This air handling unit is published with the manufacturer’s full specification — 380 V, blade material Aluminum. Made by Seemtek Fan (Suzhou) Co., Ltd. (3 years on the platform, typical reply ≤7h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Air Handling Unit
- Model Number: B3E-3A630-Y8-06, B3E-3A630-Y8-07, K3E-3A630-Y8-18
- Voltage: 380 V
- Blade Material: Aluminum
- Speed: 1260rpm, 1380rpm, 1770rpm
- Speed Control: 0-10VDC
- Warranty: 2 Years
Technical Specifications
| Mounting | Any |
|---|---|
| Voltage | 380 V |
| Speed | 1260rpm, 1380rpm, 1770rpm |
| Blade Material | Aluminum |
| Warranty | 2 Years |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM, ODM |
| Place Of Origin | Jiangsu, China |
| Brand Name | Seemtek |
| Model Number | B3E-3A630-Y8-06, B3E-3A630-Y8-07, K3E-3A630-Y8-18 |
| Product Type | Centrifugal Fan with Bracket |
| Speed Control | 0-10VDC |
| Fan Pressure | High Pressure Fan |
| Motor Type | EC External Rotor Motor |
| Type | Centrifugal Fan |
| Core Components | motor, Bearing, Impeller,Control system |
| Applicable Industries | Cooling&Heating,Refrigeration industry,AHU Equipment,Purifier,Heat Recovery Unit,Fan Wall,Charging Pile,Industrial Air Conditioner,Energy Storage Cabinet,Precision Air Conditioner |
| Selling Units | Single item |
Product Details
Voltage Type | AC |
Motor Type | EC Brushless External Rotor Motor |
Impeller Diameter | 630mm |
Impeller Material | Aluminum |
Direction of Rotation | Clockwise, seen on rotor |
Speed Control | 0-10VDC |
Type of Protection | IP54 |
Bearing | Maintenance-free ball bearings |
Frequency | 50/60Hz |
Insulation Class | F |
Operation Temperature | – 25 ºC ~ +60 ºC |
Motor Protection | Locked-Rotor Protection, Reverse Polarity Protection, Thermal Protection, Soft Start |
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–99 piece: US $661.2 / piece
- 100–499 piece: US $585.1 / piece
- 500+ piece: US $540.1 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air handling unit?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the air handling unit be supplied for my local voltage?
The standard configuration is 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Seemtek Fan (Suzhou) Co., Ltd., based in China. The company 3 years as a verified Alibaba.com supplier, Trading Company. Browse the full Seemtek Fan (Suzhou) Co., Ltd. range on HVACR Nexus.
