Cooled Industrial Water Chiller, TAICH, Plastic

The cooled industrial water chiller listed here carries cooling capacity 100 Ton chiller, 106 Kw, documented exactly as the manufacturer publishes it. Made by Shandong Taicheng Precision Technology Co., Ltd. Jinan Branch (4 years on the platform, typical reply ≤1h). Send your target quantity and destination for a firm quotation with current lead times.

Key Features of This Cooled Industrial Water Chiller

• Power: 106 Kw
• Compressor Power: 106 Kw
• Voltage: 3PH-380V-50Hz or according to customer need
• Cooling Capacity: 100 Ton chiller
• Refrigerant: R22 / R407c / R134a / R507
• Warranty: 1 Year

Technical Specifications

Product Details

Product Overview

TAICH Air Cooled industrial Water Chiller For Plastic Injection Machine

TAICH believe that customer will not only need a chiller, but also a supplier with rich experience in the cooling field to solve your cooling problems. TAICH Chiller have 15 years experience refrigeration engineer team, and 10 years manufacture experience, can support you a professional water cooling solution and stable quality chillers, we will be your reliable partner.

TAICH Water cooled chiller with the follow performance which can ensure your future use feel happy.

1. This industrial water chiller can alternate operation automatically according to load change, to balancing the operating load of the compressor, greatly extending the working life of the chillers, with trouble-free working life of more than 45,000 hours.
2. Equipped with one HANBELL or BITZER screw compressor, suitable for the cooling capacity 30 Ton to 300 Ton needs.

Air Cooled Screw Chiller Series Characteristic

1. Our chiller compressor is imported from Italy,France and so on, being of high-quality built-in safe protection, with low noise, the electricity of province is durable.

2. Industrial air cooled screw chiller series cooling capacity range: 680 kw~600 Kw ;

3. Water Chiller normal conditions: Chilled water inlet temperature is 12 degree, outlet temperature is 7 degrees. Cooling water inlet temperature is 30 degrees, outlet temperature is 35 degrees. But the lowest temperature can be -25 degree;

4. Industrial chiller stardard Input power: 3P-380V-50Hz, Allowable fluctuate voltage: ± 10%, allowable voltage difference in phase: ± 2%,Can also be customized according to customers’request.

5. All screw water chiller the quantity of compressor can be one or two ,each compressor is independent refrigeration system. Each other run independently.when the one is working ,the other can be working or not.

6. Water Chiller use PLC microcomputer control from Germany Siemens LCD touch screen, both English and Chinese human-machine interface.

7. The industrial chiller wide range of variable chilled water temperature to meet the industrial requirements throughout whole year.

8.Our industrial chiller standard refrigerant is R22, but you can choose to use environmental refrigerant such as R407C , R134A or R507.

Water Chiller Pictures

Product Paramenters

TAICH Air Cooled industrial Water Chiller For Plastic Injection Machine
Model			TC-200	TC-5250	TC-300	TC-450	TC-530
Cooling Capacity	Kw	220	2700	330	450	530
		USRT / Ton	62.6	76.8	93.8	127.9	150.7
		Kcal/h	189200	232200	283800	38700	455800
Power Supply			3PH-380V-50Hz or according to customer local need
Refrigerant	Type	R22 / R407c / R134a /R507
		Control	Thermostatic expansion valve
Compressor	Type	Semi-hermetic screw type
		Power (Kw)	73	86	106	142	165
		Start Type	Y-△
		Capacity Control	25-50-75-100(%)
Evaporator	Type	Shell and tube
		Water flow            ( m3/h)	38	46	57	77	91
		Inlet / Outlet	DN80	DN100	DN100	DN100	DN100
Condenser	Type	High efficiency hydrophilic aluminum foll finned type
		Cooling Air (m3/h)	80000	100000	120000	160000	180000
Protect System	Compressor overheat protection, high/low pressure protection, phase missing/sequence protection, flow rate protection, anti-frozen protection.
Dimension	L(mm)	3300	4400	3850	4750	5850
		W(mm)	2300	2300	2200	2200	2000
		H(mm)	2400	2400	2350	2450	2450
Weight	KG	3200	3800	3300	4000	5000

Manufacturing Technique

Water Chiller Control System

TAICH has developed a highly intelligent PLC and PC-level computer control system, which can be used for remote monitoring and control. Simple operation, connect with power supply directly, with lower failure, and high safety factor, easy installation. User can set the parameter as real working need, intuitive and reliable; SIEMENS PLC is workable.

