Centrifugal fan — voltage 220/380/400/450/600v, blade material Carbon steel. The complete factory specification follows. Made by Shandong Hanqi Industrial Co., Ltd. (5 years on the platform, typical reply ≤3h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Centrifugal Fan
- Model Number: 4-68/4-72
- Voltage: 220/380/400/450/600v
- Blade Material: Carbon steel
- Material: Carbon steel/Stainless steel/FRP/PP
- Warranty: 1 Year
- Place Of Origin: Shandong, China
Technical Specifications
| Mounting | Free Standing |
|---|---|
| Voltage | 220/380/400/450/600v |
| Blade Material | Carbon steel |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Shandong, China |
| Brand Name | HANQI |
| Model Number | 4-68/4-72 |
| Product Name | Industrial Centrifugal Fans |
| Application | Exhaust Ventilation |
| Size | Customer’s Request |
| Motor | AC Motor |
| Feature | High Working Temperature Resistance |
| Name | AC Centrifual Blower |
| Usage | High Pressure Blowing |
| Keyword | High Pressure Anticorrosion FRP Centrifugal Fan |
| Material | Carbon steel/Stainless steel/FRP/PP |
| Color | Customers’ Requirements |
| Selling Units | Single item |
| Single Package Size | XX cm |
| Single Gross Weight | 0.0 kg |
Product Details
*Centrifugal fans are widely used in factories, mines, tunnels, cooling towers, vehicles, ships and buildings for ventilation, dust removal and cooling; Ventilation and inducement of boilers and industrial furnaces; Cooling and ventilation in air conditioning equipment and household electrical equipment; Drying and selection of grains; Wind tunnel aeration and propulsion of wind sources and hovercraft.
Model 4-72 centrifugal fan
4-72,F/B-72 type centrifugal fan is mainly used for indoor ventilation general factory and large buildings or transport of air and other non
spontaneous, non explosive, volatile, not on the gas harmless, non corrosive to steel. But the transportation of gas not containing viscous substances,dust and hard particles contained no more than 150mg/m³,gas temperature should not exceed 80°C.
spontaneous, non explosive, volatile, not on the gas harmless, non corrosive to steel. But the transportation of gas not containing viscous substances,dust and hard particles contained no more than 150mg/m³,gas temperature should not exceed 80°C.
Fan type | Rpm(r/min) | Pressure(Pa) | Air Volume(m³/h) | Motor power(Kw) |
2.8A | 2900 | 994-606 | 1131-2356 | 1.5 |
3.2A | 2900 | 1300-792 | 1688-3517 | 2.2 |
3.2A | 1450 | 324-198 | 844-1758 | 3 |
3.6A | 2900 | 1758-989 | 2664-5268 | 1 |
3.6A | 1450 | 393-247 | 1332-2634 | 1.1 |
4A | 2900 | 2014-1320 | 4012-7419 | 6 |
4A | 1450 | 501-329 | 2006-3709 | 1.1 |
4.5A | 2900 | 2554-1673 | 416-634 | 8 |
4.5A | 1450 | 10562-5712 | 2856-5281 | 1.1 |
5A | 2900 | 3187-2019 | 7728-15455 | 15 |
5A | 1450 | 790-502 | 3864-7728 | 2.2 |
6A | 1450 | 1139-724 | 6677-13353 | 4 |
6A | 960 | 498-317 | 4420-8841 | 1.5 |
60 | 1450 | 1139-724 | 6677-13353 | 4 |
60 | 960 | 498-317 | 4420-8841 | 2 |
8D | 1450 | 2032-1490 | 15826-29344 | 19 |
80 | 960 | 887-651 | 10478-19428 | 5.5 |
8D | 730 | 512-376 | 7968-14773 | 3 |
10D | 1450 | 3202-2532 | 40441-56605 | 55 |
10D | 960 | 1395-1104 | 26775-37476 | 18.5 |
10D | 730 | 805-637 | 20360-28497 | 7.5 |
12D | 960 | 2013-1593 | 46267-64759 | 45 |
12D | 730 | 1160-919 | 35182-49244 | 18.5 |
6C | 2240 | 2734-1733 | 10314-20628 | 15 |
6C | 2000 | 2176-1380 | 9205-18418 | 11 |
6C | 1800 | 1760-1116 | 8288-17056 | 7.5 |
6C | 1600 | 1389-881 | 7367-14734 | 5.5 |
