Cooled screw water chiller — voltage 3PH-380V-50HZ, 207KW; 60 cooling ton. The complete factory specification follows. Made by Shenzhen Hero-Tech Refrigeration Equipment Co., Ltd. (10 years on the platform, typical reply ≤4h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Cooled Screw Water Chiller
- Power Consumption: 38KW
- Voltage: 3PH-380V-50HZ
- Cooling Capacity: 207KW; 60 cooling ton
- Refrigerant: R22/R407C/R134A
- Warranty: 1 Year
- Place Of Origin: China
Technical Specifications
| Type | Air-cooled |
|---|---|
| Voltage | 3PH-380V-50HZ |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Long Service Life |
| Core Components | PLC, Motor, compressor |
| Place Of Origin | China |
| Brand Name | HERO-TECH |
| Dimension(L*W*H) | 2550*780*1650 mm |
| Working Temperature Range | 7-35 celsius degree |
| Cooling Capacity | 207KW; 60 cooling ton |
| Power Consumption | 38KW |
| Heat Dissipation | by Cooling tower |
| Chilled Water Flow | 26.1 m³/h |
| Refrigerant | R22/R407C/R134A |
| Compressor Type | Hanbell/Bitzer semi-hermetic screw |
| Evaporator Type | Shell and tube / SS plates type |
| Pipe Size | 3 inch |
| Protective Device | 13+ Monitoring and protection devices |
| After-Sales Service Provided | Detailed SOP + Video guidance |
| Packaging Details | PE foam + Plywood case |
| Port Of Dispatch | shenzhen |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
| Supply Ability | 300 sets per Month |
Product Details
Model | HTS-50W | HTI-1A | |
Nominal cooling capacity | 207KW | 3.3KW | |
Input power | 38KW | 1.4KW | |
Refrigerant | R22 / R407C / R134A | ||
Compressor | Bitzer/Hanbell Semi-hermetic screw | ||
Condenser | Shell and tube | ||
Evaporator | Plate heat exchanger / shell and tube | ||
Chilled water flow | 26.1 m³/h | 0.5 m³/h | |
Cooling water flow | 32.3 m³/h | ||
Pipe connection | 3 inch | ||
Control system | Germany Siemens PLC controller | ||
Dimensions | 2550 * 780 * 1650 mm | ||
Weight | 1050 KG | 60 KG | |
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $13700 / set
- 10+ set: US $13300 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cooled screw water chiller?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the cooled screw water chiller be supplied for my local voltage?
The standard configuration is 3PH-380V-50HZ. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Hero-Tech Refrigeration Equipment Co., Ltd., based in China. The company 10 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Shenzhen Hero-Tech Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
