This cold storage air cooler is published with the manufacturer’s full specification — 220 V, 380 V, 110 V, power source Electric. Made by Foshan Kitdoo Refrigeration Equipment Co., Ltd. (2 years on the platform, typical reply ≤1h). Quantity and destination market determine the final price — tell us both for a firm quote.
Key Features of This Cold Storage Air Cooler
- Power Source: Electric
- Voltage: 220 V, 380 V, 110 V
- Material: Alumunim, Copper
- Application Refrigerant: R22/R404A/R134A/R410
- Warranty: 1 Year
- Place Of Origin: Guangdong, China
Technical Specifications
| Processing | Drum Evaporator |
|---|---|
| Material | Alumunim, Copper |
| Power Source | Electric |
| Core Components | Motor |
| Voltage | 220 V, 380 V, 110 V |
| Warranty | 1 Year |
| Machinery Test Report | Not Available |
| Video Outgoing-Inspection | Not Available |
| Place Of Origin | Guangdong, China |
| Weight (Kg) | 50 |
| Brand Name | Kitdoo |
| Product Name | Double side blow air cooled evaporator |
| Color | White |
| Function | Cooling Refrigeration Unit |
| After-Sales Service Provided | Online Support |
| Shipping Port | Guangzhou/Foshan/Shenzhen |
| Application | Cold Room Storage Freezer Room |
| Application Refrigerant | R22/R404A/R134A/R410 |
| Cold Room Temperature | -10 to 0℃ |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Air Cooler Evaporator by Foshan Kitdoo Refrigeration Equipment Co., Ltd.
DD medium temperature type (cool temperature -2 to -18 degrees Celsius) fan space 6.0mm
The Air Cooler Evaporator offers numerous advantages, including:
* Large heat exchange capacity
* Convenient and simple design
* High corrosion resistance
* Beautiful appearance
Key Features:
1. Al-Mg alloy sheet with powder coating (RAL-9003) for strong anti-corrosion performance and lightweight
2. Outer drip tray with integral hinged structure for easy cleaning and operation
3. U-shaped stainless heaters evenly placed into the fins for efficient defrosting
4. Quality iron shell with surface plastic-sprayed finish for corrosion resistance and aesthetics
5. Assembled with axial fan motor for soft breeze and low noise
Additional Information:
* External rotor motor with working temperature -40~60 °C
* Fan specification φ350, with options for 1 to 4 fans
* Fan motors available in 4-poles and 6-poles to meet different noise requirements
For more details, contact Foshan Kitdoo Refrigeration Equipment Co., Ltd.
cc | ||||||||||||||||
Model | Capacity | Cooling surface | Fin Space | Fan | HeaterVoltage | |||||||||||
(W) | (m2) | (mm) | Qty | Size | Air flow | Voltage | (v) | |||||||||
(mm) | (m3/h) | (v) | ||||||||||||||
DL-3.9/20 | 3900 | 20 | 4.5 | 2 | 300 | 3400 | 220 | 220 | ||||||||
DL-5.8/30 | 5800 | 30 | 4.5 | 2 | 350 | 4600 | 220 | 220 | ||||||||
DL-7.8/40 | 7800 | 40 | 4.5 | 2 | 350 | 4600 | 220 | 220 | ||||||||
DL-10.7/55 | 10700 | 55 | 4.5 | 3 | 350 | 6900 | 220 | 220 | ||||||||
DL-15.5/80 | 15500 | 80 | 4.5 | 4 | 350 | 9200 | 380 | 380 | ||||||||
DL-20.3/105 | 20300 | 105 | 4.5 | 4 | 400 | 12000 | 380 | 380 | ||||||||
DL-26.2/135 | 26200 | 135 | 4.5 | 4 | 450 | 16000 | 380 | 380 | ||||||||
DL-31.0/160 | 31000 | 160 | 4.5 | 4 | 450 | 16000 | 380 | 380 | ||||||||
DL-35.9/185 | 35900 | 185 | 4.5 | 4 | 450 | 16000 | 380 | 380 | ||||||||
DL-42.6/220 | 42600 | 220 | 4.5 | 4 | 450 | 19200 | 380 | 380 | ||||||||
Ordering and Pricing
- Minimum order quantity: 1 unit
- Volume pricing:
- 1+ unit: US $170 / unit
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this cold storage air cooler?
The standard minimum order quantity is 1 unit. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the cold storage air cooler be supplied for my local voltage?
The standard configuration is 220 V, 380 V, 110 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Kitdoo Refrigeration Equipment Co., Ltd., based in China. The company 2 years as a verified Alibaba.com supplier, Trading Company. Browse the full Foshan Kitdoo Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
