The blast freezer listed here carries 380v/50hz/3ph, 20HP/25HP/30HP, documented exactly as the manufacturer publishes it. Made by Shengzhou Lanco Refrigeration Equipment Co., Ltd. (10 years on the platform, typical reply ≤4h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Blast Freezer
- Voltage: 380v/50hz/3ph
- Cooling Capacity: 20HP/25HP/30HP
- Tube Material: Inner grooved copper tube
- Fin Material: Aluminium
- Refrigerant: R404A,R449a,R507a,R134a
- Warranty: 1 Year
Technical Specifications
| Application | Refrigeration Parts |
|---|---|
| Type | Refrigeration Compressor |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Weight (Kg) | 260 |
| Place Of Origin | Zhejiang, China |
| Brand Name | COOL TEMP |
| Name | Copper Tube Aluminium Fin Evaporator For Blast Freezer Cold Storage |
| Size | Big Evaporator |
| Cooling Capacity | 20HP/25HP/30HP |
| Tube Material | Inner grooved copper tube |
| Fin Material | Aluminium |
| Fans | Axial Fan |
| Voltage | 380v/50hz/3ph |
| Temperature | Middle & Low temperature |
| Refrigerant | R404A,R449a,R507a,R134a |
| Condition | New |
| Applicable Industries | hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company |
| Showroom Location | None |
| Selling Units | Single item |
| Single Package Size | XX cm |
Product Details
| Ceiling Type Fast Frozen Unit Coolers Fan:Φ630mm Fin Space:9.0mm/18mm Inner-charge | |||||||||||||||||||
| Model | SC4 Capacity(KW) | SC5 Capacity(KW) | Tube length | Surface | Circuit Vol. | Fan | Heater | InTube (inch) | OutTube (inch) | Net Weight (KG) | Electrical Defrost Drawing no. | Water Defrost Drawing no. | |||||||
| Airinlet Ta-25℃ Evaporation Te -31℃ | Airinlet Ta -34℃ Evaporation Te-40℃ | ||||||||||||||||||
| R22 | R404A | R22 | R404A | m | m2 | dm3 | Fan Mot no. | Air Flow (m3/h) | Air Throw (m) | Fan Mot Amper (A) | Fan Mot Power (W) | Electric Defrost (A) | Electric Defrost (W) | ||||||
| LK6T632 | 18.0 | 17.6 | 14.8 | 14.7 | 288 | 76 | 39.0 | 630*2 | 26600 | 31 | 6.4 | 3200 | 18.9Δ | 10800 | 7/8 | 1-5/8 | 280 | LK16 | LK22 |
| LK8T632 | 21.7 | 21.4 | 17.9 | 17.9 | 384 | 102 | 53.0 | 630*2 | 24200 | 29 | 6.4 | 3200 | 28.4Δ | 16200 | 1-1/8 | 2-1/8 | 310 | LK16 | LK22 |
| LK6T633 | 27.5 | 27.2 | 22.5 | 22.5 | 432 | 114 | 59.0 | 630*3 | 29900 | 32 | 9.6 | 4800 | 28.4Δ | 16200 | 1-1/8 | 2-1/8 | 380 | LK17 | LK23 |
| LK8T633 | 32.7 | 32.5 | 27.1 | 27.1 | 576 | 153 | 79.0 | 630*3 | 36300 | 30 | 9.6 | 4800 | 42.6Δ | 24300 | 1-3/8 | 2-1/8 | 420 | LK17 | LK23 |
| LK8T634 | 37.9 | 37.5 | 30.6 | 30.6 | 691 | 183 | 95.0 | 630*4 | 44800 | 31 | 12.8 | 6400 | 51.3Δ | 29250 | 1-3/8 | 2-1/8 | 510 | LK18 | LK24 |
| Defrost electric heating pipe connection:Δ triangle connection . | |||||||||||||||||||
| Floor Type Fast Frozen Unit Coolers Fan:Φ630mm Fin Space:9.0mm/18mm Inner-charge | |||||||||||||||||||
| Model | SC4 Capacity (KW) | SC5 Capacity(KW) | Tube length | Surface | Circuit Vol. | Fan | Heater | InTube (inch) | OutTube (inch) | Net Weight (KG) | Electrical Defrost Drawing no. | Water Defrost Drawing no. | |||||||
| Airinlet Ta-25℃ Evaporation Te -31℃ | Airinlet Ta -34℃ Evaporation Te-40℃ | ||||||||||||||||||
| R22 | R404A | R22 | R404A | m | m2 | dm3 | Fan Mot no. | Air Flow (m3/h) | Air Throw (m) | Fan Mot Amper (A) | Fan Mot Power (W) | Electric Defrost (A) | Electric Defrost (W) | ||||||
| LKY6T634 | 36.0 | 35.2 | 29.6 | 29.4 | 576 | 152 | 79.0 | 630*4 | 53200 | 31 | 12.8 | 6400 | 37.9Δ | 21600 | 2*7/8 | 2*1-5/8 | 560 | LK25 | LK27 |
| LKY8T634 | 43.4 | 42.8 | 36.4 | 35.8 | 768 | 204 | 105.0 | 630*4 | 48400 | 29 | 12.8 | 6400 | 56.8Δ | 32400 | 2*1-1/8 | 2*2-1/8 | 620 | LK25 | LK27 |
| LKY6T636 | 55.0 | 54.4 | 45.6 | 45.0 | 864 | 228 | 118.0 | 630*6 | 79800 | 32 | 19.2 | 9600 | 56.8Δ | 32400 | 2*1-1/8 | 2*2-1/8 | 760 | LK26 | LK28 |
| LKY8T636 | 65.4 | 65.0 | 55.4 | 54.2 | 1152 | 306 | 158.0 | 630*6 | 72600 | 30 | 19.2 | 9600 | 85.3Δ | 48600 | 2*1-3/8 | 2*2-1/8 | 840 | LK26 | LK28 |
| Defrost electric heating pipe connection:Δ triangle connection /star connection Y,Y must be connected to the neutralline. | |||||||||||||||||||
Why We Say We Should Be Your Preferred Supplier ?
Service:
We put our Customer first no matter Big or Small,Your Business is most important
to us We are here to support you.
Technology
With the support of a Competent R & D team giving strong technical support
to help you make your job more easy.
Factory Equipment
We have a fully fitted factory for sheet metal processing offering a range of
materials to suit what the Customer demands are;
Coil heat exchanges manufacturing offering range fin profiles and material
required from bare type to hydrophilic fin coil(blue fin) where corrosion control
is required;
Inner grooved copper tube and smooth copper tube optional ; Vertical Tube
Expander Machine and Tunnel Dryer Machine to get efficient and make sure
our high quality products; Fully painting service either our standard choice
Blue ,Green,Black,White or Customized to your Choice.
Sales Marketing
Are Customer Focused Solve Purpose of bringing you an easy pleasant
company to deal with.
Factory Location Advantage
We are closed to Shanghai, Ningbo,Hangzhou,Yiwu etc City ,it takes around
1.5-3 hours to our factory from one of those cities by car, and it takes 2 hours
from Guangzhou/Shenzhen to our airport(Hangzhou xiaoshan airport),Warmly
welcome to visit Us When you are available,thank you !
Ordering and Pricing
- Minimum order quantity: 1 piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this blast freezer?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the blast freezer be supplied for my local voltage?
The standard configuration is 380v/50hz/3ph. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shengzhou Lanco Refrigeration Equipment Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, Trading Company. Browse the full Shengzhou Lanco Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
