The fan listed here carries voltage single phase, refrigerant R404a, documented exactly as the manufacturer publishes it. Made by Taizhou Nanfeng Cold-Chain Co., Ltd. (18 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Fan
- Voltage: single phase
- Refrigerant: R404a
- Warranty: 1 Year
- Place Of Origin: Jiangsu, China
- Marketing Type: Ordinary Product
- Single Package Size: 100X100X100 cm
Technical Specifications
| Core Components | Motor |
|---|---|
| Machinery Test Report | Provided |
| Warranty | 1 Year |
| Video Outgoing-Inspection | Provided |
| Weight (Kg) | 100 |
| Place Of Origin | Jiangsu, China |
| Brand Name | PSRE |
| Product Name | AC fan air cooler and evaporator |
| Refrigerant | R404a |
| Voltage | single phase |
| Color | White |
| Fin Space | 3.5mm |
| Marketing Type | Ordinary Product |
| Selling Units | Single item |
| Single Package Size | 100X100X100 cm |
| Single Gross Weight | 100.0 kg |
Product Details
NF30系列吊顶式商用冷风机主要技术参数 库温≥-2℃ 片距3.5mm 冷媒 R404A NF30 Series air cooler Room temp.≥-2℃ Fin spacing 3.5mm R404A 主要性能 Main performance | ||||||||||
Model | Capacity(W) | Surface | Tube volume | defrost Heater(240V/50Hz) | ||||||
Tc0℃/7KTD | m2 | dm3 | Coil | Drain Pan | ||||||
NF5.6/301-3.5 | 1500 | 5.6 | 1.24 | 320W*2 | 420W | |||||
NF7.5/301-3.5 | 2000 | 7.5 | 1.66 | 320W*2 | 420W | |||||
NF11/301-3.5 | 2800 | 11 | 2.28 | 440W*2 | 550W | |||||
NF14/302-3.5 | 3600 | 14 | 2.83 | 760W*2 | 850W | |||||
NF18/302-3.5 | 4600 | 18 | 3.7 | 760W*2 | 850W | |||||
NF20/303-3.5 | 5400 | 20 | 4.17 | 1120W*2 | 1250W | |||||
NF26/303-3.5 | 6800 | 26 | 5.36 | 1120W*2 | 1250W | |||||
NF28/304-3.5 | 7800 | 28 | 5.52 | 1500W*2 | 1500W | |||||
NF35/304-3.5 | 9000 | 35 | 7.36 | 1500W*2 | 1500W | |||||
Model | Fan motor (220-240V.50/60Hz) | ||||||||
Quantity | Fan Diameter(mm) | Air flow（ｍ3/h) | Air Throw(m) | Input Power(W) | |||||
NF5.6/301-3.5 | 1 | 300 | 1700 | 7 | 90 | ||||
NF7.5/301-3.5 | 1 | 300 | 1700 | 6 | 90 | ||||
NF11/301-3.5 | 1 | 300 | 1700 | 7 | 90 | ||||
NF14/302-3.5 | 2 | 300 | 3400 | 8 | 180 | ||||
NF18/302-3.5 | 2 | 300 | 3400 | 7 | 180 | ||||
NF20/303-3.5 | 3 | 300 | 5100 | 11 | 270 | ||||
NF26/303-3.5 | 3 | 300 | 5100 | 11 | 270 | ||||
NF28/304-3.5 | 4 | 300 | 6800 | 10 | 360 | ||||
NF35/304-3.5 | 4 | 300 | 6800 | 10 | 360 | ||||
型 号 Model | 接口尺寸Connection Dimension(inch) | 外形尺寸External Dimension (mm) | 安装尺寸 Installation Dimension (mm) | 排水口尺寸Water Drain(inch) | ||||||||
进口Inlet | 出口Outlet | L | W | H | A | B | ||||||
NF5.6/301-3.5 | 3/8 | 5/8 | 610 | 360 | 430 | 410 | 295 | 1/2 | ||||
NF7.5/301-3.5 | 3/8 | 5/8 | 610 | 360 | 430 | 410 | 295 | 1/2 | ||||
NF11/301-3.5 | 3/8 | 5/8 | 770 | 360 | 430 | 570 | 295 | 1/2 | ||||
NF14/302-3.5 | 3/8 | 5/8 | 1160 | 360 | 430 | 960 | 295 | 1/2 | ||||
NF18/302-3.5 | 3/8 | 5/8 | 1160 | 360 | 430 | 960 | 295 | 1/2 | ||||
NF20/303-3.5 | 1/2 | 7/8 | 1630 | 360 | 430 | 1430 | 295 | 1/2 | ||||
NF26/303-3.5 | 1/2 | 7/8 | 1630 | 360 | 430 | 1430 | 295 | 1/2 | ||||
NF28/304-3.5 | 1/2 | 7/8 | 2100 | 360 | 430 | 1900 | 295 | 1/2 | ||||
NF35/304-3.5 | 1/2 | 7/8 | 2100 | 360 | 430 | 1900 | 295 | 1/2 | ||||
item | value |
Condition | New |
Applicable Industries | Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Restaurant, Food Shop, Construction works , Food & Beverage Shops, Other |
Weight (KG) | 100 |
Showroom Location | Egypt, United Kingdom, Italy, Australia |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Warranty of core components | 2 years |
Core Components | Motor |
Type | Cooler |
Place of Origin | China |
Brand Name | PSRE |
Warranty | 1 Year |
Product name | AC fan air cooler and evaporator |
Refrigerant | R404a |
Voltage | single phase |
Color | White |
fin space | 3.5mm |
Marketing Type | Ordinary Product |
We are based in Jiangsu, China, start from 1999,sell to Western Europe(45.00%),Oceania(20.00%),Domestic Market(20.00%),Eastern Asia(10.00%),Northern Europe(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Air Cooler, Fan Motor Condensing Unit, Full DC Inverter Condensing Unit, Solar-powered Container-fridge, Open Type Condensing Unit
4. why should you buy from us not from other suppliers?
We use good brand components and we do a good quality. We never supply bad quality products. We have many years experience in this area. Our products all export to Europe ,Austrilia .ect. Our quality accord with the lastest EU standards
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–19 set: US $350 / set
- 20+ set: US $300 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this fan?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the fan be supplied for my local voltage?
The standard configuration is single phase. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Taizhou Nanfeng Cold-Chain Co., Ltd., based in China. The company 18 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Taizhou Nanfeng Cold-Chain Co., Ltd. range on HVACR Nexus.
