The radial fan listed here carries voltage DC310, power source type Corded Electric, documented exactly as the manufacturer publishes it. Made by Foshan Sunwind Electric Co., Ltd. (6 years on the platform, factory-assessed). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Radial Fan
- Model Number: BC133A-D72A0-00
- Power Source Type: Corded Electric
- Voltage: DC310
- Material: Plastic
- Blade Material: Plastic
- Noise Level: 40 dB and above
Technical Specifications
| Mounting | Free Standing |
|---|---|
| Voltage | DC310 |
| Motor Type | DC Motor |
| Speed | 3900RPM |
| Material | Plastic |
| Blade Material | Plastic |
| Power Source Type | Corded Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Video Technical Support |
| Customized Support | OEM |
| Noise Level | 40 dB and above |
| Place Of Origin | Guangdong, China |
| Brand Name | SunxFan |
| Model Number | BC133A-D72A0-00 |
| Bearing | Ball bearing |
| Speed Control | Control input 0 -5/10V or PWM |
| Working Temp | -40~ +60°C |
| Insulation Class | B |
| Protection Class | IP55 |
| Approvals | CCC, CE |
| Type | Centrifugal Fan |
| Applicable Industries | HVAC |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Material | Impeller made of PA66 |
Bearing | Ball bearing |
Speed control | Control input 0-5/10V or PWM |
Working Temp. | -40~ +60°C |
Insulation Class | B |
Protection Class | IP55 |
Approvals | CCC, CE |
Voltage | DC24 |
Current | 1.3 |
Airflow | 350 |
Noise | 68 |
2001-2003: Fan blade design, impeller fluid flow development
2004-2006: Shaded-pole motor
2007-2017: BLDC & PMSM motor
2017-2021: Integrated fan motor, fluid flow, electric control to manufacture centrifugal fan and axial fan
Quality Control System:
MSA, ISO9001, Traceability system, PDCA
100% full inspection before shipment
About SunxFan:
* Design on motor, fluid flow, electric control
* Manufacture all the key components by ourselves
* Process management: IPD
* Product Reliability: Type test, life expectancy test and running test.
We manufacture a range of product:
※133mm,175mm,190mm,220mm,225mm,250mm,280mm,320mm,355mm backward curved centrifugal fan
※120,140,160,180mm single inlet forward curved centrifugal fan
※133, 146mm double inlet forward curved centrifugal fan
※200, 220, 225, 250, 280mm axial flow fan
※Motor type: 115V/230V AC, 24/48V/310VDC, 115/230V/380V EC type
Ordering and Pricing
- Minimum order quantity: 100 piece
- Volume pricing:
- 100–999 piece: US $42.5 / piece
- 1000+ piece: US $37.2 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this radial fan?
The standard minimum order quantity is 100 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this radial fan carry?
It is supplied with CCC, CE documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the radial fan be supplied for my local voltage?
The standard configuration is DC310. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Foshan Sunwind Electric Co., Ltd., based in China. The company 6 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Foshan Sunwind Electric Co., Ltd. range on HVACR Nexus.
See more in Centrifugal Fans on HVACR Nexus.
