Shell and tube heat exchanger — material 304 stainless steel (plate), heat exchanger type Plate type, tube type, scraper type. The complete factory specification follows. For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Shell And Tube Heat Exchanger
- Voltage: none
- Flow Capacity: 20m³/h
- Material: 304 stainless steel (plate)
- Warranty: 1 Year
- Certification Standard: ISO9001/CE
- Place Of Origin: Shandong, China
Technical Specifications
| Heat Exchanger Type | Plate type, tube type, scraper type |
|---|---|
| Flow Capacity | 20m³/h |
| Fluid Compatibility | Water, steam, weak acid weak base solution |
| Material | 304 stainless steel (plate) |
| Maximum Operating Temperature | 180℃ |
| Voltage | none |
| Core Components | Heat exchange plate, sealing gasket, clamping bolt |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Efficient heat transfer |
| Working Temperature Range | -10℃~180℃ |
| Place Of Origin | Shandong, China |
| Weight (Kg) | 25 |
| Brand Name | JG |
| Liquid Flow Rate | 20m³/h(706.29ft3/h) |
| Maximum Pressure Rating | 5MPa(725.19psi) |
| Dimension(L*W*H) | 800*600*400mm(31.50*23.62*15.75in) |
| Heat Transfer Efficiency | 92% |
| Sealing Method | Leak free rubber seal |
| Cleaning Method: | detachable plate |
| Waste Heat Recovery Efficiency | 35% |
| Anti Scaling Ability | food grade polished plates |
| Installation Method | Modular splicing |
| Suitable Fuel Types | biomass/coal/gas boilers |
| Certification Standard | ISO9001/CE |
| Customization Cycle | 10-15days |
| Supporting Services | Online guidance for installation and debugging |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Product Description
Our company's heat exchangers cover multiple types such as plate, shell and tube, and spiral plate, suitable for industrial scenarios such as boiler matching, chemical heat transfer, and waste heat recovery. Made of high-quality materials such as 304/316L stainless steel and titanium, it has high temperature resistance (-10 ℃~1200 ℃), corrosion resistance, and anti scaling characteristics, with a thermal efficiency of over 92% and energy saving and consumption reduction of more than 30%. Supporting non-standard customization, it can match different heat exchange areas and pressure requirements, providing installation, commissioning, and lifelong maintenance services. It is widely used in industries such as power plants, waste incineration, food and medicine, and is a stable and efficient industrial heat transfer solution.
Specification
Specification Parameters | Plate Heat Exchanger | Shell and Tube Heat Exchanger | Spiral Plate Heat Exchanger | Waste Heat Recovery Exchanger |
Heat Exchange Area (㎡) | 8-60 | 20-200 | 20-120 | 30-150 |
Working Pressure (MPa) | 0.8-4.0 | 1.0-6.4 | 0.8-4.0 | 1.6-2.5 |
Working Temperature (℃) | -10~180 | -20~450 | -10~300 | 180~800 |
Main Material | 304/316L Stainless Steel | Carbon Steel/Titanium Alloy | 304 Stainless Steel | Heat-resistant Steel/316L Stainless Steel |
Application Scenario | Boiler Waste Heat Recovery | Chemical Fluid Heat Transfer | Petroleum Medium Heat Transfer | Waste Incinerator Supporting |
Company Profile
Packing & Delivery
Our heat exchangers for export and foreign trade are packaged in thick and reinforced solid wood wooden boxes or standard sea freight containers, which can effectively resist long-distance sea freight bumps, moisture and corrosion resistance, and external impact, ensuring that the equipment is intact throughout the entire transportation process and meeting the strict requirements of international logistics.
FAQ
Q1：What are the core parameters of the heat exchanger? Can it be customized according to our working conditions? A1：Core parameters include heat exchange area (8–500㎡), working pressure (0.8–6.4MPa), working temperature (-10℃–1200℃), and material (304/316L stainless steel, titanium alloy, etc.). We fully support non-standard customization for size, material, and structure according to your working conditions, with a 7-day fast customization plan. Q2：Does the product have international certifications? How long is the warranty period? Is overseas technical support available? A2：Our heat exchangers have passed CE, ISO 9001, and ASME certifications, complying with EU and American industrial standards. The warranty period is 12 months. We provide 24-hour online technical guidance, and can arrange on-site debugging and maintenance services through our overseas cooperative agents if needed. Q3：What packaging methods do you use for export? How to ensure the safety of long-distance sea transportation? A3：We use thickened reinforced solid wood boxes for small and medium-sized products, and standard sea containers for large equipment. All products are coated with anti-rust oil, with moisture-proof film and shock-absorbing foam inside the box, effectively resisting bumps, moisture, and corrosion during transportation. Q4：What is the minimum order quantity (MOQ)? Do you offer discounts for bulk purchases? Does the quotation include shipping and tariffs? A4：The MOQ is 1 unit for standard models and 3 units for customized models. We offer a 3%–8% discount for orders over 10 units. The quotation is FOB factory price by default, excluding shipping and tariffs, but we can provide a DDP quotation including all costs according to your destination port.
Q5：Can this heat exchanger be matched with our existing boiler/waste incinerator for waste heat recovery? Is professional installation guidance provided? A5:Our products are specially designed for boiler and waste incinerator waste heat recovery scenarios, with high temperature and corrosion resistance. We will provide detailed installation drawings and operation manuals for free, and arrange professional engineers to conduct online installation guidance throughout the process.
Q5：Can this heat exchanger be matched with our existing boiler/waste incinerator for waste heat recovery? Is professional installation guidance provided? A5:Our products are specially designed for boiler and waste incinerator waste heat recovery scenarios, with high temperature and corrosion resistance. We will provide detailed installation drawings and operation manuals for free, and arrange professional engineers to conduct online installation guidance throughout the process.
