Key specification for this cross flow fan: material Metal, type Gear Motor. Everything below is reproduced from the factory data sheet. Made by Xian Huan-Tai Technology & Development Corp., Ltd. (7 years on the platform, typical reply ≤7h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Cross Flow Fan
- Model Number: HT-M-168
- AC Voltage: 230v
- Material: Metal
- Rated Speed: 2800-3500RPM
- Warranty: 3 months ~ 1 year
- Certification: CCC, CE,RoHS,UL,REACH, ISO9001:2015
Technical Specifications
| Phase | Single-Phase |
|---|---|
| AC Voltage | 230v |
| Type | Gear Motor |
| Protect Feature | Explosion-proof |
| Efficiency | IE 1,IE 2,IE 3,IE 4 |
| Warranty | 3 months ~ 1 year |
| Model Number | HT-M-168 |
| Brand Name | TOPPING |
| Place Of Origin | Shaanxi, China |
| Frequency | 50Hz |
| Application | Massager/Oven /Ventilator /Hair drier |
| Keywords | shaded pole motor |
| Color | Silver gray |
| Material | Metal |
| Motor Lamination Dimension | 61*61mm |
| Rated Speed | 2800-3500RPM |
| Current | 0.35-0.85Amp |
| Certification | CCC, CE,RoHS,UL,REACH, ISO9001:2015 |
| Selling Units | Single item |
| Single Package Size | 20X20X20 cm |
| Single Gross Weight | 0.300 kg |
Product Details
item | value |
Warranty | 3months-1year |
Place of Origin | China |
Shaanxi | |
Brand Name | TOPPING |
Model Number | HT-M-168 |
Type | GEAR MOTOR |
Frequency | 50Hz |
Phase | Single-phase |
Protect Feature | Explosion-proof |
AC Voltage | 230v |
Efficiency | IE 1,IE 2,IE 3,IE 4 |
Application | Massager/Oven /Ventilator /Hair drier |
Keywords | shaded pole motor |
Color | Silver gray |
Material | Metal |
Type | Household Applicance,Exhaust Fan |
motor Lamination Dimension | 61*61mm |
Rated Speed | 2800-3500RPM |
Current | 0.35-0.85Amp |
Certification | CCC, CE,RoHS,UL,REACH, ISO9001:2015 |
We are based in Shaanxi, China, start from 1996,sell to North America(65.00%),Western Europe(25.00%),Mid East(10.00%),Eastern Europe(5.00%),Africa(5.00%),Oceania(5.00%). There are total about 201-300 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Motor,Dc motor,AC motor,other motor
4. why should you buy from us not from other suppliers?
Quality Assurance Diversified Product Lines Design Capability Excellent Customer Service
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,FCA,CPT,DDP,DDU,Express Delivery,DAF；
Accepted Payment Currency:USD,EUR,GBP;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Spanish,Russian
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100–999 piece: US $10 / piece
- 1000–9999 piece: US $4 / piece
- 10000+ piece: US $2.5 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cross flow fan?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 months ~ 1 year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this cross flow fan carry?
It is supplied with CCC, CE,RoHS,UL,REACH, ISO9001:2015 documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the cross flow fan be supplied for my local voltage?
The standard configuration is 230v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Xian Huan-Tai Technology & Development Corp., Ltd., based in China. The company 7 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Xian Huan-Tai Technology & Development Corp., Ltd. range on HVACR Nexus.