Touch Type Panel

SIEMENS Brand Control System; Touch Type LED Panel

Electric Components

Schneider Brand Electric Components

Semi-Hermetic Screw Compressor For Water Chiller

(1). All the TAICH air cooled screw chillers adopt world famous brand semi-hermetic screw and semi-hermetic reciprocating compressors, such as HANBELL, BITZER, REFCOM and etc.
(2). Twin-screw 5:6 gear ratio and advanced linear design, low energy consumption and eco-friendly; good performance, low noise.
(3). According to the cooling capacity need, adopt single compressor or twin compressors circuits system; The compressors can automatically run alternately according to the load change, and balance the running hours of each compressor, which greatly prolongs the chillers working life, and the trouble-free running can reach more than 45,000 hours.

Heat Exchanger -Evaporator

(1). Adopt the internally and externally threaded reinforced tubes.
(2). The inside surface of the copper pipe is threaded, the outside surface of the copper pipe is smooth, so that can ensure the
good heat exchange efficient.
(3). The evaporator design running with the latest CAD design technology, CNC production and processing, compact structure ,
stable performance. And outside insulated with 25mm thick PE insulation, no condensation, less cooling loss.

Condenser

Copper tubes more thicker and processed into trapezoidal low-assistance tubes to enhance heat transfer capacity. The surface of the copper pipe is smooth, which reduces the water pressure and easy to clean and maintain.
Protection System: temperature control switch, high and low pressure switch, overload protection, compressor overheat protector, compressor frequent start protector and abnormal indicator light.

The Air Cooled Chiller Auxiliary Parts Nedd

1. Chilled water pump: connect with user equipment ( or tank) to water cooled chiller evaporator, send the cold water to customer, bring out the heat from customer.

We will supply the complete set for you, please reference the diagram system as follows

Successful Project

Air cooled chiller plastic injection machine project

Water chiller food process project

Beverage project industrial water chillers

Plastic extrusion project chiller

Certifications

Company Profile

TAICH-Your Reliable Industrial Water Chiller Manufacturer

1. With 15,000 square meters workshop; with three management system: R&D Center, Manufacturing center and Quality control center. With CNC machining center, automatic pipe bending machine, laser welding machine, high-frequency welding machine, high and low temperature testing platform and etc high-end manufacturing and testing equipment , so from the R&D to production to quality control, all-round guarantee of product delivery.

2. 40+ Skilled Workers and 15+ experienced R&D,Service Team.

3. 5000+ Annual Sales Chiller Units, Provided To 100+ Countries Market.

4. 10+ Years Experience In Industrial Cooling Worked For 50+ Field.

5. "Quality first, technological innovation" is our product concept, which requires us to be extremely responsible to customers, with zero tolerance for product defects, and requires us to focus on product optimization. We believe that by adhering to the business philosophy of "quality for survival, service for development" to build the company into a strong enterprise in the industrial refrigeration industry!

FAQ

Q 1: If you are manufacturer or trader?

Reply: We are manufacturer, all product will be factory direct price, and factory one to one directly service.

Q 2: How can I choose a right water chiller model?

Reply: If you can make sure the cooling capacity need, can find the suitable model according to our parameter data, or inform us, we choose for you. If you are not sure the cooling capacity, can inform us:

(1). Your process line description, such as what's the industry, what's the production capacity, what's the power and etc;

(2). What's the water flow in your system?

(3). What's the inlet and outlet temperature need?

(4).Or any more information you can share us, we will calculate and suggest a suitable water chiller proposal for you.

If you are looking for the most suitable Water Chiller, TAICH Chiller is the right choice. Call our sales manager for further guidance on the models, sizes, and configurations, and place your order at a very reasonable price.

Welcome to visit our factory.

Ordering and Pricing

• Minimum order quantity: 1 set
• Volume pricing:
  • 1+ set: US $12000 / set
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this cooled industrial water chiller?

The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.

Can the cooled industrial water chiller be supplied for my local voltage?

The standard configuration is 3PH-380V-50Hz or according to customer need. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Shandong Taicheng Precision Technology Co., Ltd. Jinan Branch, based in China. The company 4 years as a verified Alibaba.com supplier, Trading Company. Browse the full Shandong Taicheng Precision Technology Co., Ltd. Jinan Branch range on HVACR Nexus.
