The electric fireplace listed here carries max airflow 70-250m3/h, type dc motor, documented exactly as the manufacturer publishes it. Made by Zhongshan City Yuanjing Zhuoli Motor Co., Ltd. (2 years on the platform, typical reply ≤4h). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Electric Fireplace
- Model Number: ZL3725
- Rated Power: 10 W
- AC Voltage: 115/120 V
- Max Airflow: 70-250m3/h
- Rated Speed: 1400-2200 rpm
- Speed: 1400-2200 rpm
Technical Specifications
| Phase | Single-Phase |
|---|---|
| AC Voltage | 115/120 V |
| Rated Power | 10 W |
| Rated Speed | 1400-2200 rpm |
| Type | dc motor |
| Frame | / |
| Motor Mounting Type | Housing |
| Protect Feature | Explosion-proof |
| Efficiency | IE 1 IE 2 IE 3 IE 4 |
| Warranty | 3Years |
| Model Number | ZL3725 |
| Brand Name | YUANJING |
| Place Of Origin | Guangdong, China |
| Frequency | 50hz/60hz |
| Product Name | Cross flow fan for 60 Series |
| Insulation Class | B, E, F, H |
| Environmental Temperature | -15°C-105°C |
| Max Airflow | 70-250m3/h |
| Usage | Oven, fan heater, air curtain, electric fireplace, ventilation, etc. |
| Certification | CCC,CE,ROHS,UL,TUV,REACH,ISO9001:2015 |
| Max Static Pressure | 48-46m3/h |
| Noise DB(A) | 43-45 |
| Total Length | 188-453mm |
| Speed | 1400-2200 rpm |
| Selling Units | Single item |
| Single Package Size | 15X26X18 cm |
| Single Gross Weight | 3.0 kg |
Product Details
MODER | VOLTAGE/V | FREQUENCY/HZ | INPUT POWER/W | RPM | CURRENT/A |
YJ48-180 | 120 | 60 | 12 | 1200 | 0.2 |
YJ48-180 | 220-240 | 50 | 11 | 1200 | 0.1 |
YJ48-188 | 120 | 60 | 14 | 1450 | 0.25 |
YJ48-200 | 120 | 60 | 14.5 | 1200 | 0.22 |
YJ48-200 | 220-240 | 50 | 12 | 1200 | 0.1 |
YJ48-260 | 120 | 60 | 14.5 | 1000 | 0.2 |
YJ48-300 | 220-240 | 50 | 17.5 | 1200 | 0.13 |
YJ48-420 | 120 | 60 | 20 | 1200 | 0.3 |
ZL37-25 | DC 12V | / | 3W | 1250 | 0.2 |
FAQ
Ordering and Pricing
- Minimum order quantity: 1000 piece
- Volume pricing:
- 1000–4999 piece: US $3.35 / piece
- 5000–19999 piece: US $3.25 / piece
- 20000+ piece: US $3.15 / piece
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this electric fireplace?
The standard minimum order quantity is 1000 piece. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 3Years warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this electric fireplace carry?
It is supplied with CCC,CE,ROHS,UL,TUV,REACH,ISO9001:2015 documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the electric fireplace be supplied for my local voltage?
The standard configuration is 115/120 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Zhongshan City Yuanjing Zhuoli Motor Co., Ltd., based in China. The company 2 years as a verified Alibaba.com supplier, operates its own manufacturing. Browse the full Zhongshan City Yuanjing Zhuoli Motor Co., Ltd. range on HVACR Nexus.
