Key specification for this radial fan: 5V/12V/24V, power source type Electric. Everything below is reproduced from the factory data sheet. Made by Shenzhen Feng Huishun Technology Development Co., Ltd. (4 years on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Radial Fan
- Model Number: FH3010GSU1
- Power Source Type: Electric
- Voltage: 5V/12V/24V
- Material: Plastic
- Blade Material: Plastic
- Noise Level: 20-30dB-A
Technical Specifications
| Duct Diameter | 1-2IN |
|---|---|
| Mounting | Free Standing |
| Voltage | 5V/12V/24V |
| Material | Plastic |
| Blade Material | Plastic |
| Power Source Type | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Noise Level | 20-30dB-A |
| Place Of Origin | Guangdong, China |
| Brand Name | FH/OEM/ODM |
| Model Number | FH3010GSU1 |
| Product Name | DC Blower Fan |
| Size | 30X30X10mm |
| Bearing Type | Sleeve Bearing/Ball bearing |
| Usage | Air Ventilation,Car seat, Radiator, Toilet, Radiator, Helmet |
| Feature | High Efficiency,Low Noise Power Saving |
| Function | Customer’s Requirement |
| Color | Black |
| Certification | CE,ROHS |
| Selling Units | Single item |
| Single Package Size | 12X12X10 cm |
| Single Gross Weight | 0.02 kg |
Product Details
Product Name | DC Blower Fan |
Product Dimension | 30x30x10mm(Length* Width *Thickness) |
Material | Plastic |
Rated Voltage | 5V DC FAN (12V Optional) |
Bearing Type | Sleeve Bearing ( Ball Bearing Optional) |
Rated Speed:12000RPM(At rated Voltage,Measured after 3Mins.) Air Flow:4.15CFM (Maximum In Free Air) Air Pressure: 0.25Inch-H2O(Maximum When Air Flow = 0) Noise Level: 30dBA (At Rated Speed) | |
Operating Temperature & Life Expectancy | Ball bearing: -30°C to +75°C @ 50000hours at 40°C Sleeve bearing: -10°C to +70°C @ 30000hours at 25°C |
Function (optional) | PWM Control / FG Tacho / RD Alarm |
Feature (optional ) | Locked Motor Protection,Auto Restart,Polarity Protection,Soft Start |
Wire & Connector & Tube | Wire length & Connector model ( as required ) |
Package | Carton box,we can also according to the requirements of customers. |
Product Specification
Remarks
Factory
Sales department
Workshop Quality control
Assembly line 1
Assembly line 2
Wind Tunnel
Salt Spray Machine
Automatic Welding Machine
Answer: we can provide DC cooling fan, AC cooling fan, EC cooling fan,blower fan,centrifugal fan and cross flow fan.
2. What are kinds of information provided by the customer before inquiry?
Answer : please kindly advise the size, voltage, the type of bearing, the speed of fan , or air flow.
3. How many types bearing of our cooling fan are there in our company at present?
Answer : now we have two types bearing for the fan, sleeve and ball, working time of sleeve is for 30,000 hours, the ball is for 50,000-80,000 hours.
4. How to detect the data of cooling fan in your company?
Answer: the speed and voltage are detected by the tachometer, air flow is found by wind tunnel.
5. How to control the quanlity of products in your company.
Answer: 100% total testing before each of fan leaves our factory.
Answer: we offer an 12 months warranty and on line engineer support.
Answer: sure ,like tooling , packing and others, our engineer will do our best to meet with your requirement!
Ordering and Pricing
- Minimum order quantity: 50 piece
- Volume pricing:
- 50–999 piece: US $1.7 / piece
- 1000–9999 piece: US $1.5 / piece
- 10000–99999 piece: US $1.2 / piece
- 100000+ piece: US $0.9 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this radial fan?
The standard minimum order quantity is 50 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this radial fan carry?
It is supplied with CE,ROHS documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the radial fan be supplied for my local voltage?
The standard configuration is 5V/12V/24V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Feng Huishun Technology Development Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Shenzhen Feng Huishun Technology Development Co., Ltd. range on HVACR Nexus.
