The radial fan listed here carries 380V, blade material Cast Iron, documented exactly as the manufacturer publishes it. Made by Guangdong Leapin Environmental Technology Co., Ltd. (4 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Radial Fan
- Model Number: LT-FC
- Voltage: 380V
- Blade Material: Cast Iron
- Impeller Material: Galvanized Metal Steel Sheet
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
Technical Specifications
| Mounting | Free Standing |
|---|---|
| Voltage | 380V |
| Blade Material | Cast Iron |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Guangdong, China |
| Brand Name | leapin |
| Model Number | LT-FC |
| Product Name | HVAC system centrifugalfan |
| Air Volume | 1706-121867m ³/ h |
| Total Pressure | 199-1583Pa |
| Motor | AC Motor |
| Diameter Of Impeller | 250mm – 1000mm |
| Impeller Material | Galvanized Metal Steel Sheet |
| Function | Ventilaion |
| Type | Centrifugal Fan |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Products Description
Product name | Forward curved centrifugal DWDI |
Material | Cabinet body:composed of profile frame and box plate |
Composition | Advanced die pressing to prevent deformation of high-temperature plates |
Features/advantages | Low noise, large air volume, high temperature resistance, stable operation and convenient installation |
Scope of application | Working conditions of ventilation, fire smoke exhaust, air purification and other ventilation and fire smoke exhaust in office buildings, hotels, cinemas, auditoriums, basements, villas, shopping malls, hospitals, workshops and other places |
Transmission mode | E-belt transmission |
Motor position | Type A – motor top mounted, motor side mounted, motor rear mounted; Type B – motor built-in |
Air outlet angle | 0 °, 90 °, 180 °, 270 ° |
Transmission medium | on corrosive, non spontaneous combustion and explosion gas |
Air volume | 1706-121867m ³/ h |
Total pressure | 199-1583Pa |
Working conditions | temperature (- 20~+40 ℃); Humidity (<90 °); Medium (air – dust content not exceeding 10mg/m ³) |
Working power supply | three-phase, 380V/50Hz |
Company Profile
Guangdong Leapin Environmental Technology Co., Ltd.
Guangdong leapin Environmental Technology Co., Ltd., founded in April 2018, is a industry-leading fan manufacturer and technical design of commercial exhaust system supplier. The company is located in Foshan, China industrial zone, in which surrounded by convenient transportation and supply chain. In recent years, the company has increased investment in product research and development and production equipment, and the production process has basically achieved semi-automatic and is ahead of the manufacturing level of the same industry. Through structural reform in 2021, Foshan Factory and Sichuan Factory were established , a wholly owned subsidiary of leapin group. The formation of both factories aim to provided high quality product and services, fast respond time and meet local customers’ fan requirement. With growing demand in fans market, leapin manufacture has extend its sales network throughout all over china and partly some foreign countries. Our company has always adhered to the quality as the core standard, and each process has been strictly controlled. The product quality has been certified by the Fire Products Conformity Assessment Center of the Ministry of Public Security, and has won the China National Product Certification Certificate. It has been recognized as a "high-tech enterprise" by the government, and has been awarded the title of "Guangdong Province Contract abiding and Credit worthy Enterprise". One of our wholly owned subsidiary, Foshan Yuan lvpin ventrilation ltd, was established in 1998, and it has more than 20 years of fan manufacturing experience. The company's main products include commercial centrifugal and axial smoke exhausted fan series, electrostatic purifier series, air damper series, etc. Covering an area of about 20000 m2, it is equipped with relatively complete R&D, testing and inspection equipment. There are more than 160 employees, including 15 engineering technology R&D teams. At present, 37 national patents have been obtained for independent R&D, including 2 invention patents and 1 appearance patent. The products are mainly sold to high-rise buildings, office buildings, hotels, industrial and mining enterprises, entertainment places, residential buildings and other ventilation throughout the country, ranking among the best in the ventilation equipment industry.
Certifications
Sample Show
Our Factory
Sheet metal workshop production line
Fire damper workshop production line A
Fan inspection laboratory
Cabinet fan workshop
Robot automatic welding line
Laser cutting operation area
Continuous punching workshop
Hydraulic operation area
Axial flow fan workshop
Exhibition
Product Packaging
FAQ
1. How to select suitable products according to the on-site operation environment? The design of the entire ventilation system and the selection of fans should be carried out by professionals. It is necessary to estimate the resistance of the system as accurately as possible, otherwise improper selection will lead to poor actual use effect of the fan. 2. How long is the delivery cycle of the product? How about the payment method? 1) Generally, the delivery period is 10-30 days. The specific delivery date shall be determined in combination with the actual product. 2) Payment methods support TT, LC and Dp. The payment for goods is divided into deposit and balance payment, which shall be paid before shipment. 3. Why choose you in the same industry? What are your advantages over your peers? 1) Our company has more than 20 years of manufacturing experience in the fan industry, with complete site and equipment configuration; 2) Advanced manufacturing technology, production equipment has basically achieved semi-automatic, leading the industry level; 3) Quality assurance and product quality have been certified by the Fire Products Conformity Assessment Center of the Ministry of Public Security; 4) We owned a technical team of 12 members, formed by three senior engineers, nine intermediate engineers. Accredited fan laboratory, makes each single performance data more reliable. 4. What is the delivery method? Logistics modes include express delivery, sea transportation, land transportation and air transportation. 5. About after-sales service. 1) 24-hour service hotline, professional technicians answer product questions; 2) Provide relevant technical guidance according to the use of customers; 3) Regularly make a return visit to understand the product operation, and exchange the latest maintenance and servicing technology.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1+ piece: US $257 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this radial fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the radial fan be supplied for my local voltage?
The standard configuration is 380V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
