The air curtain listed here carries 220V, material Metal, documented exactly as the manufacturer publishes it. Made by Dongying Qinghua Trading Co., Ltd. (9 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Air Curtain
- Voltage: 220V
- Material: Metal
- Fan Speed: 3-speed
- Warranty: 3 Years
- Place Of Origin: Shandong, China
- Application Area: Super market, warehouse, greenhouse
Technical Specifications
| Type | Air Curtain |
|---|---|
| Mounting Type | Ceiling Mount |
| Key Selling Points | Long Service Life |
| Warranty | 3 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor, FAN |
| Place Of Origin | Shandong, China |
| Weight (Kg) | 20 KG |
| Brand Name | Wecoolest |
| After-Sales Service Provided | Free spare parts |
| Product Name | air curtain |
| Application Area | Super market, warehouse, greenhouse |
| Function | Fresh Keeping |
| Door Height | 3m-5m |
| Noise | 35-60 dB(A) |
| Material | Metal |
| Voltage | 220V |
| Keyword | Air curtain |
| Fan Speed | 3-speed |
| Selling Units | Single item |
| Single Package Size | 100X25X25 cm |
| Single Gross Weight | 15.000 kg |
Product Details
popular air condition cooling air curtain
The main function of the air curtain machine is to isolate the air inside and outside the building, to ensure the internal temperature of the building and prevent external bacteria from entering the interior of the building.
Optimize energy saving motor
Optimize energy saving motors,upgrade strong power, the motor is runing smoothly, Built in thermal protector, safe and reliable performance, safe and reliable continuous transport line 5000hours, is the leader in the motor.
Ultra low noise air evenly
The overall design of high quality glass fiber plastic impeller, the smooth flow speed, unequal spacing mute design.
Twin turbine air supply more powerful
Inside the fan spiral vortex duct design, can effectivrly reduce the air flow loss, while reducing the internal resistance noise.
| Model | Voltage V | Motor Power w | Wind speed m/s | Air volume m3/min | noise dB(A) | Heater power kw | Air outlet temperature rise ℃ | wire(mm2) | Dimensions L * W * H mm | |||
| Simplex | Three phase | |||||||||||
| RFM/P 125-600 | 220/380 50Hz | 60 | 4.5 | 700/600 | 59 | 3 | 6 | 40-80 | 2.5-4 | 1.5-2.5 | 600 ×180×220 | |
| RFM/P 125-900 | 80 | 4.5 | 1100/980 | 59 | 5 | 8 | 40-80 | 2.5-4 | 1.5-2.5 | 900 ×180x 220 | ||
| RFM/P 125-1200 | 120 | 4.5 | 1400/1260 | 59 | 6 | 9 | 40-80 | 4-6 | 2.5-4 | 1200×180×220 | ||
| RFM/P 125-1500 | 180 | 4.5 | 1800/1600 | 59 | 9 | 12 | 40-80 | 6-10 | 4-6 | 1500 ×180x 220 | ||
| RFM/P 125-1800 | 250 | 4.5 | 2200/2000 | 59 | 12 | 18 | 40-80 | 10-16 | 6-10 | 1800×80×220 | ||
| RFM/P 150-600 | 80 | 6 | 1000/900 | 65 | 3 | 6 | 40-80 | 2.5-4 | 1.5-2.5 | 600 x 230x 260 | ||
| RFM/P 150-900 | 120 | 6 | 1500/1200 | 65 | 5 | 8 | 10 | 38-70 | 2.5-4 | 1.5-2.5 | 900 ×230×260 | |
| RFM/P 150-1200 | 180 | 6 | 2200/2000 | 65 | 6 | 9 | 12 | 38-70 | 4-6 | 2.5-4 | 1200x 230×260 | |
| RFM/P 150-1500 | 250 | 4.5 | 3000/2600 | 65 | 9 | 12 | 16 | 38-70 | 6-10 | 4-6 | 1500 x 230x 260 | |
| RFM/P 150-1800 | 370 | 9 | 3500/3200 | 65 | 12 | 18 | 24 | 38-70 | 10-16 | 6-10 | 1800x 230x 260 | |
| RFM/P 180-900 | 250 | 9 | 2000/800 | 71 | 8 | 10 | 35-65 | 4-6 | 2.5-4 | 900 ×260x 290 | ||
| RFM/P 180-1200 | 370 | 9 | 3000/2700 | 71 | 9 | 12 | 35-65 | 6-10 | 4-6 | 1200×260 ×290 | ||
| RFM/P 180-1500 | 550 | 9.0 | 4000/3600 | 71 | 12 | 18 | 35-65 | 10-16 | 6-10 | 1500 x 260 x 290 | ||
| RFM/P 180-1800 | 650 | 9 | 4500/4100 | 71 | 18 | 24 | 35-65 | 16-25 | 10-16 | 1800x 260 x 290 | ||
Delivery
TIME OF DELIVERY:Within 35 days after receiving deposit .
Payment
Support T/T , L/C,Aalibaba
Warranty
The whole machine for 3 years.
After-sale
During the warranty period, machines which cannot run due to quality problems,Choose the following options.
1) During the one-year warranty period, non-human factors cause product quality problems, and provide parts replacement and repair and maintenance services.
2) In addition to the one-year warranty period, parts replacement and repair and maintenance services are provided at the user's expense.
Promotion Method
1) Pay the full amount in one lump sum, 1% discount.
2) Recommend other customers to buy and return a part of the commission.
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $55 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air curtain?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the air curtain be supplied for my local voltage?
The standard configuration is 220V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Dongying Qinghua Trading Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Dongying Qinghua Trading Co., Ltd. range on HVACR Nexus.
