Key specification for this centrifugal fan: voltage 48VDC, 24VDC, 12VDC, material Stainless Steel, Plastic. Everything below is reproduced from the factory data sheet. Made by Ningbo Wonsmart Motor Fan Co., Ltd. (17 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Centrifugal Fan
- Voltage: 48VDC, 24VDC, 12VDC
- Rated Voltage: 12VDC/24VDC/48VDC
- Material: Stainless Steel, Plastic
- Blade Material: Plastic
- Noise Level: 83dba
- Speed: 55m3/h, 32cfm
Technical Specifications
| Duct Diameter | 200MM |
|---|---|
| Mounting | Other |
| Voltage | 48VDC, 24VDC, 12VDC |
| Speed | 55m3/h, 32cfm |
| Material | Stainless Steel, Plastic |
| Blade Material | Plastic |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Noise Level | 83dba |
| Place Of Origin | Zhejiang, China |
| Brand Name | WONSMART |
| Model Number | WS9290B-48-240-X200&WS4807DY02V04-SRP008, WS9290B-24-220-X200&WS2408DY01V01-SRP008, WS9290B-12-220-S200&WS1230DY04V01-SRP004 |
| Bearing | NMB ball bearing |
| Driver | External driver |
| Item Name | WS9290B |
| Rated Voltage | 12VDC/24VDC/48VDC |
| Keyword | dc cooling fan dc centrifugal fan blower fan |
| Application | cooling fan |
| Feature | High Performance |
| Weight | 500g |
| Certification | ISO 9001,etl,reach,rohs |
| Selling Units | Single item |
| Single Package Size | 20X22X18 cm |
| Single Gross Weight | 2.0 kg |
Product Details
Product Description
Part Name | 12/24/48 volt dc cooling fan dc centrifugal fan blower fan |
Part No | WS9290B |
Rated votlage | 12VDC/24VDC/48VDC |
Life time(MTTF) | >20,000hours |
Unit weight | 0.5kgs |
Bearing | NMB ball bearing |
Unit size | D90*L114mm |
Insulation class | Class F |
Driver board | External |
Speed control | PWM or 0~5V |
Wiring diagram for driver controller
We can supply standard drivers for this blower. If you want to design your own driver, you can refer to the wiring diagram on the left picture.
We can supply standard drivers for this blower. If you want to design your own driver, you can refer to the wiring diagram on the left picture.
Specification
P-Q Curve for 12V dc brushless small industrial air blower machine.
WS9290B-12-220-X200 blower fan airflow against air pressure performance curve as
left chart
Model:WS9290B-12-220-S200 | ||||||
Air pressure(Kpa) | Air flow(m3/h) | Speed (r/min) | Power （W） | |||
0 | 50.0 | 22,000 | 180.0 | |||
7.0(working point) | 40.0 | 24,000 | 150.0 | |||
10.5 | 0 | 25,000 | 252.0 | |||
P-Q Curve for 24V dc brushless small industrial air blower machine.
WS9290B-48-240-X200 blower fan airflow against air pressure performance curve as
left chart
Model:WS9290B-24-220-X300 | ||||||
Air pressure(Kpa) | Air flow(m3/h) | Speed (r/min) | Power （W） | |||
0 | 47.0 | 22,500 | 187.2 | |||
8.0(working point) | 25.0 | 25,500 | 184.8 | |||
12.5 | 0 | 28,500 | 124.8 | |||
P-Q Curve for 48V dc brushless small industrial air blower machine.
WS9290B-48-240-X200 blower fan airflow against air pressure performance curve as
left chart
Model:WS9290B-48-240-X200 | ||||||
Air pressure(Kpa) | Air flow(m3/h) | Speed (r/min) | Power （W） | |||
0 | 55.0 | 26,000 | 264.0 | |||
9.0(working point) | 28.0 | 27,000 | 230.4 | |||
14.0 | 0 | 30,000 | 139.2 | |||
Drawing
Product Size Information as below:
Packing & Delivery
Qty per Ctn: 20pc Ctn size:500*400*140mm;
G.W.: 11.2KGS N.W.:9.8KGS
G.W.: 11.2KGS N.W.:9.8KGS
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Company Introduction
of 30 kpa. With our high quality parts and precise manufacturing process, WONSMART motors and blowers can
serve more than 20,000 hours.
Founded in 2009, Wonsmart has had a rapid growth rate of 30 % yearly and our products are widely used in Air cushion machines,Environment condition analyzers, Medical and other revolutionary Industrial equipment.
