Key specification for this wall-mounted frp axial fan: 380 V, 220 V, power source Electric. Everything below is reproduced from the factory data sheet. Made by Qingzhou Xianghua Machinery Co., Ltd. (1 year on the platform, typical reply ≤2h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Wall-Mounted Frp Axial Fan
- Power Source: Electric
- Voltage: 380 V, 220 V
- Material: FRP
- Blade Material: Fiber Glass
- Speed: 1400RPM
- Warranty: 1 Year
Technical Specifications
| Voltage | 380 V, 220 V |
|---|---|
| Speed | 1400RPM |
| Type | Wall-Mounted Axial Fan |
| Material | FRP |
| Blade Material | Fiber Glass |
| Mounting Type | Wall Fan |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Shandong, China |
| Brand Name | Xianghua |
| Product Name | FRP Fan |
| Application | Exhaust Ventilation |
| Usage | Air Cooling System |
| Keyword | High Pressure Anticorrosion FRP Centrifugal Fan |
| Function | Ventilaion |
| Fan Type | Industrial Exhaust Ventilation Box Cooling Fan |
| Installation | Screw Fixing |
| Bearing | Ball Bearng |
| Item | Industrial Wall Mounted Exhaust Fan |
| Advantage | Higher Energy Efficiency |
| Selling Units | Single item |
Product Details
Performance Parameters of Fans | ||||||||||||
Performance Parameter | HLA – 1460 | HLA – 1260 | HLA – 1060 | HLA – 850 | HLA – 660 | HLA – 560 | ||||||
Outer Frame Size (mm) | 1460*1460*60 | 1280*1280*58 | 1060*1060*55 | 850*850*45 | 700*700*45 | 560*560*45 | ||||||
Hole Size (mm) | 1400*1400*60 | 1200*1200*58 | 1000*1000*55 | 800*800*45 | 600*600*45 | 500*500*45 | ||||||
Voltage (V) | 380 | 380 | 380 | 380 | 380 | 380 | ||||||
Motor Power (kW) | 1.1 | 0.75 | 0.55 | 0.37 | 0.37 | 0.25 | ||||||
Fan Blade Diameter (mm) | 1250 | 1080 | 900 | 650 | 480 | 380 | ||||||
Air Volume (m³/h, 0Pa) | 38000 | 32000 | 22000 | 12000 | 6000 | 5000 | ||||||
Fan Rotation Speed (rpm) | 550 | 550 | 550 | 700 | 1400 | 1400 | ||||||
Number of Blades | 6 | 6 | 6 | 6 | 3 | 3 | ||||||
Driving Method | Direct Drive | Direct Drive | Direct Drive | Direct Drive | Direct Drive | Direct Drive | ||||||
Motor Protection Class | IP55 | IP55 | IP55 | IP55 | IP55 | IP55 | ||||||
Ordering and Pricing
- Minimum order quantity: 2 piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this wall-mounted frp axial fan?
The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the wall-mounted frp axial fan be supplied for my local voltage?
The standard configuration is 380 V, 220 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Qingzhou Xianghua Machinery Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Qingzhou Xianghua Machinery Co., Ltd. range on HVACR Nexus.
