Glycol Water Cooling Chiller, 80kW, R410A

The glycol water cooling chiller listed here carries voltage 3PH~220V/380/415V/460V~50HZ/60HZ, power 8.2~79kW, documented exactly as the manufacturer publishes it. Made by Jinan Mgreenbelt Machinery Co., Ltd. (9 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.

Key Features of This Glycol Water Cooling Chiller

• Power: 8.2~79kW
• Power Supply: 208V-480V option
• Voltage: 3PH~220V/380/415V/460V~50HZ/60HZ
• Refrigerant: R-404A, R-410A, R407C
• Warranty: 12 Months
• Place Of Origin: Shandong, China

Technical Specifications

Product Details

Product Description

Water Chiller Manufacturer

Air cooled Water Chiller is a machine that removes heat from a liquid (usually water or glycol mix) via compression.The chilled water is circulated through water cooling pipeline to industrial process machines or process to absorb heat.

Features for Water Chiller

1, Equipped with international brand hermetic scroll compressor, low noise, high efficiency, long life, and low failure rate. 2, Evaporator and condenser made of high efficiency red cooper (anti-corrosion material can also be used), high heat transferring efficiency; 3,Throttle valve and expansion valves are world famous brand, to maximize the cooling ability and ensure high stability; 4, Equipped with imported pumps, good stability of equilibrium, watertight, ensure stable and sustainable flow of chilled water; 5, Equipped with a stainless steel water tank/ shell and tube heat exchanger by different circuits demands. 6,Equipped with a full-featured microcomputer control system, set and adjust temperature (-5 ºC -25 ºC) by itself, easy operation 7, Full-featured microcomputer control system, can directly control (startup, shut down, operate) compressors, pumps and others 8, Equipped with high/low voltage protection, current overload protection to prevent compressor damage or electrical components damage caused by unstable voltage. Equipped with fault code, signal transfer output, when a failure occurs, can judge the failure rapidly and clean the failure, which increase the maintenance speed to a large extent. 9, Reserved pipe connection is easy for installation, Only need to connect the pipe and power supply for machine usage. Equipped with castors for flexible movement and convenient 10,Optional for cryogenic unit, environmentally friendly refrigerant unit

Compressor

Scroll type compressor, super cooling rate

Pump

Inbuilt circulation pump, SS304

Evaporator

Brazed plate heat exchanger, high cooling efficiency

Evaporator

Stainless steel tank coil type evaporator, can connect with milk plate heat exchanger directly.

Evaporator

Closed shell and tube type;

normally connect with buffer tank for big capacity plant

Electric Components

Standard use Schneider electric elements, custom Siemens, ABB; to make safety operations.

Condenser

Finned copper tube, to discharge heat into air through the fans

Axial fans

Axial fans diameter from 350-800mm, work for different air volumes

Controller

microprocessor-based control panel that allows you to set the desired temperature and schedule for the chiller system.

Data Sheet

Model			MG-3C	MG-5C	MG-6C	MG-8C	MG-10C(D)	MG-12C(D)
Cooling capacity in Outlet temp. -5℃	Tons/RT	1.6	2.5	3	4	5.5	6
		Kcal/h	4910	7665	8871	11886	16623	18087
		BTU/h	19453.9	30375.4	35153.6	47099.0	65870.3	71672.4
		kw	5.7	8.9	10.3	13.8	19.3	21
Input power	kW	3.45	5.45	6.31	8.22	10.54	12.33
Outlet water temperature			-5℃ to 30℃
Power supply			3PHASE-220V/380V/415V/460-50HZ/60HZ
Refrigerant	Type	R410A/R407C/R404A
		Control type	Thermostatic expansion valve
Compressor	Type	Hermetic scroll type
		Power(kw)	2.84	4.36	5.2	7	8.8	10.4
Evaporator	Type	SS Tank with coil or Shell and tube or Brazed plate heat exchanger
		Water flow(m³/h)	1.17	1.83	2.12	2.84	3.97	4.32
		Fitting pipe(mm)	DN25	DN25	DN32	DN32	DN32	DN32
Condenser	Type	Finned Copper tube +low noise air fans
		Air flow(m³/h)	3000	5000	6000	8000	10000	12000
Water pump	Type	Centrifugal water pump
		Power(kw)	0.37	0.75	0.75	0.75	0.75	0.75
		Lift(m )	20	20	20	20	20	20
Dimension	L(mm)	1200	1300	1300	1400	1560	1560
		W(mm)	600	650	650	800	850	850
		H(mm)	1100	1200	1200	1400	1500	1500
Net Weight	kg	150	200	230	310	450	500

