Key specification for this steam boiler: material Stainless Steel, type Natural Circulation. Everything below is reproduced from the factory data sheet. Made by Taikang Zhongxin Boiler Co., Ltd. (1 year on the platform, typical reply ≤1h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Steam Boiler
- Material: Stainless Steel
- Warranty: 1 Year
- Place Of Origin: Henan, China
- Application: Various factories, hospitals, central heating, swimming pool heating
- Type: Natural Circulation
- Weight (Kg): 8000
Technical Specifications
| Output | Steam |
|---|---|
| Usage | Industrial |
| Fuel | Gas |
| Pressure | Low Pressure |
| Structure | Fire Tube |
| Type | Natural Circulation |
| Material | Stainless Steel |
| Core Components | PLC, Screw, Pump, Motor, Bearing, Pressure Vessel |
| Key Selling Points | Automatic, High-Accuracy, Easy To Operate, High Safety Level, Energy Saving, Low Maintenance Cost |
| Style | Horizontal |
| Warranty | 1 Year |
| Video Outgoing-Inspection | Provided |
| Machinery Test Report | Provided |
| Weight (Kg) | 8000 |
| Place Of Origin | Henan, China |
| Brand Name | ZXBoiler |
| Dimension(L*W*H) | reference model |
| Product Name | Horizontal Fuel Gas Steam Boiler |
| Design Fuel | Gas/Oil |
| Keywords | Automatic Efficient |
| Thermal Efficiency | 92.5-99.8% |
| Working Pressure | 1.25-5.3 Mpa |
| Control System | PLC+Touch Screen |
| Boiler Structure | 3Pass |
| Rated Steam Temperature | 194/204/225C |
| Application | Various factories, hospitals, central heating, swimming pool heating |
| Operation | Fully Automatic Control |
| Selling Units | Single item |
Product Details
Project | WNS0.5-1.0-YQ | WNS1.0-1.25-YQ | WNS2.0-1.25-YQ | WNS3.0-1.25-YQ | WNS4.0-1.25-YQ | WNS6.0-1.25-YQ | WNS8.0-1.25-YQ | WNS10-1.25-YQ | |||||||||
Rated evaporation capacity(t/h) | 0.5 | 1 | 2 | 3 | 4 | 6 | 8 | 10 | |||||||||
Rated steam pressure(MPa) | 1 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | |||||||||
Rated steam temperature(°C) | 184 | 194 | 194 | 194 | 194 | 194 | 194 | 194 | |||||||||
Feed water temperature(°C) | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |||||||||
Thermal efficiency(%) | ≥93 | ||||||||||||||||
Transport reference weight(T) | 2.5 | 5.4 | 8.06 | 10 | 12.43 | 15.5 | 22 | 26.55 | |||||||||
Transport reference dimensions(mm) | long | 3300 | 4180 | 4300 | 5170 | 5600 | 6300 | 6580 | 7300 | ||||||||
wide | 1500 | 1720 | 1900 | 2000 | 2150 | 2250 | 2620 | 2860 | |||||||||
high | 1700 | 2050 | 2400 | 2500 | 2640 | 2700 | 3120 | 3400 | |||||||||
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–1 piece: US $6180 / piece
- 2–2 piece: US $5180 / piece
- 3+ piece: US $4280 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this steam boiler?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Taikang Zhongxin Boiler Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Taikang Zhongxin Boiler Co., Ltd. range on HVACR Nexus.
