This wall fan is published with the manufacturer’s full specification — 12V, power source Electric. Made by Henan Superfan Electronic Equipment Co., Ltd. (2 years on the platform, typical reply ≤3h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Wall Fan
- Power Source: Electric
- Voltage: 12V
- Material: Plastic
- Blade Material: Plastic
- Speed: 5500RPM
- Warranty: 1 Year
Technical Specifications
| Blade Diameter | 38mm |
|---|---|
| Voltage | 12V |
| Speed | 5500RPM |
| Type | Blower |
| Material | Plastic |
| Blade Material | Plastic |
| Mounting Type | Free Standing |
| Bearing Type | Sleeve Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Field installation, commissioning and training |
| Customized Support | OEM, ODM, OBM |
| Place Of Origin | Henan, China |
| Brand Name | Anne Well |
| Size | 40*40*20mm |
| Product Name | DC Blower Fan |
| Application | Electric Equipment |
| Motor Type | 2-Pole DC Brushless Motor |
| Current | 0.09A |
| Noise | 30.0DBA |
| Advantage | Bidirectional Airflow,Low Noise |
| MOQ | 1 Pcs |
| Free Sample | Available |
| Weight | 25g/Piece |
| Selling Units | Single item |
| Single Package Size | 6X6X4 cm |
| Single Gross Weight | 0.027 kg |
Product Details
| Listed Model | Bearing System | Rated Voltage | Operation Voltage | Rated Current | Rated Power | Speed | Air Flow | Static Pressure | Noise Level | Available Features(Optional) | Weight | |||
| VDC | VDC | AMP | W | RPM | CFM | mmH2O | dBA | FG | RD | Thermal Control | PWM | G | ||
| WDF4020HS/B-G | Sleeve/ Ball | 5 | 3.5~6.0 | 0.15 | 0.75 | 8,000 | 3.30 | 14.6 | 40.0 | * | * | * | 25 | |
| WDF4020MS/B-G | 3.5~6.0 | 0.12 | 0.60 | 6,500 | 2.64 | 8.90 | 34.0 | * | * | * | ||||
| WDF4020LS/B-G | 3.5~6.0 | 0.10 | 0.50 | 5,500 | 2.25 | 5.80 | 30.0 | * | * | * | ||||
| WDF4020HS/B-G | Sleeve/ Ball | 12 | 5.0~14.0 | 0.13 | 1.56 | 8,000 | 3.30 | 14.6 | 40.0 | * | * | * | ||
| WDF4020MS/B-G | 5.0~14.0 | 0.10 | 1.20 | 6,500 | 2.64 | 8.90 | 34.0 | * | * | * | ||||
| WDF4020LS/B-G | 5.0~14.0 | 0.09 | 1.08 | 5,500 | 2.25 | 5.80 | 30.0 | * | * | * | ||||
| WDF4020HS/B-G | Sleeve/ Ball | 24 | 12.0~26.0 | 0.08 | 1.92 | 8,000 | 3.30 | 14.6 | 40.0 | * | * | * | ||
| WDF4020MS/B-G | 12.0~26.0 | 0.06 | 1.44 | 6,500 | 2.64 | 8.90 | 34.0 | * | * | * | ||||
| WDF4020LS/B-G | 12.0~26.0 | 0.05 | 1.20 | 5,500 | 2.25 | 5.80 | 30.0 | * | * | * | ||||
4020 40*20mm 12V Electric Plastic Fan 0.09A 5500RPM Car Seat Cushion Wall Fan Silent Operation Mini Blower Exhaust Fans OEM ODM
PACKAGING: Brown carton or according to customer requirement.
SHIPPING:
1.Samples delivery time is 1-3 working days. Bulk order delivery time is 1~3 weeks and is according to the order quantity.
2.Fans can be dispatched by our truck driver if your factory is in Shenzhen, Dongguang or Guangzhou City.
3.Fans could be delivered by express ( FedEx, DHL, UPS, TNT, EMS or SF ) for under 100 kg, our shipping agent have discount with these express company.
4.Large Measure are shipped by sea or air as customer's requirements.
5.FOB port can be Guangzhou, Shenzhen, Xiamen, Shanghai, Ningbo, Qingdao,etc.
1. What is a DC Axial Fan?
A DC fan is usually powered by 3v, 5v, 12v, 24v, 36v and 48v. DC motor runs from the attract and repel of the permanent magnet inside the motor. It blows air along the axis of the fan, or parallel to the track of the blade axis to create changeable and not stable air-flow. Standard DC axial fan sizes include 20mm, 30mm, 40mm, 50mm, 60mm, 70mm, 80mm, 92mm, 120mm, 140mm, 150mm, 172mm, 200mm and 254mm.
2. How to choose a DC fan?
You should consider the points of blow:
-Size(MM)
-Rated voltage(V)
-Speed(RPM)
-Airflow(CFM)
-Noise level(dBA)
-Current(A)
-Connector
3. What is a Bearing?
Fan bearing includes
-Sleeve Bearing Fan: life expectancy 30000 hours,
-Hydraulic Bearing Fan: life expectancy 40000 hours,
-Ball Bearing Fan: life expectancy 50000 hours or more.
4. Are you a factory or a trading company?
Yes, we are a factory.
-Established Year: 2015
-The Number of total employees: 516
-No of R&D team member: 15
-No of QC team member: 15
-Production & Test Facility: 39
-No of Production Line: 6
-Certification: UL, CUL,TUV,CE,CCC,SGS,ISO:9001-2008
5. What is the delivery time?
Sample lead time: 3~5 business days. Mass production delivery lead time: 1~3 weeks,
Delivery Ways: FedEX, DHL, UPS, TNT Door to Door Express service, By Air, By Sea, etc.
6. Can you provide any sample? Is it free or extra?
Yes, we can offer the samples for free charge, but you are suggested taking charge of the relative freight cost.
Ordering and Pricing
- Minimum order quantity: 1 piece
- Volume pricing:
- 1–499 piece: US $1.16 / piece
- 500–999 piece: US $1.09 / piece
- 1000–4999 piece: US $1 / piece
- 5000+ piece: US $0.88 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this wall fan?
The standard minimum order quantity is 1 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the wall fan be supplied for my local voltage?
The standard configuration is 12V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Henan Superfan Electronic Equipment Co., Ltd., based in China. The company 2 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Henan Superfan Electronic Equipment Co., Ltd. range on HVACR Nexus.