Model					MG-15C(D)	MG-20C(D)	MG-25C(D)	MG-30C(T)	MG-40C(F)
						15HP	20HP	25HP	30HP	40HP
Cooling capacity	-5℃	Tons	8.08	10.69	12.23	16.15	21.18
				Kcal/h	24461	32385	37037	48923	64168
				kW	28.5	37.6	43	56.8	74.6
				BTU/Hr	96928.33	128327.65	146757.68	193856.66	254266.21
Input power	kW			15.84	20.51	23.52	31.81	40.2
Outlet water temperature					-5℃~30℃
Power supply					3PHASE – 220V/380V/415V/440V/480V-50HZ/60HZ
Refrigerant	Type			R-22 or R407c or R404a or R410a or R134a
		Control type			Thermostatic expansion valve
Compressor	Type			Scroll Type
		Power(kw)			13.2	17.5	20.4	26.1	34.8
Evaporator	Type			Tank with coil or Shell and tube or Brazed plate heat exchanger(BPHE)
		Water flow(m³/h)			5.84	7.73	8.85	11.68	15.3
		Fitting pipe(mm)			DN40	DN40	DN40	DN65	DN65
Condenser	Type			Finned Copper tube +low noise air fans
		Air flow(m³/h)			15000	20000	25000	30000	40000
Water pump	Power(kw)			1.5	1.5	1.5	2.2	2.2
		Lift(m )			20	20	20	20	20
Dimension	L(mm)			1800	2000	2000	2500	2350
		W(mm)			1000	1000	1000	1200	1460
		H(mm)			1600	1700	1700	1800	1900
Net Weight	kg			750	850	900	1150	1350

Application

Glycol Chiller ,Water Chiller Application

-5 Degree C glycol chiller mostly work for dairy milk yogurt, food, beverage, brewery, winery, distillery

5deg C ~30deg C water chiller widely work for plastic injection molding, extrusion , printing, cnc machine, chemical, oil & gas, anodizing, etc.

Our Company

Mgreenbelt is a professional manufacturing,sales, and service as one of the industrial water chiller and plastic auxiliary
equipment field of outstanding manufacturing enterprises.

1). The leader of water chiller production, 20+ years experience for R&D, more than 80% customers’choice;

2). 2+ workshops covers more than 34,000 square meter;

3). 80+ employees, including 20+ senior engineers, 40 technicians;

4). Top water chiller equipment manufacture in North of China;

5). Product chillers export to 100+ countries ,mostly in North America, South America, Aria, Middle east, Europe
6). Product chillers with SO9001,CE,RoHs, UL, CSA, CRN certificate.

As a professional water chiller manufactuer in China, we can supply kinds of chiller solution according to your different working need, OEM is accept, if this series is not workable for you, please feel free send news to us.

Production refrigeration water chillers

1).Power supply:Single or 3 phase ,208-240V,380-415V,440V-480V, 50Hz or 60Hz;

2).Refrigerant R-22 or Eco friendly R-407C,R-410A,R-134A,R-404A

3).Outlet temperature range: -25°C , -20°C , -15°C, -10°C , -5°C , 0°C , 5°C ~35°C

4).Cooling capacity: 2.7kw~1500kw (0.8tons-425tons)

5).Compressor type:Screw type,Scroll type

6).Compressor brand: Sanyo,Copeland, Danfoss, Daikin, Hanbell, Bitzer

Customer Comments

Contact US

If you are looking for the cooling system, refrigeration unit or the models above is not so suitable, welcome to contact with us by any time.

Main product : water chiller, water cooled chiller, air cooled chiller, glycol chiller, brine chiler, sea water chiller,etc.

Ordering and Pricing

• Minimum order quantity: 1 unit
• Volume pricing:
  • 1+ unit: US $1499 / unit
• Ships from: China
• Customization: OEM and ODM accepted on qualifying volumes.

Frequently Asked Questions

What is the minimum order quantity for this glycol water cooling chiller?

The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.

What warranty is provided?

The manufacturer provides a 12 Months warranty. Spare parts and technical support remain available after the warranty period.

Can the glycol water cooling chiller be supplied for my local voltage?

The standard configuration is 3PH~220V/380/415V/460V~50HZ/60HZ. Alternative voltage and frequency builds are available when specified at the time of order.

Do you accept OEM or custom branding?

Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.

How long does production and delivery take?

In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.

About the Manufacturer

This product is produced by Jinan Mgreenbelt Machinery Co., Ltd., based in China. The company 9 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Jinan Mgreenbelt Machinery Co., Ltd. range on HVACR Nexus.
