Key specification for this stainless steel horizontal pump: power source Electric, material Stainless Steel, Iron, Steel. Everything below is reproduced from the factory data sheet. Made by Hebei Minerco Machinery Co., Ltd. (1 year on the platform, typical reply ≤2h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Stainless Steel Horizontal Pump
- Model Number: IH
- Power Source: Electric
- Horsepower: 150HP
- Material: Stainless Steel, Iron, Steel
- Warranty: One Year
- Place Of Origin: Hebei, China
Technical Specifications
| Application | Industrial Utilities |
|---|---|
| Structure | Single-stage Pump |
| Max Flow Rate | 400 m³/h |
| Power Source | Electric |
| Outlet Size | DN50-200 |
| Material | Stainless Steel, Iron, Steel |
| Motor | Horizontal |
| Warranty | One Year |
| Customized Support | OEM |
| Horsepower | 150HP |
| Pressure | Max 12.5Bar |
| Model Number | IH |
| Place Of Origin | Hebei, China |
| Brand Name | MINERCO |
| Selling Units | Single item |
Product Details
- Corrosion-resistant stainless steel (SS304/SS316/SS316L) construction for aggressive chemical and industrial liquids
- Complies with ISO 2858 standard for stable performance and easy system integration
- High efficiency closed impeller design ensures smooth flow and reduced energy consumption
- Wide performance range up to 400 m³/h flow and 125 m head for industrial applications
IH type pump performance | ||||||||
Pump type | Capacity (m3/h) | Head (m) | Motor power (kw) | Speed (r/min) | ||||
IH 50-32-125 | 7.5 | 23 | 2.2 | 2900 | ||||
IH 50-32-160 | 7.5 | 34.5 | 3 | 2900 | ||||
IH 50-32-200 | 7.5 | 51.8 | 5.5 | 2900 | ||||
IH 50-32-250 | 7.5 | 82 | 11 | 2900 | ||||
IH 65-50-125 | 15 | 21.3 | 3 | 2900 | ||||
IH 65-50-160 | 15 | 34.2 | 5.5 | 2900 | ||||
IH 65-40-200 | 15 | 53.2 | 11 | 2900 | ||||
IH 65-40-250 | 15 | 81.2 | 15 | 2900 | ||||
IH 65-40-315 | 15 | 126.8 | 30 | 2900 | ||||
IH 80-65-125 | 30 | 23.2 | 5.5 | 2900 | ||||
IH 80-65-160 | 30 | 36 | 11 | 2900 | ||||
IH 80-50-200 | 30 | 55.2 | 15 | 2900 | ||||
IH 80-50-250 | 30 | 84 | 30 | 2900 | ||||
IH 80-50-315 | 30 | 128 | 48 | 2900 | ||||
IH 100-80-125 | 60 | 23.7 | 11 | 2900 | ||||
IH 100-80-160 | 60 | 37 | 15 | 2900 | ||||
IH 100-65-200 | 60 | 56 | 22 | 2900 | ||||
IH 100-65-250 | 60 | 88 | 37 | 2900 | ||||
IH 100-65-315 | 60 | 132 | 75 | 2900 | ||||
IH 125-100-200 | 120 | 61 | 45 | 2900 | ||||
IH 125-100-250 | 120 | 90 | 75 | 2900 | ||||
IH 125-100-315 | 120 | 132.5 | 110 | 2900 | ||||
IH 125-100-400 | 60 | 52 | 30 | 1450 | ||||
IH 150-125-250 | 120 | 24.8 | 30 | 1450 | ||||
IH150-125-315 | 120 | 36.3 | 30 | 1450 | ||||
IH150-125-400 | 120 | 57.5 | 55 | 1450 | ||||
IH200-150-250 | 240 | 23 | 37 | 1450 | ||||
IH200-150-315 | 240 | 35.6 | 55 | 1450 | ||||
IH200-150-400 | 240 | 55.8 | 90 | 1450 | ||||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1+ set: US $580 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this stainless steel horizontal pump?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a One Year warranty. Spare parts and technical support remain available after the warranty period.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Hebei Minerco Machinery Co., Ltd., based in China. The company 1 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Hebei Minerco Machinery Co., Ltd. range on HVACR Nexus.
