Key specification for this immersion waste oil heater: 110V,220V,240V,380V,480V, power source Electric. Everything below is reproduced from the factory data sheet. Made by Yancheng Wergin Technology Co., Ltd. (3 years on the platform, typical reply ≤5h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Immersion Waste Oil Heater
- Power Source: Electric
- Power Tolerance: +5% ~ -10%
- Voltage: 110V,220V,240V,380V,480V
- Heating Capacity: customized
- Material: Stainless Steel
- Tube Sheath Material: SUS304,316L,321,Incoloy800,840,600, Copper & Titanium
Technical Specifications
| Type | Immersion Heater |
|---|---|
| Power Source | Electric |
| Voltage | 110V,220V,240V,380V,480V |
| Material | Stainless Steel |
| Core Components | tubular heater |
| Key Selling Points | Long Service Life |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Heating Capacity | customized |
| Place Of Origin | Jiangsu, China |
| Weight (Kg) | 1.5 |
| Brand Name | WERGIN |
| Dimension(L*W*H) | customized |
| Working Temperature Range | 30 – 650 ℃ |
| Tube Sheath Material | SUS304,316L,321,Incoloy800,840,600, Copper & Titanium |
| Tube Diameter | 6.5mm,8mm.8.5mm,9mm,10mm,12mm and others |
| Immersion Length | 200mm to 6000mm as customer’s demand |
| Wattage | as customer’s demand |
| Installation | Non/screw/flange |
| Heating Resistance Wire | Ni-Cr/FeCr |
| Cold Areas | Depends on length and diameter 5-25mm |
| Insulation Material | High purity, compacted magnesium Oxide |
| Usage | Water/Oil/Liquid Heating Appliance |
| Power Tolerance | +5% ~ -10% |
| Selling Units | Single item |
| Single Package Size | 28X5X5 cm |
| Single Gross Weight | 1.5 kg |
Product Details
are welded or silver-brazed into a pipe or steel flange. Perfectly designed to be mounted in tanks and pressurized vessels.
flange heaters are used for heating liquid mediums or other specific types of liquids, and for heating gases (water, oil, heat
transfer fluid, and corrosive solutions).
Tube Diameter | Screw Size | Tube Length(under screw) | Dia*L (mm) | Power (low density) | Power (high density) | |||||
6-60 | 60W | 3KW | 4.5KW | 6KW | 9KW | 12KW | ||||
φ8mm | G1-1/4"(DN32/42mm) | 250mm | 280mm | 300mm | 450mm | 600mm | ||||
φ10mm | G1-1/2"(DN40/47mm) | 250mm | 280mm | 300mm | 450mm | 600mm | ||||
φ12mm | G2"(DN50/59mm) | 250mm | 280mm | 300mm | 450mm | 600mm | ||||
φ12mm | G2-1/2" (DN65-75mm) | 250mm | 280mm | 300mm | 450mm | 600mm | ||||
2.We can custom tubular heaters specially(According to your size,voltage,power etc.)
Please show us following important points when you need custom service:
1.What wattage and voltage will be used?
2.What is the diameter and heated length required?
3.What's the heating medium? Water or Oil heating?
4.What is thread flange size?
If you have drawing or product picture,or sample in hands,will be much better and helpful for exact price
calculation.
of engineering water tank, chemical pool, bathing pool, swimming pool, incubator, etc. 2. Heavy oil heater of heavy oil burner. 3.
Heaters for any liquid in various industrial chemicals
A: Yes we are the factory and have 10 production lines for us.
2.Q:What's the shipping method?
A: International express and sea transportation,Depend on customers.
3.Q:Can I use my own forwarder to transport the products for me?
A:Yes, if you have your own forwarder in Shanghai, you can let your forwarder ship the products for you.
4.Q:What's the Payment method?
A:T/T, 30% deposit before production, the balance before delivery.
We sugguest you transfer the full price at one time. Cause there is bank process fee, it would be a lot of money if you make twice
transfer.
5.Q: What is our payment term?
A:We can accept the payment by T/T, Ali Online, Paypal,Credit card and W/U .
6.Q:Can we print our own brand?
A: Yes, Of course.Will be our pleasure to be one your good OEM manufacturer in China to meet your OEM requirements.
7.Q:How to Place an order?
A:Please kinldy send us your order by email , we will confirm the PI with you.
Ordering and Pricing
- Minimum order quantity: 5 piece
- Volume pricing:
- 5–49 piece: US $10 / piece
- 50–99 piece: US $9.5 / piece
- 100+ piece: US $8.5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this immersion waste oil heater?
The standard minimum order quantity is 5 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the immersion waste oil heater be supplied for my local voltage?
The standard configuration is 110V,220V,240V,380V,480V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Yancheng Wergin Technology Co., Ltd., based in China. The company 3 years as a verified Alibaba.com supplier, Trading Company. Browse the full Yancheng Wergin Technology Co., Ltd. range on HVACR Nexus.
