The pressure regenerative air blower listed here carries rated voltage 200-240V/345-415V, 270m3/h, documented exactly as the manufacturer publishes it. Made by Dongguan Foersheng Intelligent M&E Co., Ltd. (14 years on the platform, typical reply ≤4h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Pressure Regenerative Air Blower
- Model Number: GHBH 003 34 1R6
- Power Source: Electric
- Power: Electric
- Rated Voltage: 200-240V/345-415V
- Max Airflow: 270m3/h
- Blade Material: Aluminium Alloy
Technical Specifications
| Application | Industrial Blower |
|---|---|
| Power Source | Electric |
| Rated Voltage | 200-240V/345-415V |
| Electric Current Type | AC |
| Blade Material | Aluminium Alloy |
| Pressure | High Pressure |
| Warranty | 18 months |
| Customized Support | OEM, ODM |
| Place Of Origin | Guangdong, China |
| Brand Name | GOORUI |
| Model Number | GHBH 003 34 1R6 |
| Usage | for air blowing or suction |
| Power | Electric |
| Material | Alluminium Alloy |
| Color | Customer Required |
| Stage | single stage |
| Phase | three phase |
| Max Airflow | 270m3/h |
| Max Vacuum | -235mbar |
| Max Pressure | 220mbar |
| Certification | CE RoHS CCC |
| Selling Units | Single item |
| Single Package Size | 44.5X44.5X45.5 cm |
| Single Gross Weight | 30.0 kg |
Product Details
Product style | single stage three phase regenerative blower and vacuum pump | ||||||
Model number | GHBH 003 34 1R6 | Weight | 27kg | ||||
Level of protection | IP55 | Insulation class | F | ||||
Certificate | CE Certificate、RoHS Certificate、ISO Certificate、TUV Certificate | ||||||
Frequency | 50Hz | 60Hz | |||||
Rated power | 2.2kw | 2.55kw | |||||
Rated voltage | 200-240△/345-415Y(V) | 220-275△/380-480Y(V) | |||||
Rated current | 9.7△/5.6Y(A) | 10.0△/5.8Y(A) | |||||
Max airflow | 265m³/h | 315m³/h | |||||
Max vacuum | -235mbar | -145mbar | |||||
Max pressure | 220mbar | 230mbar | |||||
Sound level | 65db(A) | 71db(A) | |||||
2. Use ADC12 aluminum alloy material.(same to BMW's wheel hubs)
3. Random installation( vertical or horizontal)
4. Insulation class: F, Protection class: IP54
5. 100% oil free air delivery ( Impeller connected to the motor directly, without any oil lubricating)
6. No routine maintenance (whithout wheel gear and belt,don't need to do maintenance towards those parts)
7. Quiet operation, low noise(adopt low noise motor, meanwhile inlay muffler is available if lower noise required)
8.Variable output control(pressure or vacuum)
9.Pulsation-free compression(use quakeproof footstand)
10.Long term durability(24H running)
11.Strictly tested before leaving the factory
12.CE, SGS , CCC, RoHS, ISO9001 certified.
The performance curves of GOORUI blower is tested under the condition of 1013 mbar pressure,15 °C temerature (allow ±10% difference).
Goorui regenerative blower is made up with impeller, casing, inlet and outlet, brackets, motors, pulleys, couplings, muffler, transmission parts (bearings), installed base, etc.
Pressure | Vacuum |
• Air beds and tables | • Radon gas elimination |
• Refuse burning | • Automatic bottling |
• Automatic loading | • Pneumatic conveying |
• Product drying | • Vacuum hold-down |
• Air cushioning | • Soil remediation |
• Liquid agitation | • Paper transporting |
• Sewage aeration | • Scrap collection |
• Pellet conveying | • Powder recovery |
• Blister packaging | • Gas sampling |
• Liquid spraying | • Thread holding |
• Fuel atomization | • Dust collection |
• Air knives | • Trim removal |
• Stack sampling | • Small vacuum systems |
• Fluidized beds | • Parts handling |
• Respiratory systems | • Material pickup |
Side Channel Blower Package
– To be packed with wooden case
Shipping methods
– By air cargo port to port
– By sea port to port
Also can choose the most suitable way as per your request.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–4 piece: US $228 / piece
- 5–9 piece: US $225 / piece
- 10–19 piece: US $222 / piece
- 20+ piece: US $218 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this pressure regenerative air blower?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 18 months warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this pressure regenerative air blower carry?
It is supplied with CE RoHS CCC documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the pressure regenerative air blower be supplied for my local voltage?
The standard configuration is 200-240V/345-415V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
