The shell and tube heat exchanger listed here carries material Copper, heat exchanger type Tube Heat Exchanger, documented exactly as the manufacturer publishes it. Made by Hubei Aesima Heat Exchange Equipment Co., Ltd. (1 year on the platform, typical reply ≤4h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Shell And Tube Heat Exchanger
- Flow Capacity: 25GPM
- Material: Copper
- Tube Material: SS304, SS316L, Carbon Steel, Titanium
- Shell Material: Carbon Steel, SS304, SS316L
- Warranty: 1 Year
- Certification: ASME, TEMA, ISO 9001
Technical Specifications
| Heat Exchanger Type | Tube Heat Exchanger |
|---|---|
| Flow Capacity | 25GPM |
| Fluid Compatibility | Steam, Chemical, Hot Oil, Water |
| Material | Copper |
| Maximum Operating Temperature | >600c |
| Core Components | Pressure Vessel, PLC |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Low Maintenance Cost, ASME Certified, TEMA Standard |
| Working Temperature Range | -40°C to +600°C |
| Place Of Origin | Hubei, China |
| Weight (Kg) | 20 |
| Brand Name | AESIMA |
| Liquid Flow Rate | 2.5m/s |
| Maximum Pressure Rating | Customized |
| Dimension(L*W*H) | Customized based on drawings or working conditions |
| Tube Length | 1.5 m to 12 m (standard: 3 m, 4.5 m, 6 m) |
| Connection Sizes | DN 25 to DN 600 (1" to 24") |
| Heat Transfer Area | 5 m² to 5,000 m² |
| Working Pressure | Shell side: 6-40 bar |
| Certification | ASME, TEMA, ISO 9001 |
| Tube Material | SS304, SS316L, Carbon Steel, Titanium |
| Shell Material | Carbon Steel, SS304, SS316L |
| Selling Units | Single item |
Product Details
Our Products:Shell and Tube Heat Exchanger
Advanced Thermal Management: Shell & Tube Heat Exchangers
Efficient | Robust | Versatile
Recognized as our signature product, this series is the premier solution for refineries, major chemical facilities, and demanding high-pressure environments.
Recognized as our signature product, this series is the premier solution for refineries, major chemical facilities, and demanding high-pressure environments.
Working Principle & Structure
Key Advantages
The AESIMA Advantage
uD83DuDEE1️ Wide Range of Materials | Features materials like Carbon Steel, Stainless Steel, Copper, Nickel, and Titanium, plus specialized coatings to withstand diverse process media and environments. |
⚙️ Tailor-Made Solutions | Dimensions, connections, and thermal performance are fully customizable. We also offer 100% OEM-compatible drop-in replacements. |
uD83DuDCCA HTRI Precise Calculation | Our engineering team provides HTRI calculation reports to validate actual operating conditions and ensure all performance specifications are met. |
uD83CuDF0DBroad Industry Application | Perfectly suited for Swimming Pool Heat Pumps, Aquarium Cooling, Marine, Food , and Waste Heat Recovery applications. |
✅ Quality Assurance & Warranty | Includes a 1-year warranty. Optional ASME-compliant construction is available. |
Materials & Applications
Title goes here.
uD83DuDD36 Carbon Steel
* Features: High mechanical strength and cost-effective.
* Applications: Non-corrosive environments and medium temperatures (<300°C). Commonly used for industrial system shells.
⚪ Stainless Steel (SS304/316)
* Features: Excellent corrosion resistance and good thermal performance.
* Applications: Chemical processing, food industries, and HVAC systems.
uD83DuDD35 Titanium
* Features: Superior corrosion resistance (resistant to chlorides, acids, and biofouling).
* Applications: Seawater applications, marine vessels, offshore platforms, and other critical environments.
uD83DuDFE4 Copper & Nickel Alloys
* Features: Copper alloys offer high thermal conductivity; Nickel alloys withstand extreme corrosion and high temperatures.
* Applications: Copper is used for non-corrosive water cooling; Nickel is suited for high temperatures (>800°C) or highly corrosive media.
