Key specification for this cnc axial cooling fan: voltage 12, power source Electric. Everything below is reproduced from the factory data sheet. Made by Shenzhen Weilishun Technology Limited (16 years on the platform, typical reply ≤3h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Cnc Axial Cooling Fan
- Model Number: FD12038
- Power Source: Electric
- Voltage: 12
- Voltage Range: 12V 24V 48V
- Material: Plastic
- Blade Material: Plastic
Technical Specifications
| Blade Diameter | 4in |
|---|---|
| Voltage | 12 |
| Speed | 4000 |
| Type | High-Temperature Axial Fan |
| Material | Plastic |
| Blade Material | Plastic |
| Mounting Type | Free Standing |
| Bearing Type | Ball Bearing |
| Power Source | Electric |
| Warranty | 3 Years |
| After-Sales Service Provided | Online support |
| Customized Support | OEM, ODM |
| Place Of Origin | Guangdong, China |
| Brand Name | WELLSUNFAN |
| Model Number | FD12038 |
| Fan Type | DC Brushless Fan |
| Size | 120x120x38mm (4.7×4.7×1.5inch) |
| Voltage Range | 12V 24V 48V |
| Bearing System | Ball bearings |
| Motor Type | 100%Copper Motor |
| Frame Material | PBT |
| Applications | For all kinds of electronic products cooling |
| Functions | RD FG PWM IP56 |
| Approvals | UL CUL TUV CE R0HS |
| Selling Units | Single item |
| Single Package Size | 12X12X3.8 cm |
| Single Gross Weight | 0.25 kg |
Product Details
Model | Rated Voltage | Operating Voltage | Current | Input Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | |||||||||
Part No. | VDC | VDC | A | Watt | R.P.M | CFM | mm-H20 | dBA | g | |||||||||
FD12038#12E | 12 | 10.8–13.2 | 0.32 | 3.84 | 4800 | 208.86 | 24.07 | 45 | 320 g | |||||||||
All models could be customized on voltage or any other requirements to fit your need. | ||||||||||||||||||
Model | Rated Voltage | Freq | Current | Input Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | |||||||||
Part No. | VDC | Hz | A | Watt | R.P.M | CFM | mm-H20 | dBA | g | |||||||||
AC08025#11M | 110 | 50/60 | 0.11 | 12.10 | 3000 | 17.28 | 4.83 | 35.2 | 230 | |||||||||
AC08025#11L | 110 | 50/60 | 0.11 | 12.10 | 2900 | 16.7 | 4.57 | 34.5 | 230 | |||||||||
AC08025#22M | 220 | 50/60 | 0.09 | 19.80 | 2550 | 14.49 | 3.30 | 31.7 | 230 | |||||||||
AC08025#22L | 220 | 50/60 | 0.09 | 19.80 | 2450 | 13.92 | 3.05 | 30.8 | 230 | |||||||||
All models could be customized on voltage or any other requirements to fit your need. | ||||||||||||||||||
Ordering and Pricing
- Minimum order quantity: 5 piece
- Volume pricing:
- 5–499 piece: US $3.25 / piece
- 500–4999 piece: US $1.7 / piece
- 5000+ piece: US $1 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cnc axial cooling fan?
The standard minimum order quantity is 5 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3 Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this cnc axial cooling fan carry?
It is supplied with UL CUL TUV CE R0HS documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the cnc axial cooling fan be supplied for my local voltage?
The standard configuration is 12. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Shenzhen Weilishun Technology Limited, based in China. The company 16 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Shenzhen Weilishun Technology Limited range on HVACR Nexus.
