Home hvac systems — air flow 250m³/h, power voltage /frequency 210-240/50HZ. The complete factory specification follows. Made by Sichuan Guigu Renju Technology Co., Ltd. (4 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of These Home Hvac Systems
- Model Number: TFKC-025(A6-1D2)
- Power Voltage(V)/Frequency(HZ): 210-240/50HZ
- Air Flow(M³/H): 250m³/h
- Warranty: 1 Year
- Place Of Origin: China
- Application: Hotel, Apartment, Kitchen, Bedroom, Home Bar, Laundry
Technical Specifications
| Type | HVAC Systems |
|---|---|
| Application | Hotel, Apartment, Kitchen, Bedroom, Home Bar, Laundry |
| Feature | Flexible, Easy Installation |
| Warranty | 1 Year |
| After-Sale Service | Online Technical Support, Free Spare Parts |
| Design Style | Modern |
| Project Solution Capability | Others |
| Place Of Origin | China |
| Brand Name | IGUICOO |
| Product Name | HVAC Heat Recovery Ventilation System |
| Size | 990*710*255mm |
| Motor | Brushless DC Motor |
| Color | Black/White |
| Maintenance | bottom door |
| Air Flow(M³/H) | 250m³/h |
| Noise | 31dB(A) |
| Power Voltage(V)/Frequency(HZ) | 210-240/50HZ |
| Model Number | TFKC-025(A6-1D2) |
| Installation | Ceilling |
| Selling Units | Single item |
| Single Package Size | 118X76X31.5 cm |
| Single Gross Weight | 42.000 kg |
Product Details
Specification & Dimensions
Item | TFKC-025(A6-1D2) Ceiling Mounted ERV Pre-cooling and pre-heating ventilation system |
Warranty | 1 year |
After-sale Service | Online technical support, Free spare parts |
Project Solution Capability | Provide overall solution |
Application | Hotel/School/Commercial building/Real estate project |
Design Style | Modern |
Place of Origin | China |
Model Number | TFKC-025(A6-1D2) |
Size | 990*710*255mm |
Air Flow(m³/h) | 250 m³/h |
Install type | Celling |
Maintenance | Bottom /Side door |
Heat Recovery Type | Enthalpy exchanger |
Heat Recovery Efficiency(%) | 75%-80% |
Power Voltage(V)/Frequency(HZ) | 210-240/50HZ |
Noise | 31dB(A) |
OEM/ODM | Accept |
Functional Details Description
Bypass function
When the outdoor temperature is suitable, avoid the enthalpy heat exchange core, the outdoor air is directly input into the room through the bypass channel, the wind resistance is small, and the outdoor air can quickly enter the room. When the outdoor temperature is too high or too low, the bypass is auto closed, the fresh air and exhaust air exchange heat to achieve energy recovery.
Products Features
The energy/heat recovery core (enthalpy exchanger) is made of ER paper, featuring high moisture permeability, good air tightness, good tear resistance and aging resistance. The gaps between the fibers are so small that only water molecules with small diameters can pass through, not odor molecules with large diameters. In this way, temperature and humidity can be recovered smoothly, preventing pollutants from seeping into the fresh air.
Main Feature:
The heat recovery efficiency is up to 85% Enthalpy efficiency is up to 76% Effective air exchange rate above 98% Selective molecular osmosis Flame retardant, antibacterial and mildew resistance.
Working principle: The flat plates and the corrugated plates form channels for suction or exhaust air stream. the energy is recovered when the two air steams passing through the exchanger crossly with temperature difference.
Higher Energy Efficiency and Ecology by Powerful Motors
The high-efficiency brushless DC motor is built into the Smart energy recovery ventilator, which can reduce the power consumption by 70% and save energy significantly. VSD control is suitable for most engineering air volume and ESP requirements.
Energy/heat recovery ventilation technology
Fresh air + energy recovery = Reduce operating costs for cooling or heating systems Energy recovery ventilation (ERV) is the process of energy recovery in residential and commercial HVAC systems, by exchanging energy from the exhausted air of a building or space, to process ventilated air entering the room. In the hot season, the system precools and dehumidifies the fresh air, humidify and preheat in the cold season. The benefits of using energy recovery are the ability to meet ASHRAE ventilation and energy standards while improving indoor air quality and reducing the total capacity of HVAC units.
Controller
The functions of intelligent controller are suitable for various project requirements.
– Various fan speed control to offer different supply air volume and ESP
– Temperature display to monitor indoor and outdoor temperature constantly
– Power to auto restart allow ventilator recover automatically from power cut down
– CO2 concentration control
– Humidity sensor to control indoor humidity
– RS485 connectors available for BMS central control
– External control and on/error signal output to allow administrator monitor and control the ventilator easily
– Filter alarm to remind user cleaning the filter in time
– Working status and fault display-Tuya APP control
Installation and pipe layout diagram
We can provide free pipe layout design according to the customer‘s house type.
Company Profile
Packing & Shipping
Q1: How could I get a sample?
A:We do not provide free sample, if you are interested in our products please contact our customer
service, she can tell you the details of the sample.
Q2: Sample time?
A: Existing products: Within 15 days;
Q3: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q4: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q5: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
service, she can tell you the details of the sample.
Q2: Sample time?
A: Existing products: Within 15 days;
Q3: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q4: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q5: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
FAQ
Q1: How could I get a sample?
A:We do not provide free sample, if you are interested in our products please contact our customer
service, she can tell you the details of the sample.
Q2: Sample time?
A: Existing products: Within 15~35 days;
Q3: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q4: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q5: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
service, she can tell you the details of the sample.
Q2: Sample time?
A: Existing products: Within 15~35 days;
Q3: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q4: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q5: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–1 set: US $673 / set
- 2–10 set: US $557 / set
- 11–99 set: US $538 / set
- 100+ set: US $482 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this home hvac systems?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the home hvac systems be supplied for my local voltage?
The standard configuration is 210-240/50HZ. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Sichuan Guigu Renju Technology Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Sichuan Guigu Renju Technology Co., Ltd. range on HVACR Nexus.