* Features: High mechanical strength and cost-effective.
* Applications: Non-corrosive environments and medium temperatures (<300°C). Commonly used for industrial system shells.
⚪ Stainless Steel (SS304/316)
* Features: Excellent corrosion resistance and good thermal performance.
* Applications: Chemical processing, food industries, and HVAC systems.
uD83DuDD35 Titanium
* Features: Superior corrosion resistance (resistant to chlorides, acids, and biofouling).
* Applications: Seawater applications, marine vessels, offshore platforms, and other critical environments.
uD83DuDFE4 Copper & Nickel Alloys
* Features: Copper alloys offer high thermal conductivity; Nickel alloys withstand extreme corrosion and high temperatures.
* Applications: Copper is used for non-corrosive water cooling; Nickel is suited for high temperatures (>800°C) or highly corrosive media.
Configuration Options
Different structural designs accommodate varying thermal expansion and cleaning requirements.
Type A: Fixed Tube Sheet
[Diagram Caption: Tube sheets welded directly to the shell]
* Applications: Low temperature difference (<50°C), low pressure, and clean fluids.
Type B: Floating Head
[Diagram Caption: One tube sheet is free to move axially]
* Applications: High temperature difference (>50°C), fouling or corrosive fluids, and applications requiring frequent cleaning.
Type C: U-Tube
[Diagram Caption: Tubes are bent into a U-shape]
* Applications: High temperature and high pressure (≥30 bar, >300°C). Tubes are free to expand thermally.
[Diagram Caption: Tube sheets welded directly to the shell]
* Applications: Low temperature difference (<50°C), low pressure, and clean fluids.
Type B: Floating Head
[Diagram Caption: One tube sheet is free to move axially]
* Applications: High temperature difference (>50°C), fouling or corrosive fluids, and applications requiring frequent cleaning.
Type C: U-Tube
[Diagram Caption: Tubes are bent into a U-shape]
* Applications: High temperature and high pressure (≥30 bar, >300°C). Tubes are free to expand thermally.
Advanced Tube Engineering
Precision-engineered using HTRI simulation to ensure optimal thermal efficiency and fluid dynamics.
uD83DuDCD0 Tube Pitch Configurations
* (Diagram: Triangular Layout) Triangular (30°/60°) Features higher tube density to maximize the heat transfer area. Best suited for clean fluids.
* (Diagram: Square Layout) Square (45°/90°) Provides continuous cleaning lanes to facilitate mechanical cleaning. Ideal for fouling fluids.
➰ Tube Surface & Pass Arrangements
* (Diagram: Bare vs. Finned Tube) Surface Options Available in standard Bare Tubes or Low-Finned Tubes to increase surface area (highly effective for gases or viscous oils).
* (Diagram: Pass Flow) Pass Designs Configurable from single-pass to multi-pass (2/4/6 passes) to optimize tube-side velocity and enhance the heat transfer coefficient.
* (Diagram: Triangular Layout) Triangular (30°/60°) Features higher tube density to maximize the heat transfer area. Best suited for clean fluids.
* (Diagram: Square Layout) Square (45°/90°) Provides continuous cleaning lanes to facilitate mechanical cleaning. Ideal for fouling fluids.
➰ Tube Surface & Pass Arrangements
* (Diagram: Bare vs. Finned Tube) Surface Options Available in standard Bare Tubes or Low-Finned Tubes to increase surface area (highly effective for gases or viscous oils).
* (Diagram: Pass Flow) Pass Designs Configurable from single-pass to multi-pass (2/4/6 passes) to optimize tube-side velocity and enhance the heat transfer coefficient.
Engineering & Quality Assurance
We utilize industry-leading software for our designs, including HTRI, Aspen EDR, SW6, and PV Elite.
We have successfully exported to 32 nations globally. Customer feedback validates that the actual cooling performance aligns closely with theoretical design specifications.
We conduct rigorous factory testing to guarantee leak-free operation and structural integrity, satisfying safety standards for high-pressure and high-temperature applications.
