Low temperature glycol chiller — voltage 3PH-380V/50hz as usual, others available, 58.8KW. The complete factory specification follows. Made by ShenChuangYi Refrigeration Co., Ltd. (6 years on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Low Temperature Glycol Chiller
- Model Number: SCY-20A
- Power: 58.8KW
- Voltage: 3PH-380V/50hz as usual, others available
- Refrigerant: R22, R407C, R410A, R134A
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
Technical Specifications
| Voltage | 3PH-380V/50hz as usual, others available |
|---|---|
| Power | 58.8KW |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Competitive Price |
| Core Components | PLC, Pump, Compressor, Condenser, Evaporator |
| Model Number | SCY-20A |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 760 |
| Brand Name | SCY |
| Dimension(L*W*H) | 1900x990x1660mm |
| Working Temperature Range | -5deg C ~50deg C |
| Product Name | Air cooled water chiller |
| Application | Injection molding, extrusion, blowing |
| Compressor Type | Hermetic scroll |
| Compressor Brand | Copeland, Danfoss, Pansonic |
| Refrigerant | R22, R407C, R410A, R134A |
| Evaporator Type | Shell and tube/ Plate/ Coil in Tank |
| Condenser | Air cooled finned copper tube |
| Expansion Valve | Emerson/ Danfoss |
| Dry Filter | Danfoss / Emerson |
| Temperature Controller | Microcomputer |
| Selling Units | Single item |
| Single Package Size | 15X10X15 cm |
| Single Gross Weight | 15.0 kg |
Product Details
Product Overview
-5C 0C Brewery Beer Wine Production Cooling Low Temperature Glycol Chiller With Heat Exchanger Plate
Industrial Air Cooled glycol chiller widely work for many different industries, such as food, beverage, brewery, winery, distillery, dairy and normal water chiller work for plastic injection molding, extrusion(sheet & profile), blow molding, PET, plastic film, and other industrial field : electroplating (surface treatment), chemical, hydraulic system, leaser, shoe-making, electronic, printing, etc.
FEATURES AT A GLANCE
Industrial Air Cooled Water Chiller
Air cooled industrial chiller is a kind of most popular sale chillers, easy installation, it can start to work by water pipeline and power connected, no need to apply with cooling tower, and convenient to install and move in the factory.
1. Using Panasonic from Japan, COPELAND from the United States and Danfoss from Denmark, low noise and power saving, More durable; 2. With high efficiency V type shape condenser, easy for heat discharge out； 3.World famous brand parts: such Danfoss/ ALCO expansion valve, Schneider electrical components; 4. Chiller have 3 type evaporator work for different circuit: Closed shell and tube/ Plate, and Open tank coil ; 5.Stable quality, long using life. 6.Strong unit base frame ensured the equipment stable operation 7.Refrigerant is R407C,R22,but R410A,R134A also available. 8.Power and frequency supply:380V-3PH-50HZ as standard;othes 220~480V-3PH, 50/60HZ available; 9.Chilled water range: -5°C to 30°C
PRODUCT CONFIGURATION
Temperature Control System
1. Micro-computer control system include program board and operation panel;
2. Display current actual temperature and also show set temperature, detail running parts status can be inquired and errors show with full system protections.
Electrical Components
1. Schneider electrical parts as regularly, and other Simens, Chnt, ABB available with UL CSA certified.
2. Include air switch, AC Contactors, Thermal relay, to match for each motor capacity.
3. Reliable and safe
Emerson Copeland Compressor
Panasonic Compressor
Water Flow Switch
Coil in Tank type Evaporator.
1. Stainless steel water tank, internal with SUS304 tube, no rust on water system.
2. with water level sensor and ball valve for auto-filling water.
Plate type evaporator
1. Smart space , copper welding and stainless steel plates material.
2. much higher cooling efficiency and easy for built one buffer tank
Shell and tube type evaporator
1. Closed loop, shell and tube type, , compared to open tank type, more stable system.
2. suitable for cooling multiple plastic moulding machines.
Axial Fans
Circulation Water Pump.
High/low Pressure Controller
PRODUCT SPECIFICATIONS
Model | SCY-10A | SCY-12A | SCY-15A | SCY-20A | SCY-25A | ||||||
Power supply | 3Φ-50Hz-380V(208-230V, 380-420V,440-480V,50Hz or 60Hz, 3phase) | ||||||||||
Cooling capacity | kw at +7deg C | 28.5 | 35.7 | 40.5 | 58.8 | 70 | |||||
kw at 0deg C | 21.8 | 28.5 | 27.1 | 47 | 55.6 | ||||||
kw at -5deg C | 17.5 | 21.4 | 23.2 | 36.7 | 43.2 | ||||||
Power consumption | kw | 9.35 | 11.25 | 14.1 | 18.4 | 21.7 | |||||
Running current | A | 18.1 | 21.7 | 27.2 | 35.5 | 41 | |||||
Freeze water flow | m³/h | 4.8 | 6 | 7.8 | 10.8 | 12.6 | |||||
Compressor | Type | Scroll | |||||||||
Input power(kw) | 7.5 | 9 | 11.25 | 15 | 18 | ||||||
Pump | Power(kw) | 0.75 | 0.75 | 1.5 | 1.5 | 2.2 | |||||
Refrigerant | Type | R22, R134a, R407c, R410a | |||||||||
Control method | External balanced thermostatic expansion valve | ||||||||||
Filling (kg) | 6 | 7 | 8 | 12 | 13 | ||||||
Evaporator | Type | Shell and tube, Plate, Coil in Tank | |||||||||
Pipe size(in) | 1-1/2" | 2" | 2-1/2" | ||||||||
Condenser | Type | High efficient Finned Copper Tube | |||||||||
Fan | Type | Axial-flow Fan | |||||||||
Air volume(m³/h) | 10000 | 12000 | 15000 | 20000 | 25000 | ||||||
Power(kw) | 1.1 | 1.35 | 1.35 | 1.5 | 1.5 | ||||||
Safty protector | Dual pressure switch, frost-proof protection, soluble pin/safety valve, overload protective device, coil over-heating protection system, temperature automatic protection switch. | ||||||||||
Dimension | Length(mm) | 1300 | 1450 | 1600 | 1900 | 1900 | |||||
Width(mm) | 780 | 790 | 900 | 990 | 990 | ||||||
Height(mm) | 1530 | 1530 | 1640 | 1660 | 1860 | ||||||
Weight(kg) | 400 | 450 | 540 | 760 | 810 | ||||||
PRODUCT PICTURE
Successful Project
Scope of application
Company Profile
Why Choose Us
Certifications
Ordering and Pricing
- Minimum order quantity: 1 unit
- Volume pricing:
- 1–4 unit: US $4800 / unit
- 5+ unit: US $4200 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this low temperature glycol chiller?
The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the low temperature glycol chiller be supplied for my local voltage?
The standard configuration is 3PH-380V/50hz as usual, others available. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by ShenChuangYi Refrigeration Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full ShenChuangYi Refrigeration Co., Ltd. range on HVACR Nexus.
