The cnc vacuum air blower listed here carries rated voltage 200-720V, power source Electric, documented exactly as the manufacturer publishes it. Made by Wuxi Gezhiling Mechanical & Electrical Co., Ltd. (15 years on the platform, typical reply ≤17h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Cnc Vacuum Air Blower
- Model Number: RB
- Power Source: Electric
- Rated Voltage: 200-720V
- Blade Material: Aluminium Alloy
- Material: die-casting Aluminum Alloy
- Warranty: 1 year
Technical Specifications
| Application | Industrial Blower |
|---|---|
| Power Source | Electric |
| Rated Voltage | 200-720V |
| Electric Current Type | AC |
| Blade Material | Aluminium Alloy |
| Pressure | High Pressure |
| Warranty | 1 year |
| Customized Support | OEM, ODM |
| Place Of Origin | Jiangsu, China |
| Brand Name | GZLing |
| Model Number | RB |
| Color | Silver |
| Frequency | 50HZ and 60 Hz air blower |
| Cooling Method | Air Cooling |
| Material | die-casting Aluminum Alloy |
| Product Name | 7.5kw CNC vacuum air blower |
| Freight | call us for details |
| Selling Units | Single item |
| Single Package Size | 55X53X57 cm |
| Single Gross Weight | 85.000 kg |
Product Details
Specification:
- Product name: 7.5kw CNC vacuum air blower
- IP55 Insulation class F
- Bearing continuously works 130000 hours without maintance18-moth warranty
- Famous Brand (OEM Allowed)
- Certificates:CE,RoHS,CCC
- German technology
- EX-stock
1.Parameters: for 5.5kw CNC table vacuum air blower
| Item NO. | Stage (S/D/3) | Frequency (HZ) | Power (KW) | Voltage (V) | Current (A) | Air Flow (m³/h) | Vacuum (mbar) | Pressure (mbar) | Sound dB(A) | Weight (KG) |
| XGB-7500 | Single | 50 | 7.5 | 345-415/ 600-720Y | 14.3/8.26Y | 530 | -300 | 280 | 80 | 68 |
| 60 | 8.6 | 380-480/ 660-720Y | 16.7/9.24Y | 620 | -320 | 430 | 82 |
2.Performance curves:
3.Size:
4.Explosive view:
5.Feature:
- Beautiful surface,Easy installation,Low noise level
- No vibration, and therefore complete dynamic stability
- Pulsation-free discharge,free maintenance
- Higher pressure ratio,100% oil free
- High temperature-resistant bearings with longer grease life
- Suitable for environmental protection
- Wide frequency motor with IP55,CALSS H
- Passed ISO,CE,CCC,UL ROHS test
- Air capacity:from 40m3/h to 2500m3/h
- Pressure:from 60mbar to 780mbar
6.Application:
- Pneumatic conveying systems
- Lifting and holding of parts by vacuum
- Packing machines
- Aeration of sewage-treatment plants
- Filling of bags/bottles/hoppers
- Soil remediation
- Thermoforming
- Sorting/enveloping of letters
- Food-processing
- Laser printers
- Dental suction equipment
- Paper processing
- Printers/copiers
- Textile machines
- Aeration of fish ponds
- Gas analysis
- Swimming pool equipment/whirlpools
7.Installation connection:
9.Certificate:
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $550 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cnc vacuum air blower?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 year warranty. Spare parts and technical support remain available after the warranty period.
Can the cnc vacuum air blower be supplied for my local voltage?
The standard configuration is 200-720V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Wuxi Gezhiling Mechanical & Electrical Co., Ltd., based in China. The company 15 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Wuxi Gezhiling Mechanical & Electrical Co., Ltd. range on HVACR Nexus.
