This bathroom exhaust fan is published with the manufacturer’s full specification — voltage AC 220V~240V, blade material Cast Iron. Made by Suzhou Blauberg Motoren Technology Co., Ltd. (6 years on the platform, factory-assessed). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Bathroom Exhaust Fan
- Model Number: SD-F160C-EC-01
- Voltage: AC 220V~240V
- Blade Material: Cast Iron
- Warranty: 2 Years
- Certification: CCC
- Place Of Origin: Jiangsu, China
Technical Specifications
| Voltage | AC 220V~240V |
|---|---|
| Blade Material | Cast Iron |
| Mounting | Roof Fan |
| Warranty | 2 Years |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Jiangsu, China |
| Brand Name | Blauberg |
| Model Number | SD-F160C-EC-01 |
| Product Name | FAN MOTOR |
| Application | General Machinery |
| Housing | Iron |
| Protection Class | IP55 |
| Protect Feature | Waterproof |
| Usage | Electric Tool |
| Certification | CCC |
| Size | 247*221*130mm |
| Selling Units | Single item |
| Single Package Size | 45X45X30 cm |
| Single Gross Weight | 3.5 kg |
Product Details
Type | SD-F160C-EC-01 | Nominal Speed | 3450+5%RPM | |
Motor | EC059AC230V040W | Max. Input Power | 86W | |
Phase | 1~ | Max. Input Current | 2.3A | |
Nominal Voltage | 230VAC | Sound level | 70dB(A) | |
Nominal Voltage Range | 184~276VAC | Min.Ambient Temperature | -25℃ | |
Frequency | 50/60 Hz | Max.Ambient Temperature | 60℃ | |
Method of Obtaining Data | FA | ML=Max. load ME=Max, effciency FA=Free Air | ||
Model | Nominal voltage[VDC] | Speed (RPM) | Power input max(W) | Current max(A) | Sound pres level[dB(A)] | Perm amb temp[*c) | Electrical connection |
SD-F120B-EC-00 | 24 | 3650 | 75 | 3.2 | 67 | -25 ºC ~ +60 ºC | D |
SD-F140B-EC-00 | 24 | 1860 | 85 | 3.6 | 72 | -25 ºC ~ +60 ºC | D |
SD-F140C-EC-00 | 24 | 1860 | 85 | 3.6 | 72 | -25 ºC ~ +60 ºC | D |
SD‐F160B‐EC‐01 | 24 | 3050 | 150 | 6.5 | 72 | -25 ºC ~ +60 ºC | D |
SD-F160C-EC-00 | 24 | 2650 | 85 | 3.6 | 66 | -25 ºC ~ +60 ºC | D |
SD-F160C-EC-01 | 24 | 3050 | 150 | 6.5 | 68 | -25 ºC ~ +60 ºC | D |
SD-F180A-EC-01 | 24 | 2000 | 150 | 6.3 | 66 | -25 ºC ~ +60 ºC | D |
Deep Customization
Various Support
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–199 piece: US $77.3 / piece
- 200–1999 piece: US $72.89 / piece
- 2000+ piece: US $66.74 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this bathroom exhaust fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 2 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this bathroom exhaust fan carry?
It is supplied with CCC documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the bathroom exhaust fan be supplied for my local voltage?
The standard configuration is AC 220V~240V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Suzhou Blauberg Motoren Technology Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Suzhou Blauberg Motoren Technology Co., Ltd. range on HVACR Nexus.