6C | 1250 | 846-537 | 5756-11511 | 3 |
6C | 1120 | 679-431 | 5157-10314 | 2.2 |
6C | 1000 | 541-344 | 4144-8288 | 2.2 |
6C | 900 | 438-278 | 4144-8288 | 1.5 |
6C | 800 | 346-220 | 3684-7367 | 1.1 |
8C | 1800 | 3032-3143 | 19646-25240 | 30 |
8C | 1800 | 2302-2920 | 28105-36427 | 37 |
8C | 1600 | 2390-2478 | 17463-22435 | 55 |
8C | 1600 | 2303-1816 | 24982-32380 | 30 |
8C | 1250 | 1507-1106 | 13643-25297 | 11 |
8C | 1120 | 1209-1166 | 12224-15705 | 7.5 |
8C | 1120 | 1124-887 | 17487-22666 | 11 |
8C | 1000 | 963-929 | 10914-14022 | 5.5 |
8C | 1000 | 895-707 | 15614-20237 | 7.5 |
8C | 900 | 779-752 | 9823-12620 | 4 |
8C | 900 | 725-572 | 14052-18213 | 5.5 |
8C | 800 | 615-452 | 8732-16190 | 3 |
8C | 710 | 485-468 | 749-9956 | 2.2 |
8C | 710 | 450-356 | 11085-14368 | 3 |
8C | 630 | 381-280 | 6876-12749 | 2.2 |
10C | 1250 | 2373-1877 | 34863-48797 | 37 |
10C | 1120 | 1902-1505 | 31237-43722 | 30 |
10C | 1000 | 1514-1199 | 27890-39038 | 19 |
10C | 900 | 1225-970 | 25101-35134 | 15 |
10C | 800 | 967-766 | 22312-31230 | 11 |
10C | 710 | 761-603 | 19082-27717 | 7.5 |
10C | 630 | 599-475 | 17571-24594 | 535 |
10C | 560 | 473-375 | 15618-21861 | 4 |
10C | 500 | 377-299 | 13945-19519 | 3 |
12C | 1120 | 2746-2172 | 53978-75552 | 75 |
12C | 1000 | 2185-1969 | 48195-60397 | 45 |
12C | 1000 | 1859-1729 | 63953-67457 | 55 |
12C | 900 | 1767-1399 | 43375-60712 | 37 |
12C | 800 | 1395-1376 | 38556-41973 | 22 |
12C | 800 | 1321-1104 | 45391-53966 | 30 |
12C | 710 | 1097-869 | 34218-47895 | 18.5 |
12C | 630 | 883-684 | 30362-42498 | 15 |
12C | 560 | 682-673 | 26989-29381 | 7.5 |
12C | 560 | 646-540 | 31774-37776 | 1 |
12C | 500 | 543-430 | 24097-33728 | 7.5 |
12C | 450 | 440.434 | 21687-23610 | 4 |
12C | 450 | 417-348 | 25532-30356 | 5.5 |
12C | 400 | 347-275 | 19278-26983 | 3 |
Company Profile
Shandong Hanqi Industry Co., Ltd. is an emerging comprehensive industrial company integrating design, development, manufacturing, installation, sales and after-sales service. It has its own factory and research institute, and has established strategic cooperative relationship with the main advantageous manufacturers in China, and has been providing solution services for customers all over the world for more than ten years.
With the advantages of reliable quality, reasonable price and practical functions, our products are popular in the world market, and we have established long-term and stable partnership with customers from different countries, such as Russia, Saudi Arabia, United Arab Emirates, Singapore, Algeria, Australia, Bangladesh, Brazil, Canada, Costa Rica, Denmark, Honduras, India, Indonesia, Jordan, Lithuania, Malaysia, Pakistan, Romania, South Africa, Thailand, the United States, Vietnam, and so on, Lithuania, Malaysia, Pakistan, Romania, South Africa, Thailand, USA, Vietnam and so on.
OEM&ODM
Strong R&D team allow us provid-ing new designs frequently and wecan always satidfy our customer'sOEM and ODM requirements.
ELITE TEAM
we have experienced manage-ment team dnd well-trained production workers and 24-houronline foreign trade assistant forourbetter customer service
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–19 piece: US $500 / piece
- 20+ piece: US $300 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this centrifugal fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the centrifugal fan be supplied for my local voltage?
The standard configuration is 220/380/400/450/600v. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
