This inflatable centrifugal air blower is published with the manufacturer’s full specification — rated voltage 12VDC, 24VDC, power source Electric. Made by Ningbo Leison Motor Co., Ltd. (12 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Inflatable Centrifugal Air Blower
- Model Number: LS-9250-24V
- Power Source: Electric
- Rated Voltage: 12VDC, 24VDC
- Blade Material: Plastic
- Material: PA66+GF+Aluminium
- Speed: 27000+/-5%rpm
Technical Specifications
| Application | Air Blower |
|---|---|
| Power Source | Electric |
| Rated Voltage | 12VDC, 24VDC |
| Electric Current Type | DC |
| Blade Material | Plastic |
| Pressure | High Pressure |
| Warranty | 3 Years |
| Customized Support | OEM, ODM |
| Place Of Origin | Zhejiang, China |
| Brand Name | NBLEISON |
| Model Number | LS-9250-24V |
| Phase | 3 Phase |
| Speed | 27000+/-5%rpm |
| Certification | CE and ROHS |
| Material | PA66+GF+Aluminium |
| Usage | Ventilating machine/Bipap machine and other medical equipment |
| IP | IP54 |
| Selling Units | Single item |
| Single Package Size | 10X10X12 cm |
| Single Gross Weight | 0.7 kg |
Product Details
small size dc air portable blower for air pillow machine 12V/24V/48V with power supply | ||||||
Voltage and Current | (12V–16A),(24V– 8A ),(48V–4A) | |||||
Max Air Flow (Air pressure=0) | 580/min,21CFM, 35m³/h | Max Pressure (Air flow=0) | 9.5Kpa,95 cmH2O, 1.38 psi | |||
Size | D:92mm * H:65mm | Noise | 42db(1Kpa-1M) | |||
Power | 200W | Warranty | 1 year | |||
Speed | 28000±5% rpm | MOQ | 100 pcs | |||
Material | PA66+GF+aluminium | Price | $23.98-$40 | |||
Certification | CE | Port | Ningbo/Shanghai | |||
Dc micro motor
Dc micro gear motor
High torque dc gear motor
Brushless motor
Hybrid stepper motor
AC Gear Motor
Our product ranges include: 1) DC Brush motor: 6-130mm diameter, 0.01-1000W output power
2) DC Spur Gear Motor: 12-110mm diameter, 0.1-300W output power
3) DC Planeary Gear Motor: 10-82mm diameter, 0.1-100W output power
4) Brushless DC Motor: 28-110mm, 5-1500W output power
5) Stepper Motor: NEMA 08 to NEMA 43, Can with gearbox and lead screw
6) Servo Motor: 42mm to 130mm diameter, 50-4000w
7) AC Gear Motor: 49 to 100mm diameter, 6-140 output power
A:If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed life time and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.
Q: Do you have customized service for your standard motors?
A:Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. If you need additional wires/cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q:What certifications do you have?
A:We currently have CE and ROSH certifications.
Q:Can you send me your price list?
A:Since we have hundreds of different products, and price varies per different specifications, we are not able to offer a price list. But we can quote within 24 hours once got your inquiries to make sure you can get the price in time.
Q:Can I visit your company?
A:Yes, welcome to visit our company, but please let us know at least two weeks in advance to help us make sure no other
meetingsduring the day you visit us.
Ordering and Pricing
- Minimum order quantity: 10 piece
- Volume pricing:
- 10–99 piece: US $35 / piece
- 100+ piece: US $24.8 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this inflatable centrifugal air blower?
The standard minimum order quantity is 10 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this inflatable centrifugal air blower carry?
It is supplied with CE and ROHS documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the inflatable centrifugal air blower be supplied for my local voltage?
The standard configuration is 12VDC, 24VDC. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Ningbo Leison Motor Co., Ltd., based in China. The company 12 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Ningbo Leison Motor Co., Ltd. range on HVACR Nexus.