Wonsmart production and inspection equipment include auto winding machines, balancing machines, and CNC machines. We also have airflow and pressure testing equipment and motor performance testing equipment. All products are 100% inspected before delivery to guarantee all the products arrive at the customers with satisfied quality.
Wonsmart is I S O 9 0 0 1 certificated and we have paid attention to product quality and customer service. Our professional and spry team hold the same goal of being one of the best brushless motor and blower supplier.
With ETL,CE, ROHS, REACH certification, 60% of Wonsmart’s products are exported to North America, EU, Japan
Founded in 2009, Wonsmart has had a rapid growth rate of 30 % yearly and our products are widely used in Air cushion machines,Environment condition analyzers, Medical and other revolutionary Industrial equipment.
Wonsmart production and inspection equipment include auto winding machines, balancing machines, and CNC machines. We also have airflow and pressure testing equipment and motor performance testing equipment. All products are 100% inspected before delivery to guarantee all the products arrive at the customers with satisfied quality.
Wonsmart is I S O 9 0 0 1 certificated and we have paid attention to product quality and customer service. Our professional and spry team hold the same goal of being one of the best brushless motor and blower supplier.
With ETL,CE, ROHS, REACH certification, 60% of Wonsmart’s products are exported to North America, EU, Japan
and Korea. Customers from these countries are very satisfied with Wonsmart’s stable quality, fast delivery and reasonable price.
We also accept ODM and OEM projects and customized specification.
Please feel free to contact us.
We also accept ODM and OEM projects and customized specification.
Please feel free to contact us.
Our Services & Strength
We also accept ODM and OEM projects and customized specification.
We also accept ODM and OEM projects and customized specification.
FAQ
Are you factory or trading company?
We are factory with 4,000 square meters and we have been focus on high pressure
We are factory with 4,000 square meters and we have been focus on high pressure
BLDC blowers for more than 10 years
Can you design a new blower fan if we give you target performance?
Yes, we offer ODM service for both blower fan and controller board
Can we connect this centrifugal air blower directly onto power source?
Can you design a new blower fan if we give you target performance?
Yes, we offer ODM service for both blower fan and controller board
Can we connect this centrifugal air blower directly onto power source?
This blower fan is with BLDC motor inside and it needs a controller board to run.
What kind of power source shall we use to drive this blower fan?
Generally, our customers use 24vdc switching power supply or Li-on battery.
Do you also sell controller board for this blower fan?
Yes, we can supply adapted controller board for this blower fan.
How to change impeller speed if we use your controller board?
You can use 0~5v or PWM to change speed. Our standard controller board is also with
What kind of power source shall we use to drive this blower fan?
Generally, our customers use 24vdc switching power supply or Li-on battery.
Do you also sell controller board for this blower fan?
Yes, we can supply adapted controller board for this blower fan.
How to change impeller speed if we use your controller board?
You can use 0~5v or PWM to change speed. Our standard controller board is also with
a potentiometer to change speed conveniently.
What is the MTTF of this centrifugal air blower?
MTTF of this centrifugal air blower is 20,000+ hours under 25 C degree.
Can we use this centrifugal air blower to suct water?
This blower fan can not be used to suck water. If you need to suck water, you can ask us to
choose proper item for this special working condition.
Can we use this centrifugal air blower to suck dust directly?
This blower fan can not be used to suck dust directly.If you need to suck dust, you can ask
us to choose proper item for this special working condition.
What can do if the working condition is dirty?
A filter is strongly recommended to assemble onto the the inlet of the blower fan
How to decrease the noise of the blower?
Many of our customers use foam, silicone to fill between blower fan and machine to insulate
the blower noise.
What is the MTTF of this centrifugal air blower?
MTTF of this centrifugal air blower is 20,000+ hours under 25 C degree.
Can we use this centrifugal air blower to suct water?
This blower fan can not be used to suck water. If you need to suck water, you can ask us to
choose proper item for this special working condition.
Can we use this centrifugal air blower to suck dust directly?
This blower fan can not be used to suck dust directly.If you need to suck dust, you can ask
us to choose proper item for this special working condition.
What can do if the working condition is dirty?
A filter is strongly recommended to assemble onto the the inlet of the blower fan
How to decrease the noise of the blower?
Many of our customers use foam, silicone to fill between blower fan and machine to insulate
the blower noise.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this centrifugal fan carry?
It is supplied with ISO 9001,etl,reach,rohs documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the centrifugal fan be supplied for my local voltage?
The standard configuration is 48VDC, 24VDC, 12VDC. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
