Key specification for this wall fan: voltage Dc 24V, 12 V, power source type Corded Electric. Everything below is reproduced from the factory data sheet. Made by Guangzhou Kingan Auto Parts Co., Limited (13 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Wall Fan
- Power Source Type: Corded Electric
- Voltage: Dc 24V, 12 V
- Material: PA66
- Blade Material: Plastic PA66
- Noise Level: 40 dB and above
- Speed: 4350rpm
Technical Specifications
| Duct Diameter | 6.5inch |
|---|---|
| Mounting | Wall Fan |
| Voltage | Dc 24V, 12 V |
| Motor Type | DC Motor |
| Speed | 4350rpm |
| Material | PA66 |
| Blade Material | Plastic PA66 |
| Power Source Type | Corded Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM |
| Noise Level | 40 dB and above |
| Place Of Origin | Guangdong, China |
| Brand Name | KINGAN |
| Selling Units | Single item |
| Single Package Size | 23X23X20 cm |
| Single Gross Weight | 5.0 kg |
Product Details
Model | K3A165-DAN-72 | K3A165-DCN-72 | |
Size | 165mm | 165mm | |
Voltage | 10-15V | 16-28V | |
Current | 2.67A | 1.35A | |
Motor | Brushless | Brushless | |
Rotational speed | 4350rpm | 4480rpm | |
Airflow | 200m3/h | 200m3/h | |
Rate Power | 32W | 32W | |
Working temperature | -25℃ ~ 60℃ | ||
Control Mode | 0-10V voltage control PWM control | ||
Motor Protection | Motor shaft-locking + Over-voltage protection = soft-start protection | ||
certificate | ROHS, EMC, LVD, CE | ||
Type | Centrifugal Fan |
Brand Name | KINGAN |
Electric Current Type | DC |
Blade/Impeller Material | PA66 firbreglass-reinforced |
Direction | Clockwise Seen from Rotor |
Motor Type | BLDC External Rotor Motor |
Insulation Class | B |
Warranty | 25 Months |
Amb Working Temp | -25℃ to +60℃ |
Bearing type | Ball Bearing |
Packaging Details | Individual inner box for each single fan and blower. Each order packing is carefully designed according to the transport way. |
Port/Airport | Guangzhou, Shenzhen |
Supply Ability | 5000 Pieces per Month |
After-sales Service Provided | Technical support online (Instant chat messager, email, phone call, video call technical support) |
Place of Origin | Guangzhou, China |
Applicable Industries | Building(Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops,Restaurant,Factory),Farms,AHU,Heating Gas Boiler, Refrigeration ,Industrial Automation,Vehicles,FFU,Construction works ,Energy & Mining, Home Use |
Ordering and Pricing
- Minimum order quantity: 2 piece
- Volume pricing:
- 2–49 piece: US $58 / piece
- 50+ piece: US $50 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this wall fan?
The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the wall fan be supplied for my local voltage?
The standard configuration is Dc 24V, 12 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Guangzhou Kingan Auto Parts Co., Limited, based in China. The company 13 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Guangzhou Kingan Auto Parts Co., Limited range on HVACR Nexus.
