The vrf system air conditioner listed here carries power supply 220-240V/380V/1Ph/50Hz/60Hz, airflow 6000m³/h, documented exactly as the manufacturer publishes it. Made by Henan Shangfeng Hvac Engineering Co., Ltd. (4 years on the platform, typical reply ≤5h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Vrf System Air Conditioner
- Power Supply: 220-240V/380V/1Ph/50Hz/60Hz
- Power Input: 2.6-24.33Kw
- Operating Voltage: 230 VAC
- Cooling Capacity: 8-96 hp
- Heating Capacity: 25-90kw
- Airflow: 6000m³/h
Technical Specifications
| Type | Fan Coil Unit |
|---|---|
| Airflow | 6000m³/h |
| Operating Voltage | 230 VAC |
| Mounting Type | Ceiling Mount |
| Key Selling Points | R410A |
| Warranty | 3 Years |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Core Components | Motor, Pump |
| Place Of Origin | Henan, China |
| Weight (Kg) | 360 KG |
| Brand Name | TX, Customized |
| Dimension(L*W*H) | Customized |
| Product Name | T3 Tropical Condition VRF System Air Conditioner |
| Refrigerant | R-410A |
| Function | CoolingHeating |
| Cooling Capacity | 8-96 hp |
| Heating Capacity | 25-90kw |
| Compressor | DC Inverter Compressor |
| Power Supply | 220-240V/380V/1Ph/50Hz/60Hz |
| Power Input | 2.6-24.33Kw |
| Noise | 54-57db(A) |
| Working Condition | Cooling:-5~55 Heating:-30~30 |
| Selling Units | Single item |
| Single Package Size | 260X160X130 cm |
| Single Gross Weight | 180.000 kg |
Product Details
Type | Mini VRF | Large VRF | ||||
Capacity | HP | 3HP-12HP | 8HP-32HP | |||
Power supply | V/Ph/Hz | 220-240V/1PH/50Hz 208-230V/1PH/60Hz 380-415V/3PH/50Hz & 60Hz | 220-240V/1PH/50Hz 208-230V/1PH/60Hz 380-415V/3PH/50Hz & 60Hz | |||
Cooling | Capacity | kW | 8KW~33.5KW | 25.2KW-90KW | ||
kBtu/h | 27.3-114.3kBtu/h | 86-307.1kBtu/h | ||||
Power input | kW | 2.6-9.46KW | 5.31-24.79KW | |||
EER | kW/kW | 3.08-3.54 | 3.63-4.75 | |||
Heating | Capacity | kW | 9KW-37.5KW | 27.4KW-100KW | ||
kBtu/h | 30.7-128kBtu/h | 93.5-341.2kBtu/h | ||||
Power input | kW | 2.65-8.99KW | 4.98-24.33KW | |||
COP | kW/kW | 3.4-4.17 | 4.11-5.5 | |||
Comperssors | Type | – | DC inverter | |||
Fan motors | Type | – | DC inverter | |||
Refrigerant | Type | R410A | ||||
Aiflrow rate | m3/h | 3300-8000 | 15000-17000 | |||
dB(A) | 45-60 | 58-64 | ||||
Ambient temp | Cooling | ℃ | ‘-5-55℃ | -5-55℃ | ||
Heating | ℃ | -15-30℃ | -30-30℃ | |||
1. Country and City, Use place Max. and Min Temp?
2. Voltage? 220v or 380v? 50hz or 60hz?
3. Project Drawing? Or building layout? Or equipment BOQ?
4. Expected shipping date of this project?
Ordering and Pricing
- Minimum order quantity: 2 set
- Volume pricing:
- 2–9 set: US $600 / set
- 10+ set: US $300 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this vrf system air conditioner?
The standard minimum order quantity is 2 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the vrf system air conditioner be supplied for my local voltage?
The standard configuration is 230 VAC. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Henan Shangfeng Hvac Engineering Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, Trading Company. Browse the full Henan Shangfeng Hvac Engineering Co., Ltd. range on HVACR Nexus.
