Cooled industrial water chiller — 66.8kw, 20.95kw. The complete factory specification follows. Made by ShenChuangYi Refrigeration Co., Ltd. (6 years on the platform, typical reply ≤1h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Cooled Industrial Water Chiller
- Power Consumption: 20.95kw
- Pump Power: 1.5kw
- Voltage: 1/3PH-50/60Hz-208-230V, 380-420V, 440-480V
- Cooling Capacity: 66.8kw
- Refrigerant Type: R134a/R407c/R410a
- Warranty: 1 Year
Technical Specifications
| Type | Water-Cooled |
|---|---|
| Voltage | 1/3PH-50/60Hz-208-230V, 380-420V, 440-480V |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Easy To Operate |
| Core Components | Compressor, Condenser, Evaporater, Expansion valve |
| Place Of Origin | Guangdong, China |
| Brand Name | SCY |
| Dimension(L*W*H) | 1700*800*1480mm |
| Working Temperature Range | 5-35 |
| Product Name | Water-cooled Chiller |
| Refrigerant Type | R134a/R407c/R410a |
| Cooling Capacity | 66.8kw |
| Power Consumption | 20.95kw |
| Running Current | 31.8A |
| Freeze Water Flow | 10.8m3/h |
| Cooling Water Flow | 13.9m3/h |
| Compressor Type | Scroll |
| Pump Power | 1.5kw |
| Condenser Type | Shell and Tube |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
3.Refrigerant: R22, R134a, R407c, R410a
4.Power Supply: 3Φ-50Hz-380V
5.Compressor: Scroll Compressor(20%-30% higher in efficiency)
| Model | SCY-20W | SCY-25W | SCY-30W | SCY-40W | SCY-50W | ||||||
| Power supply | 3Φ-50Hz-380V(208-230V, 380-420V,440-480V,50Hz or 60Hz, 3phase) | ||||||||||
| Cooling capacity | kw | 66.8 | 78.8 | 98.7 | 133.6 | 157.6 | |||||
| TONS | 18.99 | 22.41 | 28.06 | 37.99 | 44.81 | ||||||
| Kcal/h | 57450 | 67800 | 84880 | 114900 | 135700 | ||||||
| Power consumption | kw | 17.2 | 20.2 | 24.5 | 34 | 41.5 | |||||
| Running current | A | 33.2 | 38.9 | 47.3 | 65.6 | 80 | |||||
| Freeze water flow | m³/h | 11.1 | 13.2 | 16.7 | 22.2 | 26.4 | |||||
| Cooling water flow | m³/h | 13.3 | 15.8 | 20 | 26.6 | 31.6 | |||||
| Compressor | Type | Scroll/piston | |||||||||
| Input power(kw) | 15 | 18 | 22.5 | 30 | 37.5 | ||||||
| Pump | Power(kw) | 2.2 | 2.2 | 2.2 | 4 | 4 | |||||
| Refrigerant | Type | R22, R134a, R407c, R410a | |||||||||
| Control method | External balanced thermostatic expansion valve | ||||||||||
| Filling volume(kg) | 11 | 13 | 16 | 22 | 26 | ||||||
| Evaporator | Type | Shell and tube, Plate, Coil in Tank | |||||||||
| Pipe diameter(in) | 2" | 2-1/2" | 3" | ||||||||
| Condenser | Type | Shell and tube | |||||||||
| Pipe diameter(in) | 2" | 2-1/2" | 3" | ||||||||
| Safty protector | Dual pressure switch, frost-proof protection, soluble pin/safety valve, overload protective device, coil over-heating protection system, temperature automatic protection switch. | ||||||||||
| Dimension | Length(mm) | 1700 | 1700 | 2100 | 2100 | 2100 | |||||
| Width(mm) | 800 | 900 | 900 | 1100 | 1100 | ||||||
| Heiht(mm) | 1500 | 1500 | 1380 | 1430 | 1430 | ||||||
| Weight(kg) | 630 | 680 | 850 | 900 | 1050 | ||||||
| Remarks | 1.Testing results under above conditions: Inlet/outlet chilled water temperatuer 12℃/7℃, inlet/outlet cooling water temperature 30℃/35℃. | ||||||||||
| 2.The above parameters will be updated continuously. If you need a custom service, please send your technical requirements before placing an order. | |||||||||||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $1620 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cooled industrial water chiller?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the cooled industrial water chiller be supplied for my local voltage?
The standard configuration is 1/3PH-50/60Hz-208-230V, 380-420V, 440-480V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
