Window Air Conditioner, 24V/48V, 100%

This window air conditioner is published with the manufacturer’s full specification — model number T2-35GW/DC(12000BTU), certificate CE TUV. Made by Guangdong Tunto Green Power Technology Co., Limited (14 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Window Air Conditioner

• Model Number: T2-35GW/DC(12000BTU)
• Load Power (W): 1700W
• Output Voltage (V): 48V
• Warranty: 1 Year
• Place Of Origin: Guangdong, China
• Application: Commercial

Technical Specifications

Product Details

Product Description

Installation Instructions

Details Images

Air conditioning characteristics

Work voltage from DV42V to DC60V High-SEER BLDC (Brushless DC) permanent magnet compressor No Inverter-100% DC operation Compressor provides high erriciency operation and slow start Overnight operation available Innovative control logic for energy saving Runs smoothly at -10℃ to + 55℃ Quiet operation

Mono Solar Panels

Peak Power Watts: 250W Mono Fro STD, Poly Maximum Power Voltage: 31.8V Maximum Power Current: 8.81A Open Circuit Voltage: 38.8V Short Circuit Current: 9.33A Dimensions:1650×992×35 mm (65.0×39.1×1.38 inches) Weight:15.32 kg

MPPT Solar charger controller

01.Iron shell and excellent heat dispersion  The tracking rate of maximum power is ≥99%  02.Chinese and English liquid crystal(LCD)display

03.Display real-time power generation and curve and fault record

04.Display daily power generation and cumulative power generation

05.The components used are all first-line brands, the high temperature resistance is not lower than 105℃, and the design life is more than 10 years

06.The creative maximum power is tracking, can improve the solar system availability dramatically and maximum conversion rate is >98%.

07.With charging mode indicator and working mode indicator.

Lead Acid GEL/AGM Battery

Capacity(kWh): 0.4/0.8/1.2/1.6/2 Nominal Voltage(Vdc): 2 Nominal Capacity(AH): 200/400/600/800/1000 Voltage Range(Vdc): 2.27 V~2.30 V Depth of Discharge: 70%

Product parameters

Air conditioning parameter

Model No.

T2-17GW/DC

T2-26GW/DC

T2-35GW/DC

T2-50GW/DC

T2-60GW/DC

T2-72GW/DC

0.75HP

1HP

1.5HP

2HP

2.5HP

3HP

0.5ton

0.75ton

1ton

1.5ton

1.8ton

2ton

Power Consumption

Capacity

Cooling

Btu/h

6000

9000

12000

18000

20000

24000

W

1700

2600

3500

5200

6000

7200

Heating

Btu/h

7000

10000

13000

20000

24000

27000

W

1900

2800

3700

6000

7000

7900

Noise

Indoor

dB(A)

≤36

≤40

≤42

≤43

≤45

≤50

Outdoor

≤48dB(A)

≤50

≤50

≤52

≤54

≤56

≤58

Air Circulation

m³/h

400

450

550

650

850

1050

Suitable Area

㎡

6~10

10~15

12~25

20~30

26~42

30~48

EER

W/W

4.52

4.56

4.67

4.73

4.66

4.67

Btu/h/w

15.88

15.79

16.00

16.63

16.67

16.00

Refrigerant

R-134A

R-134A

R-134A

R-134A

R-134A

R-134A

Work Temp

℃

-15~60

-15~60

-15~60

-15~60

-15~60

-15~60

Power Consumption

Power Input

W

350

500

750

1100

1200

1300

Rated Current

A

32.5

19/9.5

16

22

24

30

Input Power

V

DC 12

DC 24/48

DC 48

DC 48

DC48

DC48

Certifications

Why Choose Us

With diligent sureness and service innovation as our company spirit, careful manufacture, continuous improvement and pursuit of excellence as our quality spirit.

Ordering and Pricing

• Minimum order quantity: 2 set
• Volume pricing:
  • 2+ set: US $399 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this window air conditioner?

The standard minimum order quantity is 2 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Which certifications does this window air conditioner carry?

It is supplied with CE TUV documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.

Can the window air conditioner be supplied for my local voltage?

The standard configuration is 48V. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Guangdong Tunto Green Power Technology Co., Limited, based in China. The company 14 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Guangdong Tunto Green Power Technology Co., Limited range on HVACR Nexus.
