | 380/220 | |
UO-600-1 | SS 304 | 660*660*360 | 1 | 15000 | 585mm(7 pcs) | 1500 | 380/220 | |
UO-600-2 | GL sprayed | 660*660*360 | 1.2 | 15000 | 585mm(7 pcs) | 1500 | 380/220 |
WEIFANG U-ONE MACHINERY EQUIPMENT CO.,LTD is a company engaged in temperture controlled equipments,water treatment equipments and chemical raw materials, electronic products trading company. The company was established in May 2013, has many famous enterprises at home and abroad (such as SIEMENS MOTOR company) to establish a long-term friendly business relationship. Company mainly engaged in exhaust fan,cooling pad,evaporative air cooler,heater and water treatment products.
Since its inception continue to absorb a variety of talents, improve product quality, improving staff quality, in order to grow
their companies. Strict quality guarantee system and perfect management system, high-quality products after-sales service is our foothold in this, my company of "quality first, reputation first" principle, provide customers with quality and quantity of various types of products. Always uphold the "quality, integrity and pragmatic, motivated, service-oriented" business philosophy, and applies the company's management and operating among. The face of fierce competition, the company system is constantly being improved, relying on science and technology, continuously improve the technology content of products sold, for society, customers and companies to create a higher market value. My company has been in good faith to create enterprises, to credit management market, has won a good reputation, also won the respect of their domestic counterparts.
Business strictly in accordance with relevant state laws, regulations and rules of the WTO requirements management according to law, actively participate in regional economic cooperation, recent years the company has reached annual sales of as much as 5,000,000, business prospects and good, the next time, My company will expand the scale of operation and steady development of corporate economic, sincerely seeking partners, good faith cooperation and seek common development, writing a new chapter in high-tech electronics.
their companies. Strict quality guarantee system and perfect management system, high-quality products after-sales service is our foothold in this, my company of "quality first, reputation first" principle, provide customers with quality and quantity of various types of products. Always uphold the "quality, integrity and pragmatic, motivated, service-oriented" business philosophy, and applies the company's management and operating among. The face of fierce competition, the company system is constantly being improved, relying on science and technology, continuously improve the technology content of products sold, for society, customers and companies to create a higher market value. My company has been in good faith to create enterprises, to credit management market, has won a good reputation, also won the respect of their domestic counterparts.
Business strictly in accordance with relevant state laws, regulations and rules of the WTO requirements management according to law, actively participate in regional economic cooperation, recent years the company has reached annual sales of as much as 5,000,000, business prospects and good, the next time, My company will expand the scale of operation and steady development of corporate economic, sincerely seeking partners, good faith cooperation and seek common development, writing a new chapter in high-tech electronics.
Q:Is your company a manufacturer or a trading company?
A:We are manufacturers,we have own trade company, we also have our own factory and design, sales team.
Q:Can you make our own brand?
A:Yes,we can provide OEM &ODM service. And we can make your brand on the products.
Q:What kind of voltage can you make, can you customize the voltage?
A:For exhaust fans and air coolers, the standard voltage we produce is 3 phase 380V 50Hz, or 1 phase 220V 50Hz, the input power is depends on the type of product. We can customize the voltage and frequency of the motor according to your requirements.
Q:What is your minimum order quantity?
A:Usually,MOQ of exhaust fan and air cooler is 10 sets, MOQ of cooling pad is one 20’ container. Small quantity we also can do,but the cost will be high.
Q:Can I have a sample to test before ordering in large quantities?
A:Yes,of course. We can offer 1 set sample for evaluation and testing.
Q: How is your after-sale service?
A: we will guide you to install and use the machine and we will provide a certain percentage of free spare parts.If your motor break in the guaranty year Period, we will send you a fresh one or compensating you for the cost of repairing the machine by giving you the discount of the same amount in the next order.
A:We are manufacturers,we have own trade company, we also have our own factory and design, sales team.
Q:Can you make our own brand?
A:Yes,we can provide OEM &ODM service. And we can make your brand on the products.
Q:What kind of voltage can you make, can you customize the voltage?
A:For exhaust fans and air coolers, the standard voltage we produce is 3 phase 380V 50Hz, or 1 phase 220V 50Hz, the input power is depends on the type of product. We can customize the voltage and frequency of the motor according to your requirements.
Q:What is your minimum order quantity?
A:Usually,MOQ of exhaust fan and air cooler is 10 sets, MOQ of cooling pad is one 20’ container. Small quantity we also can do,but the cost will be high.
Q:Can I have a sample to test before ordering in large quantities?
A:Yes,of course. We can offer 1 set sample for evaluation and testing.
Q: How is your after-sale service?
A: we will guide you to install and use the machine and we will provide a certain percentage of free spare parts.If your motor break in the guaranty year Period, we will send you a fresh one or compensating you for the cost of repairing the machine by giving you the discount of the same amount in the next order.
Ordering and Pricing
- Minimum order quantity: 50 set
- Volume pricing:
- 50–99 set: US $35 / set
- 100–199 set: US $33 / set
- 200+ set: US $30 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this greenhouse air circulation fan?
The standard minimum order quantity is 50 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this greenhouse air circulation fan carry?
It is supplied with ce documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the greenhouse air circulation fan be supplied for my local voltage?
The standard configuration is 220V/380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Weifang U-One Machinery Equipment Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Weifang U-One Machinery Equipment Co., Ltd. range on HVACR Nexus.
