The centrifugal blower listed here carries blade material Plastic, certification CE/RoHS/TUV, documented exactly as the manufacturer publishes it. Made by Shenzhen Topfan Technology Development Co., Ltd. (17 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Centrifugal Blower
- Model Number: 5445/7020/10025/10042/10060, 12025/12042/13382/13391, 15035/17569/19069/19092, 22085/22599/25093
- Voltage: Other
- Blade Material: Plastic
- Material: Plastic Blade
- Warranty: 1 Year
- Certification: CE/RoHS/TUV
Technical Specifications
| Mounting | Free Standing |
|---|---|
| Voltage | Other |
| Blade Material | Plastic |
| Electric Current Type | DC |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | China |
| Brand Name | MX/OEM/ODM |
| Model Number | 5445/7020/10025/10042/10060, 12025/12042/13382/13391, 15035/17569/19069/19092, 22085/22599/25093 |
| Product Name | Industrial Centrifugal Fans |
| Application | Exhaust Ventilation |
| Size | 54–250mm |
| Motor | Copper Motor |
| Feature | High Efficiency |
| Type | DC Centrifugal Blower Fan, Centrifugal Fan |
| Usage | Dusty Air Ventilation |
| Material | Plastic Blade |
| Keyword | High Pressure Anticorrosion FRP Centrifugal Fan |
| Certification | CE/RoHS/TUV |
| Applicable Industries | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other |
| Core Components | Motor, Bearing |
| Selling Units | Single item |
| Single Package Size | 22X22X20 cm |
| Single Gross Weight | 1.000 kg |
Product Details
Model | Bearing Type | Rated Volt | Operating Volt | Rated Current | Input Power | Speed | Max. Airflow | Max. Static Pressure | Noise Level | ||||||||
Part No. | S B Y | VDC | VDC | AMP | Watt | RPM | CFM | Pa | dB-A | ||||||||
MX7020GBH1 | B | 12 | 6.0-13.8 | 0.9 | 10.8 | 9200 | 39.9 | 560 | 61 | ||||||||
MX10042GBU1 | B | 12 | 6.0-13.8 | 2.56 | 30.8 | 6000 | 119 | 457.8 | 58.5 | ||||||||
MX12042GBU1 | B | 12 | 6.0-13.8 | 1.5 | 18 | 4000 | 120.2 | 308.7 | 51.5 | ||||||||
MX13382GBH1 | B | 12 | 6.0-13.8 | 2.4 | 28.8 | 4150 | 226 | 395 | 61 | ||||||||
MX15035GBH1 | B | 12 | 6.0-13.8 | 1.24 | 14.9 | 3800 | 135 | 410 | 59 | ||||||||
MX17569GBU1 | B | 12 | 6.0-13.8 | 14 | 168 | 5700 | 622 | 1100 | 80 | ||||||||
MX19069GBU4 | B | 48 | 36.8-60.5 | 3.08 | 148 | 4400 | 571 | 970 | 51.5 | ||||||||
MX22599GBH4 | B | 48 | 36.8-60.5 | 4.7 | 226 | 3500 | 1030 | 940 | 78 | ||||||||
MX25093GBU4 | B | 48 | 36.8-60.5 | 4.8 | 230 | 3100 | 965.3 | 750 | 73 | ||||||||
More Models | Other RPM/CFM/Voltage/Current…please contact us see the specification for more details. | ||||||||||||||||
Product Name | DC AC EC Centrifugal Fan |
Brand | MX topfan/OEM/ODM |
Frame and Impeller | Plastic(94V-0)，PBT |
Bearing Type | Sleeve bearing&Ball Bearing |
Function Range | PWM FG RD IP58 IP68 |
Leadwire | Red Wire Positive(+)，Black Wire Negative(-) |
Rated Voltage | 5V 12V 24V 48V 100V 200V 230V 380V… |
Operating Tempetature | -30℃ to +80℃ |
Product Applications | Household Appliances/Machine/Aeronautical/Power equipment, etc |
Ordering and Pricing
- Minimum order quantity: 2 piece
- Volume pricing:
- 2–99 piece: US $17.01 / piece
- 100–999 piece: US $16.51 / piece
- 1000+ piece: US $16.03 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal blower?
The standard minimum order quantity is 2 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this centrifugal blower carry?
It is supplied with CE/RoHS/TUV documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the centrifugal blower be supplied for my local voltage?
The standard configuration is Other. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Topfan Technology Development Co., Ltd., based in China. The company 17 years as a verified Alibaba.com supplier, Trading Company, passed third-party supplier assessment. Browse the full Shenzhen Topfan Technology Development Co., Ltd. range on HVACR Nexus.
