The high quality plate listed here carries voltage as per request, material Stainless Steel, documented exactly as the manufacturer publishes it. For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This High Quality Plate
- Voltage: as per request
- Flow Capacity: customized
- Material: Stainless Steel
- Plate Material: SS304/SS316/SS316L/Titanium
- Gasket Material: NBR/EPDM/FKM
- Frame Material: GS/SS
Technical Specifications
| Heat Exchanger Type | Plate Heat Exchanger |
|---|---|
| Flow Capacity | customized |
| Fluid Compatibility | customized |
| Material | Stainless Steel |
| Maximum Operating Temperature | customized |
| Voltage | as per request |
| Core Components | Engine |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Competitive Price |
| Working Temperature Range | customized |
| Place Of Origin | Jiangsu, China |
| Weight (Kg) | 100 |
| Brand Name | GOJE |
| Liquid Flow Rate | Customized Made |
| Maximum Pressure Rating | 2.5Mpa(362.59psi) |
| Dimension(L*W*H) | DESIGNED |
| After-Sales Service Provided | Engineers available to service machinery overseas |
| Color | Blue |
| Type | plate heat exchanger |
| Application | heating or cooling |
| Plate Material | SS304/SS316/SS316L/Titanium |
| Gasket Material | NBR/EPDM/FKM |
| Frame Material | GS/SS |
| Interface Material | CS/304/316L/hastelloy/Ti |
| Marketing Type | Ordinary Product |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
Plate Material Characteristics | ||
Material | Application | |
SS304 | Drink water, None Corrosive Liquid, Oils, Fresh Steam etc. | |
SS316L | Well water, river water, closed circulating water and other water with complex components, Dilute sulfuric acid with temperature ≤ 50 ℃ and concentration ≤ 10% etc. | |
Titanium | Liquid that contains chlorine iron, Sea water etc. | |
Titanium Palladium Alloy | Higher temperature and corrosion resistance than titanium. | |
Nickel 20 | It is mainly used for caustic solution (NaOH, Koh, etc.) with high concentration (50% ~ 70%) and high temperature (boiling point). | |
Hastelloy C-276 | It has good corrosion resistance, almost not affected by Cl -, excellent corrosion resistance to various concentrations of sulfuric acid, and is one of the few materials that can be used in hot concentrated sulfuric acid, widely used in organic acids (such as formic acid, acetic acid), high temperature HF acid and a certain concentration of hydrochloric acid (< 40%), phosphoric acid (< 50%); chloride, fluoride. | |
Gasket Material Charactristics | ||||
Material | Working Temperature | Working Enviroment | ||
NBR | -25~120℃ | Alkane, olefin and other non-polar media, all kinds of mineral oil, animal and vegetable oil, hot water, salt water, etc。 | ||
EPDM | -50~170℃ | Superheated water, steam, atmospheric ozone, non petroleum based lubricating oil, weak acid, weak base, ketone alcohol, etc | ||
HNBR | -25~150℃ | Crude oil, sulfur-containing oil and organic sulfur compounds, some heat transfer oil, new refrigerant 134a, etc | ||
Viton | -25~150℃ | Nonpolar mineral oil, high temperature water vapor, sulfuric acid, chlorine water, phosphate with concentration above 98% | ||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–9 set: US $300 / set
- 10+ set: US $200 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this high quality plate?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the high quality plate be supplied for my local voltage?
The standard configuration is as per request. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by JIANGSU GAOJIE ENERGY SAVING EQUIPMENT GROUP CO., LTD., based in China. The company 11 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full JIANGSU GAOJIE ENERGY SAVING EQUIPMENT GROUP CO., LTD. range on HVACR Nexus.
