Air curtain — voltage AC 220V~240V, power source Electric. The complete factory specification follows. Made by Wenzhou Jason Fan Manufacturer Co., Ltd. (18 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Air Curtain
- Model Number: FJK225PB230
- Power Source: Electric
- Voltage: AC 220V~240V
- Material: PBT
- Blade Material: Plastic
- Speed: 2700 RPM
Technical Specifications
| Voltage | AC 220V~240V |
|---|---|
| Speed | 2700 RPM |
| Type | Roof Axial Fan |
| Material | PBT |
| Blade Material | Plastic |
| Mounting Type | Ceiling Fan |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 4 Years |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Zhejiang, China |
| Brand Name | Jasonfan |
| Model Number | FJK225PB230 |
| Color | RAL7035 |
| Protection Grade | IP54 |
| Termination | 2 Terminals |
| Fan Filter Size | 310*310*140mm |
| Fan | C2E-190.45A |
| Selling Units | Single item |
Product Details
High Efficiency Air Curtain Cooling Standing Ventilation Industrial Ceiling Centrifugal Fans Roof UPS Fan Cabinet Top Ventilator
RAL 7035 grey is the standard offer with the possibility to change to RAL 7032 by means of a replacement grille.
Bear in mind the pressure losses caused by the outlet element (grille with filter, ventilation louvre or simple opening) when determining the fan flow rate.Protection class: EN60529 IP54
| Specifications | |
| Category | Air filter fan |
| Type | FJK225PB230 |
| Rated Voltage | 230V AC |
| Frequency | 50/60Hz |
| Current | 0.6/0.74A |
| Input Power | 131/170W |
| Speed | 2550/2750 RPM |
| Max Air Flow | 1020/1140m³/h |
| Static Pressure | 430/585Pa |
| Noise | 62/64dB |
| Weight | 4.56 KG |
| Certificate | UL,CCC,CE,ISO9001 |
Q: Are you a factory or trading company?
A: We are a factory.
Q: Where is your factory located? How can I visit there?
A: Our factory is located in Yueqing City,Zhejiang Province, China, about 30 mins from Wenzhou Airport .Warmly welcome to visit us!
Q: What products do you make?
A: We have been producing AC cooling axial fans , Centrifugal fans, Filter fans etc since established in 2006.
Q: What information do you need in order to get a quotation?
A: Generally, we need the information like quantity, size, voltage , air flow to select a right or a similar fan for you and quote you.
Q: Can I have samples for testing before placing orders?
A: Yes. We suggest that our customers have some samples of their required fans for quality testing first.
Q: Can I have a discount for the quoted price?
A: Yes. The price is quoted based on the quantity.
Q: How is your quality control systerm?
A : Each fan needs to go though strict inspection by QC before delivery, or inspected by 3rd party who customer appoints.
Q: Does the product have CE,UL etc approval?
A : Yes. All of our products have CE,RoHS approval, some have UL approval.
Q: Can you make the fan with our company's logo?
A : Yes.
Q: What is your payment term?
A : TT,LC.
Ordering and Pricing
- Minimum order quantity: 6 piece
- Volume pricing:
- 6–119 piece: US $71.5 / piece
- 120–239 piece: US $70.7 / piece
- 240+ piece: US $68.9 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this air curtain?
The standard minimum order quantity is 6 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 4 Years warranty. Spare parts and technical support remain available after the warranty period.
Can the air curtain be supplied for my local voltage?
The standard configuration is AC 220V~240V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Wenzhou Jason Fan Manufacturer Co., Ltd., based in China. The company 18 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Wenzhou Jason Fan Manufacturer Co., Ltd. range on HVACR Nexus.
