Key specification for this ventilation axial jet fan: 230 V, 380 V, power source Electric. Everything below is reproduced from the factory data sheet. Made by Hricc Industrial Equipment (Shandong) Co., Ltd. (2 years on the platform, typical reply ≤5h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Ventilation Axial Jet Fan
- Power Source: Electric
- Power(KW): 5-250
- Voltage: 230 V, 380 V
- Material: Cast Iron
- Blade Material: Stainless Steel
- Speed: 3 000 RPM
Technical Specifications
| Voltage | 230 V, 380 V |
|---|---|
| Speed | 3 000 RPM |
| Type | Duct Axial Fan |
| Material | Cast Iron |
| Blade Material | Stainless Steel |
| Mounting Type | Free Standing |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Shandong, China |
| Brand Name | hrc |
| Product Name | HRC SDF tunnel fans |
| Power(KW) | 5-250 |
| Rotating Speed(R/Min) | 980-2800 |
| Air Volume (M³/Min) | 90-9500 |
| Pressure(Pa) | 275-9000 |
| Color | Red/white/grey/yellow/blue/customized |
| Package | Wooden case |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
风机型号 | 风量 (m³/min) | 风压(pa) | 转速 (r/min) | 最高点功率 (KW) | 最大配用电机功率 (KW) |
SDF(A)-2-4.0 | 90-140 | 275-1450 | 2900 | 33 | 2.2×2 |
SDF(A)-2-5.0 | 214-328 | 485-2695 | 2900 | 9.5 | 5.5×2 |
SDF(A)-2-5.6 | 250-385 | 540-2900 | 2900 | 17.8 | 11×2 |
SDF(A)-2-6.0 | 310-480 | 1350-4600 | 2900 | 25.1 | 15×2 |
SDF(A)-2-6.3 | 450-725 | 1500-5000 | 2900 | 30.2 | 18.5×2 |
SDF(A)-2-6.5 | 500-800 | 1600-5400 | 2900 | 7.4 | 22×2 |
SDF(A)-2-7.1 | 624-990 | 1900-6400 | 2900 | 54.2 | 30×2 |
SDF(A)-2-7.5 | 700-1100 | 2120-6750 | 2900 | 67.3 | 37×2 |
SDF(A)-2-8.0 | 760-1225 | 2400-7500 | 2900 | 83.7 | 45×2 |
SDF(A)-2-8.0 | 770-1300 | 2600-8150 | 2900 | 102.3 | 55×2 |
材质 Material | 双面PVC Double-sided PVC |
直径 Diameter | 200-3000mm或定制 200-3000mm or customized |
厚度 Thickness | 0.49-0.9mm或定制 0.49-0.9mm or customized |
重量 Weight | 470g/m²或定制 470g/m² or customized |
长度 Length | 1-300m 或定制 1-300m or customized |
抗风压性能 Wind pressure resistance | ≥5000pa |
温度 Temperature | -20-200℃ |
颜色 Color | 黑色、黄色、橙色或定制 Black, yellow, orange or customized |
equipment research and development.
Q2:Where is your factory located? How can I visit there?
A: Our factory is located in Zibo City, Shandong Province, China.Contact us ahead before you go visit,then we can fully arrange
the schedule and meet you.Welcome to visit us!
Q3: How does your factory do regarding quality control?
A: Quality is the most important principle. Hurric people always attach great importance to quality controlling from the very
beginning to the very end. Our factory has passed ISO and CE certification.
Q:ls the product customized?
A4:Varous types can be customlzed.
Q5. What is your warranty?
A.Our warranty is 12 months after received the centrifugal fans. During the warranty period, replace the damaged parts for free of
charge. Out warranty period, to provide timely, high-quality technical services and price concessions spare parts to
ensure.continuous safe and high-quality equipment operation.
Q6. What are your terms of payment?
A. TT 30% AS THE ADVANCE PAYMENT AND TT 70% AFTER INSPECTION BEFORE SHIPPING.
B. 100% IRREVOCABLE L/C AT STGHT.
Q7 . What products do you produce?
A. Industrial fan, crusher, generator and other mining machinery and equipment
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $500 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this ventilation axial jet fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the ventilation axial jet fan be supplied for my local voltage?
The standard configuration is 230 V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Hricc Industrial Equipment (Shandong) Co., Ltd., based in China. The company 2 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Hricc Industrial Equipment (Shandong) Co., Ltd. range on HVACR Nexus.
