The industrial ventilation exhaust fan listed here carries voltage DC310, blade material Plastic, documented exactly as the manufacturer publishes it. Made by Foshan Sunwind Electric Co., Ltd. (6 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Industrial Ventilation Exhaust Fan
- Model Number: BC220A-D092A6-00
- Voltage: DC310
- Blade Material: Plastic
- Material: Impeller made of PA66
- Speed: 3500RPM
- Speed Control: Control input0 5/10V or PWIM
Technical Specifications
| Voltage | DC310 |
|---|---|
| Speed | 3500RPM |
| Blade Material | Plastic |
| Mounting | Wall Fan |
| Warranty | 1 Year |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM |
| Place Of Origin | Guangdong, China |
| Brand Name | SunxFan |
| Model Number | BC220A-D092A6-00 |
| Material | Impeller made of PA66 |
| Bearing | Ball bearing |
| Speed Control | Control input0 5/10V or PWIM |
| Working Temp | -40~ +60°C |
| Insulation Class | B |
| Protection Class | IP55 |
| Approvals | CCC, CE |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Material | Impeller made of PA66 |
Bearing | Ball bearing |
Speed control | Control input 0-5/10V or PWM |
Working Temp. | -40~ +60°C |
Insulation Class | B |
Protection Class | IP55 |
Approvals | CCC, CE |
2001-2003: Fan blade design, impeller fluid flow development
2004-2006: Shaded-pole motor
2007-2017: BLDC & PMSM motor
2017-2021: Integrated fan motor, fluid flow, electric control to manufacture centrifugal fan and axial fan
Quality Control System:
MSA, ISO9001, Traceability system, PDCA
100% full inspection before shipment
About SunxFan:
* Design on motor, fluid flow, electric control
* Manufacture all the key components by ourselves
* Process management: IPD
* Product Reliability: Type test, life expectancy test and running test.
We manufacture a range of product:
※133mm,175mm,190mm,220mm,225mm,250mm,280mm,320mm,355mm backward curved centrifugal fan
※120,140,160,180mm single inlet forward curved centrifugal fan
※133, 146mm double inlet forward curved centrifugal fan
※200, 220, 225, 250, 280mm axial flow fan
※Motor type: 115V/230V AC, 24/48V/310VDC, 115/230V/380V EC type
Ordering and Pricing
- Minimum order quantity: 300 piece
- Volume pricing:
- 300–499 piece: US $40.2 / piece
- 500–999 piece: US $38.2 / piece
- 1000–1999 piece: US $36.2 / piece
- 2000+ piece: US $34.2 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this industrial ventilation exhaust fan?
The standard minimum order quantity is 300 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this industrial ventilation exhaust fan carry?
It is supplied with CCC, CE documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the industrial ventilation exhaust fan be supplied for my local voltage?
The standard configuration is DC310. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Sunwind Electric Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Foshan Sunwind Electric Co., Ltd. range on HVACR Nexus.
